Huawei Technologies Co., Ltd Tecal CH121 ssj_ops@100% = 13,828,286
ssj_ops@100% per Host = 1,728,536
ssj_ops@100% per JVM = 172,854
Test Sponsor: Huawei Technologies Co., Ltd SPEC License #: 3175 Test Method: Multi Node
Tested By: Huawei Technologies Co., Ltd Test Location: Shenzhen, Guangdong, China Test Date: Sep 6, 2013
Hardware Availability: Sep-2013 Software Availability: Jan-2012 Publication: Oct 21, 2013
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     13,567,761
Calibration 2     13,865,156
Calibration 3     13,869,827
ssj_ops@calibrated=13,867,492
100% 99.7% 13,867,492 13,828,286
90% 90.0% 12,480,743 12,477,388
80% 80.0% 11,093,994 11,094,670
70% 70.0% 9,707,244 9,704,461
60% 60.1% 8,320,495 8,329,164
50% 50.0% 6,933,746 6,935,082
40% 40.0% 5,546,997 5,546,081
30% 30.0% 4,160,248 4,164,300
20% 20.0% 2,773,498 2,773,565
10% 10.0% 1,386,749 1,390,341
Active Idle   0 0
Graph of results
Aggregate SUT Data
# of Nodes # of Chips # of Cores # of Threads Total RAM (GB) # of OS Images # of JVM Instances
8 16 160 320 192 8 80
System Under Test
Shared Hardware
Shared Hardware
Enclosure: Huawei Tecal E9000
Form Factor: 12U
Power Supply Quantity and Rating (W): 1 x 3000
Power Supply Details: Huawei P/N PW02310LKL
Network Switch: Huawei Quidway S5348TP-SI
Network Switch Details: 48-PORT Quidway S5348TP-SI
KVM Switch: None
KVM Switch Details: None
Other Hardware: None
Comment: None
Set: 'sut'
Set Identifier: sut
Set Description: System Under Test
# of Identical Nodes: 8
Comment: None
Hardware per Node
Hardware Vendor: Huawei Technologies Co., Ltd
Model: Tecal CH121
Form Factor: Blade
CPU Name: Intel Xeon E5-2660 v2
CPU Characteristics: 10-Core, 2.2GHz, 25MB L3 Cache (Intel Turbo Boost Technology up to 3.0GHz)
CPU Frequency (MHz): 2200
CPU(s) Enabled: 20 cores, 2 chips, 10 cores/chip
Hardware Threads: 40 (2 / core)
CPU(s) Orderable: 1,2 chips
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 256 KB I+D on chip per core
Tertiary Cache: 25 MB I+D on chip per chip
Other Cache: None
Memory Amount (GB): 24
# and size of DIMM: 6 x 4 GB
Memory Details: 4GB 2Rx8 PC3L-10600R ECC RDIMM,Slots 1A1 1B1, 1C1,2A1,2B1,2C1 populated
Power Supply Quantity and Rating (W): None
Power Supply Details: Shared
Disk Drive: 1 x 240GB SSD 2.5" SATA Huawei P/N 02310MMT
Disk Controller: Integrated SATA controller
# and type of Network Interface Cards (NICs) Installed: 1 x Dual-port Intel 82580 Gigabit Ethernet controller
NICs Enabled in Firmware / OS / Connected: 2/2/1
Network Speed (Mbit): 1000
Keyboard: None
Mouse: None
Monitor: None
Optical Drives: No
Other Hardware: None
Software per Node
Power Management: Power Saver Mode enabled in OS
Operating System (OS): Microsoft Windows Server 2008 Enterprise x64 Edition
OS Version: R2 SP1 (64-bit)
Filesystem: NTFS
JVM Vendor: IBM Corporation
JVM Version: IBM J9 VM (build 2.6,JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120322_106209 (JIT enabled, AOT enabled)
JVM Command-line Options: -Xaggressive -Xcompressedrefs -Xmx1875m -Xms1875m -Xmn1400m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -Xconcurrentlevel0
JVM Affinity: start /affinity [F,F0,F00,F000,F0000,F00000,F000000,F0000000,F00000000,F000000000]
JVM Instances: 10
JVM Initial Heap (MB): 1875
JVM Maximum Heap (MB): 1500
JVM Address Bits: 64
Boot Firmware Version: V063
Management Firmware Version: 3.35
Workload Version: SSJ 1.2.10
Director Location: Controller
Other Software: IBM SDK Java Technology Edition Version 7.0 for windows x64
Boot Firmware Settings
Management Firmware Settings
none
System Under Test Notes
Notes
None
Host Instance Summary
Host ssj_ops@100%
WIN-31IEMCI502Q 1,736,862
WIN-4RHT5K6DGDR 1,719,703
WIN-6CL781RHVI7 1,722,741
WIN-B44R29Q23JP 1,735,667
WIN-K2ET5B05GLG 1,725,000
WIN-L5GJVQGBAGG 1,732,303
WIN-Q4POSRLKNCI 1,723,109
WIN-U43FQGB3PEV 1,732,901
ssj_ops@100% 13,828,286
ssj_ops@100% per Host 1,728,536
ssj_ops@100% per JVM 172,854
Graph of per-host results
Host 'WIN-31IEMCI502Q' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,702,574
Calibration 2     1,738,347
Calibration 3     1,741,556
ssj_ops@calibrated=1,739,952
100% 99.8% 1,739,952 1,736,862
90% 89.9% 1,565,956 1,563,531
80% 80.1% 1,391,961 1,394,117
70% 70.0% 1,217,966 1,218,812
60% 60.1% 1,043,971 1,044,885
50% 49.9% 869,976 867,388
40% 40.0% 695,981 696,178
30% 29.9% 521,985 520,753
20% 20.0% 347,990 347,960
10% 10.0% 173,995 174,669
Active Idle   0 0
Graph of results
See the Host Performance Report for additional details.
Host 'WIN-4RHT5K6DGDR' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,686,814
Calibration 2     1,728,558
Calibration 3     1,724,585
ssj_ops@calibrated=1,726,572
100% 99.6% 1,726,572 1,719,703
90% 90.1% 1,553,914 1,555,435
80% 80.0% 1,381,257 1,381,028
70% 69.9% 1,208,600 1,206,930
60% 60.1% 1,035,943 1,037,557
50% 49.9% 863,286 861,891
40% 39.9% 690,629 689,759
30% 30.1% 517,971 519,308
20% 20.0% 345,314 344,892
10% 10.0% 172,657 172,786
Active Idle   0 0
Graph of results
See the Host Performance Report for additional details.
Host 'WIN-6CL781RHVI7' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,691,315
Calibration 2     1,729,942
Calibration 3     1,731,200
ssj_ops@calibrated=1,730,571
100% 99.5% 1,730,571 1,722,741
90% 90.0% 1,557,514 1,557,340
80% 79.8% 1,384,457 1,380,585
70% 70.0% 1,211,400 1,211,538
60% 60.0% 1,038,343 1,038,306
50% 50.1% 865,286 867,812
40% 40.1% 692,229 694,253
30% 30.1% 519,171 521,036
20% 20.0% 346,114 346,462
10% 10.0% 173,057 172,492
Active Idle   0 0
Graph of results
See the Host Performance Report for additional details.
Host 'WIN-B44R29Q23JP' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,700,772
Calibration 2     1,741,842
Calibration 3     1,741,903
ssj_ops@calibrated=1,741,873
100% 99.6% 1,741,873 1,735,667
90% 90.1% 1,567,685 1,570,182
80% 80.0% 1,393,498 1,392,737
70% 69.8% 1,219,311 1,216,268
60% 60.1% 1,045,124 1,046,386
50% 50.0% 870,936 870,167
40% 40.0% 696,749 696,070
30% 30.1% 522,562 523,566
20% 20.0% 348,375 347,844
10% 10.0% 174,187 174,472
Active Idle   0 0
Graph of results
See the Host Performance Report for additional details.
Host 'WIN-K2ET5B05GLG' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,685,702
Calibration 2     1,726,695
Calibration 3     1,727,154
ssj_ops@calibrated=1,726,925
100% 99.9% 1,726,925 1,725,000
90% 89.8% 1,554,232 1,550,884
80% 79.7% 1,381,540 1,377,127
70% 70.1% 1,208,847 1,210,466
60% 60.1% 1,036,155 1,038,476
50% 50.0% 863,462 863,344
40% 40.0% 690,770 690,096
30% 29.9% 518,077 516,574
20% 20.0% 345,385 346,146
10% 10.1% 172,692 173,627
Active Idle   0 0
Graph of results
See the Host Performance Report for additional details.
Host 'WIN-L5GJVQGBAGG' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,707,151
Calibration 2     1,737,157
Calibration 3     1,736,546
ssj_ops@calibrated=1,736,852
100% 99.7% 1,736,852 1,732,303
90% 90.1% 1,563,167 1,564,172
80% 80.2% 1,389,481 1,392,523
70% 70.0% 1,215,796 1,214,938
60% 59.9% 1,042,111 1,040,339
50% 50.1% 868,426 869,878
40% 40.0% 694,741 694,879
30% 30.0% 521,056 521,663
20% 19.9% 347,370 345,949
10% 10.0% 173,685 173,739
Active Idle   0 0
Graph of results
See the Host Performance Report for additional details.
Host 'WIN-Q4POSRLKNCI' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,697,264
Calibration 2     1,726,925
Calibration 3     1,729,831
ssj_ops@calibrated=1,728,378
100% 99.7% 1,728,378 1,723,109
90% 89.9% 1,555,540 1,554,123
80% 80.2% 1,382,702 1,386,823
70% 69.9% 1,209,865 1,207,988
60% 60.1% 1,037,027 1,038,136
50% 50.0% 864,189 865,040
40% 40.1% 691,351 692,640
30% 30.1% 518,513 520,253
20% 20.0% 345,676 345,699
10% 10.1% 172,838 173,815
Active Idle   0 0
Graph of results
See the Host Performance Report for additional details.
Host 'WIN-U43FQGB3PEV' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,696,169
Calibration 2     1,735,690
Calibration 3     1,737,051
ssj_ops@calibrated=1,736,370
100% 99.8% 1,736,370 1,732,901
90% 89.9% 1,562,733 1,561,722
80% 80.0% 1,389,096 1,389,732
70% 70.1% 1,215,459 1,217,521
60% 60.2% 1,041,822 1,045,079
50% 50.1% 868,185 869,561
40% 39.9% 694,548 692,205
30% 30.0% 520,911 521,147
20% 20.1% 347,274 348,612
10% 10.1% 173,637 174,741
Active Idle   0 0
Graph of results
See the Host Performance Report for additional details.
