| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | December 2000 |
| Software Available | July 2001 |
| Date Tested | September 2001 |
| SFS License Number | 33 |
| Licensee Locations | Sunnyvale, CA |
| CPU, Memory and Power |
|---|
| Model Name | F840 (TCP, 42x36GB FCAL, GbE) |
| Processor | 733-MHz Intel Pentium III Coppermine |
| # of Processors | 1 core, 1 chip, 1 core/chip |
| Primary Cache | 16 KB I + 16 KB D |
| Secondary Cache | 256 KB on-die |
| Other Cache | N/A |
| UPS | none |
| Other Hardware | none |
| Memory Size | 3072 MB |
| NVRAM Size | 128 MB |
| NVRAM Type | DIMM on PCI card |
| NVRAM Description | 15-day battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | Data ONTAP 6.1.1 |
| Other Software | none |
| File System | WAFL |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | default |
| # NFS Processes | N/A |
| Fileset Size | 102.5 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | X1025B PCI adapter card |
| Number Networks | 1 (N1) |
| Number Network Controllers | 1 |
| Protocol Type | TCP |
| Switch Type | Extreme Summit4 (N1) |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 |
| Number of Disks | 42 |
| Number of Filesystems | 1 |
| File System Creation Ops | default |
| File System Config | 5 RAID-groups of 8 disks each |
| Disk Controller | X2040B FC-AL adapter card (128 KB RAM standard) |
| # of Controller Type | 2 |
| Number of Disks | 7,7,7/7,7,7 |
| Disk Type | X231A 36GB FC-AL |
| File Systems on Disks | F1/F1 |
| Special Config Notes | none |
|
