| Availability Dates |
|---|
| Hardware | Aug-98 |
| HTTP Software | Oct-98 |
| Operating System | Feb-99 |
| Hardware |
|---|
| Vendor | IBM |
| Model | RS/6000 S70 |
| Processor | 262 MHz RS64-2 |
| # of Processors | 12 |
| Primary Cache | 64KBI+64KBD on chip |
| Secondary Cache | 8MB(I+D) off chip |
| Other Cache | None |
| Memory | 8192MB |
| Disk Subsystem | 4 9.1GB 16 Bits SCSI Disk Drive |
| Disk Controllers | Wide SCSI I/O Controller |
| Other Hardware | -- |
| Software |
|---|
| Operating System | AIX 4.3.2 + APAR IX83061 |
| File System Type | JFS |
| Other Software | None |
| HTTP Software |
|---|
| Vendor | Zeus Technology Ltd |
| HTTP Software | Zeus 1.3.3 |
| # of "threads" | 12 |
| Server Cache | See Below |
| Log Mode | Common Log Format |
|
| Test Sponsor |
|---|
| Test Date | Oct-98 |
| Tested By | IBM Austin |
| SPEC License | 11 |
| Network |
|---|
| # of Controllers | 12 |
| Network Controllers | IBM PCI 155 Mbps ATM Adapter |
| # of Nets | 12 |
| Type of Nets | ATM |
| Network Speed | 155 Mb/sec |
| MSL (sec) | 30 (Non RFC1122) |
| Time-Wait (sec) | 60 (Non RFC1122) |
| Load Generators |
|---|
| # of Load Generators | 36 |
| # of Processes Each | 12 |
| Model | See Below |
| Processor | PowerPC 604e |
| # of Processors | 2 |
| Memory | 256MB |
| Network Controller | IBM PCI 155 Mbps ATM |
| Operating System | AIX 4.3.2 |
| Compiler | IBM Cset++ Version 3.1.3 |
| Benchmark Configuration |
|---|
| Maximum Requested Load | 12400 |
| Maximum Fileset Size (MB) | 2431 |
|
