| Availability Dates |
|---|
| Hardware | Sep-97 |
| HTTP Software | Dec-97 |
| Operating System | Nov-97 |
| Hardware |
|---|
| Vendor | Fujitsu LTD. |
| Model | GRANPOWER 7000 model 600 |
| Processor | 248MHz UltraSPARC-II |
| # of Processors | 8 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 1MB(I+D) off chip |
| Other Cache | None |
| Memory | 4096MB |
| Disk Subsystem | 4GB for OS and log and 4GB for webserver |
| Disk Controllers | 1 on board SCSI |
| Other Hardware | None |
| Software |
|---|
| Operating System | UXP/DS V20L23 |
| File System Type | ufs |
| Other Software | None |
| HTTP Software |
|---|
| Vendor | Fujitsu LTD. |
| HTTP Software | InfoProvider Pro V10L21 |
| # of "threads" | 40 |
| Server Cache | See Notes |
| Log Mode | Common |
|
| Test Sponsor |
|---|
| Test Date | Sep-97 |
| Tested By | Fujitsu LTD |
| SPEC License | 19 |
| Network |
|---|
| # of Controllers | 9 |
| Network Controllers | on board and LANF/B x8 |
| # of Nets | 9 |
| Type of Nets | 100BASE-T Hub's |
| Network Speed | 100Mbit |
| MSL (sec) | 30 (Non RFC1122) |
| Time-Wait (sec) | 60 (Non RFC1122) |
| Load Generators |
|---|
| # of Load Generators | 9 |
| # of Processes Each | 18 |
| Model | GRANPOWER 7000 Model 200 |
| Processor | 167UltraSPARC |
| # of Processors | 2 |
| Memory | 512MB |
| Network Controller | on board |
| Operating System | UXP/DS V20L23 |
| Compiler | cc |
| Benchmark Configuration |
|---|
| Maximum Requested Load | 3600 |
| Maximum Fileset Size (MB) | 1313 |
|
