| Name | R620 G50 |
| Vendor | Nettrix |
| Vendor URL | https://www.nettrix.com.cn |
| Available | Apr-2024 |
| Model | R620 G50 |
| Form Factor | 2U |
| CPU Name | Intel(R) Xeon(R) Platinum 8562Y+ CPU @ 2.8GHz |
| CPU Characteristics | 32Core, 2.80GHz, 60MB L3 Cache (Turbo Boost Technology up to 4.1 GHz) |
| Number of Systems | 1 |
| Nodes Per System | 1 |
| Chips Per System | 2 |
| Cores Per System | 64 |
| Cores Per Chip | 32 |
| Threads Per System | 128 |
| Threads Per Core | 2 |
| Version | NNH1041268 |
| CPU Frequency (MHz) | 2800 |
| Primary Cache | 32KB I + 48KB D on chip per core |
| Secondary Cache | 2 MB I+D on chip per core |
| Tertiary Cache | 60MB I+D on chip per chip |
| Other Cache | None |
| Disk | 1x 960GB NVMe SSD |
| File System | btrfs |
| Memory Amount (GB) | 1024 |
| # and size of DIMM(s) | 16 x 64GB |
| Memory Details | 16 x 64GB-Hynix-DDR5-5600-2Rx4 |
| # and type of Network Interface Cards (NICs) | 4 x 1 Gbit NICs |
| Power Supply Quantity and Rating (W) | 2 x 2000W |
| Other Hardware | 1 x OCP with 4 x 1 Gbit NICs |
| Cabinet/Housing/Enclosure | None |
| Shared Description | None |
| Shared Comment | None |
| Notes | - NA: The test sponsor attests, as of date of publication, that CVE-2017-5754 (Meltdown) is mitigated in the system as tested and documented.
- Yes: The test sponsor attests, as of date of publication, that CVE-2017-5753 (Spectre variant 1) is mitigated in the system as tested and documented.
- Yes: The test sponsor attests, as of date of publication, that CVE-2017-5715 (Spectre variant 2) is mitigated in the system as tested and documented.
|
|
| Name | None |
| Vendor | None |
| Vendor URL | None |
| Version | None |
| Available | None |
| Bitness | None |
| Notes | None |
