SPECjbb2005 SPECjbb2005 bops = 2085977, SPECjbb2005 bops/JVM = 173831
IBM Corporation IBM System x3500 M4
IBM Corporation IBM J9 VM (build 2.6, JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120204_101769 (JIT enabled, AOT enabled)

JVM run JVM Scores
1176999
2176276
3177070
4173398
5175276
6171533
7171535
8172863
9171621
10176453
11173517
12169436
SPECjbb2005 bops = 2085977, SPECjbb2005 bops/JVM = 173831

Hardware
Hardware Vendor IBM Corporation
Vendor URL http://www.ibm.com
Model IBM System x3500 M4
Processor Intel Xeon E5-2697 v2 (Intel Turbo Boost Technology up to 3.5 GHz)
MHz 2700
# of Chips 2
# of Cores 24
# of Cores/Chip 12
HW Threading Enabled? Yes
Procs Avail to Java 48
Memory (MB) 262144
Memory Details 16 x 16384MB, 2Rx4 PC3-14900R; slots 1, 2, 4, 5, 8, 9, 11, 12, 13, 14, 16, 17, 20, 21, 23 and 24 populated
Primary cache 32KBI+32KBD
Secondary cache 256 KB (I+D) on chip per core
Other cache 30 MB per processor
Filesystem NTFS
Disks 1 x 200GB 2.5" SATA SSD
Other hardware
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version IBM J9 VM (build 2.6, JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120204_101769 (JIT enabled, AOT enabled)
JVM Command Line set JAVAOPTIONS=-Xaggressive -Xcompressedrefs -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -Xconcurrentlevel0
JVM Initial Heap Memory (MB) 1400
JVM Maximum Heap Memory (MB) 1875
JVM Address bits 64
JVM CLASSPATH .\jbb.jar;
.\check.jar;
JVM BOOTCLASSPATH C:\IBM\ibm_sdk70\jre\bin\compressedrefs\jclSC170\vm.jar;
C:\IBM\ibm_sdk70\jre\lib\se-service.jar;
C:\IBM\ibm_sdk70\jre\lib\math.jar;
C:\IBM\ibm_sdk70\jre\lib\jlm.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmorb.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmorbapi.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmcfw.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmpkcs.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmcertpathfw.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmjgssfw.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmjssefw.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmsaslfw.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmjcefw.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmjgssprovider.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmjsseprovider2.jar;
C:\IBM\ibm_sdk70\jre\lib\ibmcertpathprovider.jar;
C:\IBM\ibm_sdk70\jre\lib\xmldsigfw.jar;
C:\IBM\ibm_sdk70\jre\lib\xml.jar;
C:\IBM\ibm_sdk70\jre\lib\charsets.jar;
C:\IBM\ibm_sdk70\jre\lib\resources.jar;
C:\IBM\ibm_sdk70\jre\lib\rt.jar
OS Version Microsoft Windows Server 2008 R2 Enterprise x64 SP1
Other software
Test Information
Tested by IBM Corporation
SPEC license # 11
Test location Taipei, Taiwan
Test date Aug 30, 2013
H/w available Dec 2013
JVM available Mar 2012
OS available July 2008
Other s/w available
AOT Compilation

Tuning
  • Affinity masks set to 0xF, 0xF0, 0xF00, 0xF000, 0xF0000, 0xF00000, 0xF000000, 0xF0000000, 0xF00000000, 0xF000000000, 0xF0000000000, 0xF00000000000
  • Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
  • BIOS Settings
    • Turbo Mode: Enable
    • All Prefetcher: Disable
    • QPI Link Frequency: Max Performance
    • Memory Power Management: Disable
    • Patrol Scrub: Disable
    • Memory Data Scrambling: Disable
    • Active Energy Management: Capping Disabled
    • Power/Performance Bias: Platform Controlled
    • Platform Controlled Type: Max Performance
Notes



JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 55899
2 141015
3 155269
4 178533 *
5 178329 *
6 176856 *
7 176862 *
8 174416 *
SPECjbb2005 (from 4 to 8) 176999 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 56764
2 143270
3 163366
4 179139 *
5 177360 *
6 176356 *
7 174952 *
8 173571 *
SPECjbb2005 (from 4 to 8) 176276 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 58339
2 141337
3 157580
4 178986 *
5 178720 *
6 178024 *
7 175594 *
8 174026 *
SPECjbb2005 (from 4 to 8) 177070 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 54428
2 141060
3 159688
4 174904 *
5 174660 *
6 172944 *
7 172100 *
8 172382 *
SPECjbb2005 (from 4 to 8) 173398 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 59232
2 146061
3 165830
4 178179 *
5 176758 *
6 175494 *
7 172488 *
8 173463 *
SPECjbb2005 (from 4 to 8) 175276 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 52677
2 133567
3 162096
4 174191 *
5 171484 *
6 171383 *
7 170575 *
8 170032 *
SPECjbb2005 (from 4 to 8) 171533 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 58607
2 138188
3 162093
4 173867 *
5 172869 *
6 171715 *
7 170365 *
8 168858 *
SPECjbb2005 (from 4 to 8) 171535 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 54698
2 135782
3 160784
4 175594 *
5 173832 *
6 172461 *
7 171528 *
8 170902 *
SPECjbb2005 (from 4 to 8) 172863 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 53402
2 141201
3 159809
4 173252 *
5 172694 *
6 171566 *
7 170800 *
8 169794 *
SPECjbb2005 (from 4 to 8) 171621 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 58101
2 146977
3 161539
4 179031 *
5 176897 *
6 176317 *
7 175548 *
8 174472 *
SPECjbb2005 (from 4 to 8) 176453 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 54096
2 137564
3 158995
4 176093 *
5 174148 *
6 173383 *
7 171844 *
8 172118 *
SPECjbb2005 (from 4 to 8) 173517 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013


JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 55934
2 142417
3 158372
4 171654 *
5 170371 *
6 170027 *
7 168361 *
8 166766 *
SPECjbb2005 (from 4 to 8) 169436 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Aug 30, 2013

SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 02-Oct-2013
