SPECjbb2005 SPECjbb2005 bops = 2495770, SPECjbb2005 bops/JVM = 103990
IBM Corporation IBM Flex System p270 (3.4 GHz, 24 core)
IBM Corporation JRE 1.7.0 (32-bit) IBM J9 2.6 AIX [build pap3270sr3-20120319_01(SR3)]

JVM run JVM Scores
1103925
2104289
3103173
4103622
5104311
6103203
7102685
8104393
9104917
10104552
11105374
12103337
13102690
14103818
15103600
16105588
17102471
18103622
19105166
20104886
21104070
22103835
23104340
24103903
SPECjbb2005 bops = 2495770, SPECjbb2005 bops/JVM = 103990

Hardware
Hardware Vendor IBM Corporation
Vendor URL http://www.ibm.com
Model IBM Flex System p270 (3.4 GHz, 24 core)
Processor POWER7+ (Intelligent Energy Optimization enabled, up to 3787 MHz)
MHz 3416
# of Chips 4
# of Cores 24
# of Cores/Chip 6
HW Threading Enabled? Yes
Procs Avail to Java 96
Memory (MB) 262144
Memory Details 16 x 16 GB DDR3 1066 MHz
Primary cache 32 KBI + 32 KBD on chip per core
Secondary cache 256 KB I+D on chip per core
Other cache 10 MB I+D on chip per core
Filesystem AIX/JFS2
Disks 1 x 300 GB SFF-1 SSD
Other hardware IBM Flex System Enterprise Chassis 7893-92X
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version JRE 1.7.0 (32-bit) IBM J9 2.6 AIX [build pap3270sr3-20120319_01(SR3)]
JVM Command Line execrset -c processor_set_number -e java -Xlp -Xgcpolicy:gencon -Xms2560m -Xmx2560m -Xmn2048m -Xaggressive -XtlhPrefetch -XlockReservation -Xgcthreads4 spec.jbb.JBBmain -propfile SPECjbb.props
JVM Initial Heap Memory (MB) 2560
JVM Maximum Heap Memory (MB) 2560
JVM Address bits 32
JVM CLASSPATH jbb.jar:
check.jar
JVM BOOTCLASSPATH /speclocal/sdk/jre/lib/ppc/default/jclSC170/vm.jar:
/speclocal/sdk/jre/lib/se-service.jar:
/speclocal/sdk/jre/lib/math.jar:
/speclocal/sdk/jre/lib/jlm.jar:
/speclocal/sdk/jre/lib/ibmorb.jar:
/speclocal/sdk/jre/lib/ibmorbapi.jar:
/speclocal/sdk/jre/lib/ibmcfw.jar:
/speclocal/sdk/jre/lib/ibmpkcs.jar:
/speclocal/sdk/jre/lib/ibmcertpathfw.jar:
/speclocal/sdk/jre/lib/ibmjgssfw.jar:
/speclocal/sdk/jre/lib/ibmjssefw.jar:
/speclocal/sdk/jre/lib/ibmsaslfw.jar:
/speclocal/sdk/jre/lib/ibmjcefw.jar:
/speclocal/sdk/jre/lib/ibmjgssprovider.jar:
/speclocal/sdk/jre/lib/ibmjsseprovider2.jar:
/speclocal/sdk/jre/lib/ibmcertpathprovider.jar:
/speclocal/sdk/jre/lib/xmldsigfw.jar:
/speclocal/sdk/jre/lib/xml.jar:
/speclocal/sdk/jre/lib/charsets.jar:
/speclocal/sdk/jre/lib/resources.jar:
/speclocal/sdk/jre/lib/rt.jar
OS Version IBM AIX V7.1 TL2 SP3
Other software
Test Information
Tested by IBM Corporation
SPEC license # 11
Test location Austin, TX
Test date Jun 27, 2013
H/w available Aug-2013
JVM available Nov-2012
OS available Aug-2013
Other s/w available
AOT Compilation

Tuning
Operating system tunings
  • dscrctl -n -s 1
  • MEMORY_AFFINITY=MCM
  • The "Dynamic Power Saver - Favor Performance" mode was enabled on "IBM Advanced System Management"
Notes
  • 9600 16 MB large pages defined with vmo command
  • 24 JVMs were run in processor sets each containing 1 core
  • This Compute Node is housed in an "IBM Flex System Enterprise Chassis" and is the only Compute Node

JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 27184
2 69465
3 90640
4 109367 *
5 106450 *
6 104541 *
7 100739 *
8 98529 *
SPECjbb2005 (from 4 to 8) 103925 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25157
2 67257
3 90885
4 109936 *
5 106778 *
6 104852 *
7 101275 *
8 98604 *
SPECjbb2005 (from 4 to 8) 104289 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 22906
2 66266
3 89619
4 108644 *
5 105814 *
6 103945 *
7 100214 *
8 97251 *
SPECjbb2005 (from 4 to 8) 103173 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 24167
2 66685
3 89976
4 109217 *
5 106169 *
6 104297 *
7 100557 *
8 97872 *
SPECjbb2005 (from 4 to 8) 103622 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 24532
2 66447
3 88026
4 109289 *
5 107218 *
6 105314 *
7 101055 *
8 98682 *
SPECjbb2005 (from 4 to 8) 104311 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25755
2 65410
3 89266
4 108811 *
5 105686 *
6 103487 *
7 100213 *
8 97819 *
SPECjbb2005 (from 4 to 8) 103203 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25232
2 63533
3 86887
4 108553 *
5 105062 *
6 103328 *
7 99904 *
8 96581 *
SPECjbb2005 (from 4 to 8) 102685 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25412
2 63926
3 89210
4 109680 *
5 106643 *
6 105060 *
7 101686 *
8 98899 *
SPECjbb2005 (from 4 to 8) 104393 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 23201
2 67983
3 90134
4 110704 *
5 107209 *
6 105293 *
7 101792 *
8 99585 *
SPECjbb2005 (from 4 to 8) 104917 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25670
2 67974
3 89928
4 110236 *
5 107258 *
6 105146 *
7 101417 *
8 98703 *
SPECjbb2005 (from 4 to 8) 104552 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 24287
2 65055
3 90779
4 111266 *
5 107911 *
6 105910 *
7 102198 *
8 99586 *
SPECjbb2005 (from 4 to 8) 105374 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 23256
2 66910
3 89421
4 108486 *
5 105715 *
6 103987 *
7 100378 *
8 98118 *
SPECjbb2005 (from 4 to 8) 103337 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 26096
2 69278
3 89356
4 108419 *
5 105051 *
6 103208 *
7 99634 *
8 97136 *
SPECjbb2005 (from 4 to 8) 102690 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 27698
2 69759
3 90006
4 109317 *
5 106233 *
6 104542 *
7 100573 *
8 98423 *
SPECjbb2005 (from 4 to 8) 103818 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25594
2 67654
3 89383
4 109420 *
5 105967 *
6 104183 *
7 100451 *
8 97978 *
SPECjbb2005 (from 4 to 8) 103600 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 26819
2 69172
3 91052
4 111300 *
5 107852 *
6 106393 *
7 102553 *
8 99843 *
SPECjbb2005 (from 4 to 8) 105588 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 17 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25225
2 63851
3 88188
4 108159 *
5 104639 *
6 103221 *
7 98910 *
8 97427 *
SPECjbb2005 (from 4 to 8) 102471 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 18 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 24428
2 63158
3 89863
4 108863 *
5 106136 *
6 104297 *
7 100881 *
8 97933 *
SPECjbb2005 (from 4 to 8) 103622 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 19 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 23524
2 68299
3 90777
4 110399 *
5 107561 *
6 106112 *
7 102233 *
8 99523 *
SPECjbb2005 (from 4 to 8) 105166 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 20 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 24570
2 69290
3 91512
4 110682 *
5 107633 *
6 105266 *
7 101937 *
8 98912 *
SPECjbb2005 (from 4 to 8) 104886 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 21 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25236
2 67760
3 89704
4 109959 *
5 106468 *
6 104573 *
7 100933 *
8 98415 *
SPECjbb2005 (from 4 to 8) 104070 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 22 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 24702
2 67196
3 89351
4 109407 *
5 106362 *
6 104552 *
7 100618 *
8 98235 *
SPECjbb2005 (from 4 to 8) 103835 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 23 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 25531
2 64638
3 87184
4 109853 *
5 106744 *
6 104981 *
7 101581 *
8 98543 *
SPECjbb2005 (from 4 to 8) 104340 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013

JVM 24 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 23472
2 68508
3 89788
4 109901 *
5 106481 *
6 104556 *
7 100576 *
8 98003 *
SPECjbb2005 (from 4 to 8) 103903 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jun 27, 2013
SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 21-Aug-2013
