SPECjbb2005 SPECjbb2005 bops = 2811958, SPECjbb2005 bops/JVM = 175747
Cisco Systems Cisco UCS B420 M3 (Intel Xeon E5-4650, 2.7GHz)
IBM IBM J9 JVM (build 2.6, JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120322_106209 (JIT enabled, AOT enabled)

JVM run JVM Scores
1175367
2177800
3175498
4176531
5175080
6176086
7177357
8176246
9173613
10174470
11176612
12176982
13174682
14173805
15175429
16176400
SPECjbb2005 bops = 2811958, SPECjbb2005 bops/JVM = 175747

Hardware
Hardware Vendor Cisco Systems
Vendor URL http://www.cisco.com
Model Cisco UCS B420 M3 (Intel Xeon E5-4650, 2.7GHz)
Processor Intel Xeon E5-4650 (Intel Turbo Boost Technology upto 3.3 GHz)
MHz 2700
# of Chips 4
# of Cores 32
# of Cores/Chip 8
HW Threading Enabled? yes
Procs Avail to Java 64
Memory (MB) 262144
Memory Details 256GB (32 x 8GB PC3-12800R, ECC, running 1600MHz, memory slots polulated - A0,A1,B0,B1,C0,C1,D0,D1,E0,E1,F0,F1,G0,G1,H0,H1,I0,I1,J0,J1,K0,K1,L0,L1,M0,M1,N0,N1,O0,O1,P0,P1)
Primary cache 32KB I+32KB D on chip per core
Secondary cache 256KB(I+D) on chip per core
Other cache 20MB (I+D) on chip per chip
Filesystem NTFS
Disks 2 x 300GB SAS
Other hardware Cisco UCS 6248UP 48 Port Fabric Interconnect, Cisco UCS 5100 Series Blade Server Chassis, Cisco UCS 2208XP Fabric Extender
Software
Software Vendor IBM
Vendor URL http://www.IBM.com
JVM Version IBM J9 JVM (build 2.6, JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120322_106209 (JIT enabled, AOT enabled)
JVM Command Line start /AFFINITY %HEX% java -Xaggressive -Xcompressedrefs -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -Xconcurrentlevel0 spec.jbb.JBBmain -propfile SPECjbb.prop
JVM Initial Heap Memory (MB) 1875
JVM Maximum Heap Memory (MB) 1875
JVM Address bits 64
JVM CLASSPATH .\jbb.jar;
.\check.jar;
JVM BOOTCLASSPATH c:\IBM\java70\jre\lib\aggressive.jar;
c:\IBM\java70\jre\bin\compressedrefs\jclSC170\vm.jar;
c:\IBM\java70\jre\lib\se-service.jar;
c:\IBM\java70\jre\lib\math.jar;
c:\IBM\java70\jre\lib\jlm.jar;
c:\IBM\java70\jre\lib\ibmorb.jar;
c:\IBM\java70\jre\lib\ibmorbapi.jar;
c:\IBM\java70\jre\lib\ibmcfw.jar;
c:\IBM\java70\jre\lib\ibmpkcs.jar;
c:\IBM\java70\jre\lib\ibmcertpathfw.jar;
c:\IBM\java70\jre\lib\ibmjgssfw.jar;
c:\IBM\java70\jre\lib\ibmjssefw.jar;
c:\IBM\java70\jre\lib\ibmsaslfw.jar;
c:\IBM\java70\jre\lib\ibmjcefw.jar;
c:\IBM\java70\jre\lib\ibmjgssprovider.jar;
c:\IBM\java70\jre\lib\ibmjsseprovider2.jar;
c:\IBM\java70\jre\lib\ibmcertpathprovider.jar;
c:\IBM\java70\jre\lib\xmldsigfw.jar;
c:\IBM\java70\jre\lib\xml.jar;
c:\IBM\java70\jre\lib\charsets.jar;
c:\IBM\java70\jre\lib\resources.jar;
c:\IBM\java70\jre\lib\rt.jar
OS Version Microsoft Windows Server 2008 R2 Enterprise Edition SP1
Other software
Test Information
Tested by Cisco Systems
SPEC license # 9019
Test location San Jose, CA
Test date Oct 25, 2012
H/w available August-2012
JVM available June-2012
OS available Feb-2011
Other s/w available N/A
AOT Compilation

Tuning
Operating system tunings
  • "Lock pages in memory" enabled for benchmark user.
  • Hardware Prefetcher disabled in BIOS
  • Adjacent Cache Line Prefetch disabled in BIOS
  • Affinity Masks set to 0xF, 0xF0, 0xF00, 0xF000, 0xF0000, 0xF00000, 0xF000000, 0xF0000000, 0xF00000000, 0xF000000000, 0xF0000000000, 0xF00000000000, 0xF000000000000, 0xF0000000000000, 0xF00000000000000, 0xF000000000000000
Notes


JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 53582
2 142451
3 165247
4 177524 *
5 177384 *
6 174591 *
7 174158 *
8 173180 *
SPECjbb2005 (from 4 to 8) 175367 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 56243
2 144610
3 165020
4 180718 *
5 179066 *
6 177403 *
7 176327 *
8 175486 *
SPECjbb2005 (from 4 to 8) 177800 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 57640
2 142666
3 163776
4 178418 *
5 176668 *
6 174930 *
7 174512 *
8 172962 *
SPECjbb2005 (from 4 to 8) 175498 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 53380
2 134394
3 162284
4 178321 *
5 177446 *
6 176596 *
7 176013 *
8 174279 *
SPECjbb2005 (from 4 to 8) 176531 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 54070
2 144586
3 161806
4 177471 *
5 176123 *
6 174499 *
7 173951 *
8 173356 *
SPECjbb2005 (from 4 to 8) 175080 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 54816
2 140980
3 165154
4 178459 *
5 176616 *
6 175622 *
7 174771 *
8 174964 *
SPECjbb2005 (from 4 to 8) 176086 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 56185
2 137698
3 165651
4 179748 *
5 177907 *
6 177473 *
7 176161 *
8 175499 *
SPECjbb2005 (from 4 to 8) 177357 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 52530
2 141096
3 167647
4 179034 *
5 177846 *
6 176036 *
7 174581 *
8 173734 *
SPECjbb2005 (from 4 to 8) 176246 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 54617
2 145097
3 160389
4 175651 *
5 174786 *
6 173583 *
7 171647 *
8 172397 *
SPECjbb2005 (from 4 to 8) 173613 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 55099
2 143947
3 163192
4 176148 *
5 175972 *
6 173092 *
7 173924 *
8 173215 *
SPECjbb2005 (from 4 to 8) 174470 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 54745
2 140844
3 165980
4 179016 *
5 177929 *
6 176982 *
7 175546 *
8 173586 *
SPECjbb2005 (from 4 to 8) 176612 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 50189
2 134322
3 153080
4 178590 *
5 178644 *
6 176516 *
7 176336 *
8 174825 *
SPECjbb2005 (from 4 to 8) 176982 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 51485
2 137732
3 156525
4 176710 *
5 175506 *
6 175064 *
7 174063 *
8 172066 *
SPECjbb2005 (from 4 to 8) 174682 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 54710
2 136266
3 160592
4 176849 *
5 174998 *
6 173386 *
7 171838 *
8 171953 *
SPECjbb2005 (from 4 to 8) 173805 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 58848
2 143017
3 161495
4 178152 *
5 177089 *
6 174469 *
7 173957 *
8 173476 *
SPECjbb2005 (from 4 to 8) 175429 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012

JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 53813
2 145390
3 166155
4 178673 *
5 178252 *
6 176355 *
7 175662 *
8 173059 *
SPECjbb2005 (from 4 to 8) 176400 SPECjbb2005 bops
SPEC license # 9019 Tested by: Cisco Systems Test date: Oct 25, 2012
SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 15-Nov-2012
