Hardware |
Hardware Vendor |
Fujitsu |
Vendor URL |
http://www.fujitsu.com |
Model |
PRIMERGY RX500 S7, Intel Xeon E5-4650, 2.70 GHz |
Processor |
Intel Xeon E5-4650 (Intel Turbo Boost Technology up to 3.30 GHz) |
MHz |
2700 |
# of Chips |
4 |
# of Cores |
32 |
# of Cores/Chip |
8 |
HW Threading Enabled? |
Yes |
Procs Avail to Java |
64 |
Memory (MB) |
262144 |
Memory Details |
32 x 8 GB PC3L-12800R-11, ECC; slots 1A-1P, 2A-2P populated |
Primary cache |
32KB(I) + 32KB(D) on chip, per core |
Secondary cache |
256KB(I+D) on chip, per core |
Other cache |
20MB(I+D) on chip, per chip |
Filesystem |
NTFS |
Disks |
1 x Fujitsu S26361-F4482-E130 (2.5", SAS, 300GB, HDD) |
Other hardware |
N/A |
|
Software |
Software Vendor |
Oracle Corporation |
Vendor URL |
http://www.oracle.com |
JVM Version |
Oracle Java HotSpot(TM) 64-Bit Server VM on Windows, version 1.6.0_30 |
JVM Command Line |
start /HIGH /NODE [0,1,2,3] /AFFINITY [0xFFFF] /B java -server -Xmx29g -Xms29g -Xmn24g -XX:BiasedLockingStartupDelay=200 -XX:ParallelGCThreads=16 -XX:SurvivorRatio=60 -XX:TargetSurvivorRatio=90 -XX:InlineSmallCode=3900 -XX:MaxInlineSize=270 -XX:FreqInlineSize=2500 -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=4 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:LoopUnrollLimit=45 -XX:+UseCompressedStrings -XX:+AggressiveOpts -XX:+UseLargePages -XX:+UseParallelOldGC -XX:-UseAdaptiveSizePolicy |
JVM Initial Heap Memory (MB) |
29696 |
JVM Maximum Heap Memory (MB) |
29696 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\Program Files\Java\jdk1.6.0_30\jre\lib\alt-string.jar; C:\Program Files\Java\jdk1.6.0_30\jre\lib\alt-rt.jar; C:\Program Files\Java\jdk1.6.0_30\jre\lib\resources.jar; C:\Program Files\Java\jdk1.6.0_30\jre\lib\rt.jar; C:\Program Files\Java\jdk1.6.0_30\jre\lib\sunrsasign.jar; C:\Program Files\Java\jdk1.6.0_30\jre\lib\jsse.jar; C:\Program Files\Java\jdk1.6.0_30\jre\lib\jce.jar; C:\Program Files\Java\jdk1.6.0_30\jre\lib\charsets.jar; C:\Program Files\Java\jdk1.6.0_30\jre\lib\modules\jdk.boot.jar; C:\Program Files\Java\jdk1.6.0_30\jre\classes |
OS Version |
Microsoft Windows Server 2008 R2 Enterprise SP1 |
Other software |
N/A |
|
Test Information |
Tested by |
Fujitsu |
SPEC license # |
19 |
Test location |
Paderborn, Germany |
Test date |
Jun 17, 2012 |
H/w available |
Jul-2012 |
JVM available |
Dec-2011 |
OS available |
Feb-2011 |
Other s/w available |
N/A |
|
Tuning |
- Set "Hardware Prefetch=Disable" in BIOS.
- Set "Adjacent Sector Prefetch=Disable" in BIOS.
- Set "DCU Streamer Prefetch=Disable" in BIOS.
|
Notes |
- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
- input.expected_peak_warehouse was set to 16 due to a known inconsistency in processor reporting with the JVM used.
|
|
