Hardware |
Hardware Vendor |
Hewlett-Packard Company |
Vendor URL |
http://www.hp.com |
Model |
ProLiant DL580 G7 |
Processor |
Intel Xeon X7560 2.27 GHz (Intel Turbo Boost Technology up to 2.67 GHz) |
MHz |
2267 |
# of Chips |
2 |
# of Cores |
16 |
# of Cores/Chip |
8 |
HW Threading Enabled? |
Yes |
Procs Avail to Java |
32 |
Memory (MB) |
65536 |
Memory Details |
32 x 2 GB PC3-10600R CL9 |
Primary cache |
32 KB I + 32 KB D on chip, per core |
Secondary cache |
256 KB I+D on chip, per core |
Other cache |
24 MB I+D on chip, per chip |
Filesystem |
NTFS |
Disks |
1 x 146 GB 15 K SAS |
Other hardware |
|
|
Software |
Software Vendor |
IBM Corporation |
Vendor URL |
http://www.ibm.com |
JVM Version |
IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090519_35743 (JIT enabled, AOT enabled) |
JVM Command Line |
java -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -spec.jbb.JBBmain -propfile SPECjbb.V1.props |
JVM Initial Heap Memory (MB) |
1875 |
JVM Maximum Heap Memory (MB) |
1875 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
c:\java\ibm\jre\bin\compressedrefs\jclSC160\vm.jar; c:\java\ibm\jre\lib\annotation.jar; c:\java\ibm\jre\lib\beans.jar; c:\java\ibm\jre\lib\java.util.jar; c:\java\ibm\jre\lib\jndi.jar; c:\java\ibm\jre\lib\logging.jar; c:\java\ibm\jre\lib\security.jar; c:\java\ibm\jre\lib\sql.jar; c:\java\ibm\jre\lib\ibmorb.jar; c:\java\ibm\jre\lib\ibmorbapi.jar; c:\java\ibm\jre\lib\ibmcfw.jar; c:\java\ibm\jre\lib\rt.jar; c:\java\ibm\jre\lib\charsets.jar; c:\java\ibm\jre\lib\resources.jar; c:\java\ibm\jre\lib\ibmpkcs.jar; c:\java\ibm\jre\lib\ibmcertpathfw.jar; c:\java\ibm\jre\lib\ibmjgssfw.jar; c:\java\ibm\jre\lib\ibmjssefw.jar; c:\java\ibm\jre\lib\ibmsaslfw.jar; c:\java\ibm\jre\lib\ibmjcefw.jar; c:\java\ibm\jre\lib\ibmjgssprovider.jar; c:\java\ibm\jre\lib\ibmjsseprovider2.jar; c:\java\ibm\jre\lib\ibmcertpathprovider.jar; c:\java\ibm\jre\lib\ibmxmlcrypto.jar; c:\java\ibm\jre\lib\management-agent.jar; c:\java\ibm\jre\lib\xml.jar; c:\java\ibm\jre\lib\jlm.jar; c:\java\ibm\jre\lib\javascript.jar |
OS Version |
Microsoft Windows Server 2008 Enterprise x64 Edition with R2 |
Other software |
|
|
Test Information |
Tested by |
Hewlett-Packard Company |
SPEC license # |
3 |
Test location |
Houston, TX |
Test date |
May 12, 2010 |
H/w available |
Mar-2010 |
JVM available |
Jul-2009 |
OS available |
Nov-2009 |
Other s/w available |
|
|
Tuning |
"Lock pages in memory" enabled for benchmark user. Power Option Set to High Performance Used start /AFFINITY 0xFF 0xFF00 0xFF0000 0xFF000000 0xFF00000000 0xFF0000000000 0xFF000000000000 0xFF00000000000000 was used to bind physical CPU nodes |
Notes |
Command line options are described at: http://publib.boulder.ibm.com/infocenter/javasdk/v6r0/index.jsp BIOS Configuration- Power Regulator set to Static High
- Node Interleaving Disabled
- Hardware Prefetcher Disabled
- Adjacent Sector Prefetcher Disabled
|
|
