SPECjbb2005 SPECjbb2005 bops = 2012730, SPECjbb2005 bops/JVM = 125796
IBM Corporation IBM System x3850 X5
IBM Corporation IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090519_35743 (JIT enabled, AOT enabled)

JVM run JVM Scores
1125961
2125544
3126019
4125099
5125009
6126204
7126829
8125845
9125684
10126234
11124816
12125341
13124179
14126091
15127361
16126514
SPECjbb2005 bops = 2012730, SPECjbb2005 bops/JVM = 125796

Hardware
Hardware Vendor IBM Corporation
Vendor URL http://www.ibm.com
Model IBM System x3850 X5
Processor Intel Xeon X7560 (Intel Turbo Boost Technology up to 2.666GHz)
MHz 2266
# of Chips 4
# of Cores 32
# of Cores/Chip 8
HW Threading Enabled? Yes
Procs Avail to Java 64
Memory (MB) 262144
Memory Details 64 x 4 GB 4Rx8 PC3-8500R, all slots on all memory cards populated
Primary cache 32KB I + 32KB D on chip per core
Secondary cache 256KB (I+D) on chip per core
Other cache 24MB (I+D) on chip per chip
Filesystem NTFS
Disks 1 x 73GB 15K rpm SAS
Other hardware
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090519_35743 (JIT enabled, AOT enabled)
JVM Command Line start /AFFINITY %HEX% java -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp spec.jbb.JBBmain -propfile SPECjbb.props
JVM Initial Heap Memory (MB) 1875
JVM Maximum Heap Memory (MB) 1875
JVM Address bits 64
JVM CLASSPATH .\jbb.jar;
.\check.jar;
JVM BOOTCLASSPATH C:\Program Files\IBM\Java60\jre\bin\compressedrefs\jclSC160\vm.jar;
C:\Program Files\IBM\Java60\jre\lib\annotation.jar;
C:\Program Files\IBM\Java60\jre\lib\beans.jar;
C:\Program Files\IBM\Java60\jre\lib\java.util.jar;
C:\Program Files\IBM\Java60\jre\lib\jndi.jar;
C:\Program Files\IBM\Java60\jre\lib\logging.jar;
C:\Program Files\IBM\Java60\jre\lib\security.jar;
C:\Program Files\IBM\Java60\jre\lib\sql.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmorb.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmorbapi.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmcfw.jar;
C:\Program Files\IBM\Java60\jre\lib\rt.jar;
C:\Program Files\IBM\Java60\jre\lib\charsets.jar;
C:\Program Files\IBM\Java60\jre\lib\resources.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmpkcs.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmcertpathfw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjgssfw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjssefw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmsaslfw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjcefw.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjgssprovider.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmjsseprovider2.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmcertpathprovider.jar;
C:\Program Files\IBM\Java60\jre\lib\ibmxmlcrypto.jar;
C:\Program Files\IBM\Java60\jre\lib\management-agent.jar;
C:\Program Files\IBM\Java60\jre\lib\xml.jar;
C:\Program Files\IBM\Java60\jre\lib\jlm.jar;
C:\Program Files\IBM\Java60\jre\lib\javascript.jar
OS Version Microsoft Windows Server 2008 R2 Enterprise x64
Other software
Test Information
Tested by IBM Corporation
SPEC license # 11
Test location RTP, NC
Test date Mar 11, 2010
H/w available Mar-2010
JVM available Jun-2009
OS available Oct-2009
Other s/w available
AOT Compilation

Tuning
Operating system tunings
  • Affinity Masks set to 0xf, 0xf0, 0xf00, 0xf000, 0xf0000, 0xf00000, 0xf000000, 0xf0000000, 0xf00000000, 0xf000000000, 0xf0000000000, 0xf00000000000, 0xf000000000000, 0xf0000000000000, 0xf00000000000000, 0xf000000000000000
  • Lock Pages in memory enabled under Local Security Policies
BIOS Settings
  • Operating Mode set to Custom Mode
  • Turbo Boost Power set to Traditional
  • Processor Data Prefetch set to Disable
  • Demand Scrub set to Disable
Notes



JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41491
2 96648
3 107762
4 126871 *
5 126766 *
6 126133 *
7 125774 *
8 124263 *
SPECjbb2005 (from 4 to 8) 125961 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41475
2 95984
3 108870
4 126733 *
5 126318 *
6 125806 *
7 125162 *
8 123698 *
SPECjbb2005 (from 4 to 8) 125544 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43812
2 96435
3 107690
4 127033 *
5 127204 *
6 125977 *
7 125529 *
8 124349 *
SPECjbb2005 (from 4 to 8) 126019 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40935
2 96738
3 107580
4 126870 *
5 125803 *
6 124680 *
7 124390 *
8 123750 *
SPECjbb2005 (from 4 to 8) 125099 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40938
2 94989
3 108024
4 126230 *
5 125658 *
6 125098 *
7 124143 *
8 123915 *
SPECjbb2005 (from 4 to 8) 125009 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41601
2 96184
3 111646
4 127159 *
5 127399 *
6 126181 *
7 125645 *
8 124634 *
SPECjbb2005 (from 4 to 8) 126204 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40995
2 95501
3 110040
4 127992 *
5 127308 *
6 126726 *
7 126348 *
8 125771 *
SPECjbb2005 (from 4 to 8) 126829 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41862
2 94335
3 111208
4 126546 *
5 127099 *
6 126485 *
7 125225 *
8 123872 *
SPECjbb2005 (from 4 to 8) 125845 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41713
2 96284
3 112265
4 127530 *
5 126834 *
6 124888 *
7 125007 *
8 124159 *
SPECjbb2005 (from 4 to 8) 125684 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 43905
2 96929
3 107821
4 127235 *
5 127132 *
6 126507 *
7 125296 *
8 124998 *
SPECjbb2005 (from 4 to 8) 126234 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41187
2 95528
3 111139
4 125872 *
5 125625 *
6 124741 *
7 124019 *
8 123824 *
SPECjbb2005 (from 4 to 8) 124816 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40585
2 95694
3 110045
4 126028 *
5 126008 *
6 125379 *
7 124907 *
8 124385 *
SPECjbb2005 (from 4 to 8) 125341 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40980
2 93861
3 109046
4 124544 *
5 124904 *
6 124536 *
7 123826 *
8 123086 *
SPECjbb2005 (from 4 to 8) 124179 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41326
2 96196
3 108564
4 127592 *
5 126997 *
6 125955 *
7 125331 *
8 124582 *
SPECjbb2005 (from 4 to 8) 126091 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41695
2 96216
3 107953
4 128033 *
5 128396 *
6 127532 *
7 126809 *
8 126037 *
SPECjbb2005 (from 4 to 8) 127361 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010


JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 41061
2 95345
3 108537
4 128254 *
5 126631 *
6 126449 *
7 126089 *
8 125147 *
SPECjbb2005 (from 4 to 8) 126514 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Mar 11, 2010

SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 27-Apr-2010
