Hardware |
|---|
| Hardware Vendor |
Huawei Technologies Co., Ltd. |
| Vendor URL |
http://www.huawei.com |
| Model |
Tecal RH2285 |
| Processor |
Intel Xeon processor X5570 (Intel Turbo Boost Technology up to 3.33 GHz) |
| MHz |
2930 |
| # of Chips |
2 |
| # of Cores |
8 |
| # of Cores/Chip |
4 |
| HW Threading Enabled? |
Yes |
| Procs Avail to Java |
16 |
| Memory (MB) |
24576 |
| Memory Details |
6x4GB DDR3 1333 CL9 |
| Primary cache |
32KB(I) + 32KB(D) on chip, per core |
| Secondary cache |
256KB per core |
| Other cache |
8MB shared per 4 cores |
| Filesystem |
NTFS |
| Disks |
1 x 80GB SSD SATA |
| Other hardware |
none |
|
|
Software |
|---|
| Software Vendor |
IBM Corporation |
| Vendor URL |
http://www.ibm.com |
| JVM Version |
IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090519_35743 (JIT enabled, AOT enabled) |
| JVM Command Line |
start /affinity [000F, 00F0, 0F00, F000] Java -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -Xmn1200m -Xms1600m -Xmx1600m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -Xgcthreads4 |
| JVM Initial Heap Memory (MB) |
1600 |
| JVM Maximum Heap Memory (MB) |
1600 |
| JVM Address bits |
64 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar;
|
| JVM BOOTCLASSPATH |
C:\J9\bin\compressedrefs\jclSC160\vm.jar;
C:\J9\lib\annotation.jar;
C:\J9\lib\beans.jar;
C:\J9\lib\java.util.jar;
C:\J9\lib\jndi.jar;
C:\J9\lib\logging.jar;
C:\J9\lib\security.jar;
C:\J9\lib\sql.jar;
C:\J9\lib\ibmorb.jar;
C:\J9\lib\ibmorbapi.jar;
C:\J9\lib\ibmcfw.jar;
C:\J9\lib\rt.jar;
C:\J9\lib\charsets.jar;
C:\J9\lib\resources.jar;
C:\J9\lib\ibmpkcs.jar;
C:\J9\lib\ibmcertpathfw.jar;
C:\J9\lib\ibmjgssfw.jar;
C:\J9\lib\ibmjssefw.jar;
C:\J9\lib\ibmsaslfw.jar;
C:\J9\lib\ibmjcefw.jar;
C:\J9\lib\ibmjgssprovider.jar;
C:\J9\lib\ibmjsseprovider2.jar;
C:\J9\lib\ibmcertpathprovider.jar;
C:\J9\lib\ibmxmlcrypto.jar;
C:\J9\lib\management-agent.jar;
C:\J9\lib\xml.jar;
C:\J9\lib\jlm.jar;
C:\J9\lib\javascript.jar |
| OS Version |
Microsoft Windows Server 2008 Enterprise x64 Edition + SP1 (64-bit) |
| Other software |
none |
|
|
Test Information |
|---|
| Tested by |
Huawei |
| SPEC license # |
3175 |
| Test location |
Shenzhen, PRC |
| Test date |
Dec 15, 2009 |
| H/w available |
Aug-2009 |
| JVM available |
Jul-2009 |
| OS available |
May-2008 |
| Other s/w available |
n/a |
|
|
Tuning |
|---|
| Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark. |
|
Notes |
|---|
BIOS Configuration- HW Prefetcher Disabled
- Cache Line Prefetcher Disabled
|
|
