Hardware |
Hardware Vendor |
Fujitsu |
Vendor URL |
http://www.fujitsu.com |
Model |
PRIMERGY TX300 S5, Intel Xeon W5590, 3.33 GHz |
Processor |
Intel Xeon W5590 (Intel Turbo Boost Technology up to 3.60 GHz) |
MHz |
3333 |
# of Chips |
2 |
# of Cores |
8 |
# of Cores/Chip |
4 |
HW Threading Enabled? |
Yes |
Procs Avail to Java |
16 |
Memory (MB) |
49152 |
Memory Details |
12x4GB PC3-10600R (CAS 9-9-9) |
Primary cache |
32KB(I) + 32KB(D) on chip, per core |
Secondary cache |
256KB(I+D) on chip, per core |
Other cache |
8MB(I+D) on chip, per chip |
Filesystem |
NTFS |
Disks |
Fujitsu (2.5", SAS, 73GB, 10krpm) |
Other hardware |
N/A |
|
Software |
Software Vendor |
Oracle Corporation |
Vendor URL |
http://www.oracle.com |
JVM Version |
Oracle JRockit(R) 6 P28.0.0 (build P28.0.0-29-114096-1.6.0_11-20090427-1759-windows-x86_64) |
JVM Command Line |
start /HIGH /AFFINITY [0x000F,0x00F0,0x0F00,0xF000] /B java -Xms3900m -Xmx3900m -Xns3300m -XXaggressive -Xlargepages -Xgc:genpar -XXcallprofiling -XXgcthreads=4 -XXtlasize:min=4k,preferred=1024k spec.jbb.JBBmain -propfile SPECjbb.props |
JVM Initial Heap Memory (MB) |
3900 |
JVM Maximum Heap Memory (MB) |
3900 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\bin\jrockit\jrockit1.6.0.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\bin\jrockit\jmapi.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\bin\jrockit\jmxmapi.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\bin\jrockit\rmp.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\bin\jrockit\latency.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\lib\resources.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\lib\rt.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\lib\sunrsasign.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\lib\jsse.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\lib\jce.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\lib\charsets.jar; C:\Program Files\Java\jrockit-jdk1.6.0_11\jre\classes |
OS Version |
Microsoft Windows Server 2008 Enterprise x64 Edition + SP2 |
Other software |
N/A |
|
Test Information |
Tested by |
Fujitsu |
SPEC license # |
19 |
Test location |
Paderborn, Germany |
Test date |
Aug 7, 2009 |
H/w available |
Oct-2009 |
JVM available |
May-2009 |
OS available |
May-2009 |
Other s/w available |
N/A |
|
Tuning |
- Turned off "Hardware Prefetch" in BIOS.
- Turned off "Adjacent Sector Prefetch" in BIOS.
- Set "Memory Speed" to Max Performance in BIOS.
- Each JVM instance was affinitized to 2 cores of a socket.
- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
|
|
