Hardware |
Hardware Vendor |
Hewlett-Packard Company |
Vendor URL |
http://www.hp.com |
Model |
ProLiant BL685c G6 |
Processor |
AMD Opteron 8435 |
MHz |
2600 |
# of Chips |
4 |
# of Cores |
24 |
# of Cores/Chip |
6 |
HW Threading Enabled? |
No |
Procs Avail to Java |
24 |
Memory (MB) |
65536 |
Memory Details |
16 x 4 GB PC2-6400P CL5 |
Primary cache |
64 KB I + 64 KB D on chip, per core |
Secondary cache |
512 KB I+D on chip, per core |
Other cache |
6 MB I+D on chip, per chip |
Filesystem |
NTFS |
Disks |
1 x 146 GB 10 K SAS |
Other hardware |
|
|
Software |
Software Vendor |
Oracle Corporation |
Vendor URL |
http://www.oracle.com |
JVM Version |
Oracle JRockit(R) (build P28.0.0-29-114096-1.6.0_11-20090427-1759-windows-x86_64, compiled mode) |
JVM Command Line |
java -Xms3900m -Xmx3900m -Xns3300m -XXaggressive -XlargePages -XXcallprofiling -XXsetGC:genparcon -XXgcthreads:6 -XXtlasize:min=8k,preferred=512k -spec.jbb.JBBmain -propfile SPECjbb.V1.props |
JVM Initial Heap Memory (MB) |
3900 |
JVM Maximum Heap Memory (MB) |
3900 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\Program Files\java\jrockit-jdk1.6.0_11\jre\bin\jrockit\jrockit1.6.0.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\bin\jrockit\jmapi.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\bin\jrockit\jmxmapi.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\bin\jrockit\rmp.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\bin\jrockit\latency.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\lib\resources.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\lib\rt.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\lib\sunrsasign.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\lib\jsse.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\lib\jce.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\lib\charsets.jar; C:\Program Files\java\jrockit-jdk1.6.0_11\jre\classes |
OS Version |
Microsoft Windows Server 2008 Enterprise x64 Edition with SP2 |
Other software |
|
|
Test Information |
Tested by |
Hewlett-Packard Company |
SPEC license # |
3 |
Test location |
Houston, TX |
Test date |
Jul 6, 2009 |
H/w available |
Jun-2009 |
JVM available |
Jun-2009 |
OS available |
May-2009 |
Other s/w available |
|
|
Tuning |
"Lock pages in memory" enabled for benchmark user. Power Option Set to High Performance Used Affinity to bind each JVM to the cores of a single physical processor. |
Notes |
Command line options are described at: http://download.oracle.com/docs/cd/E13150_01/jrockit_jvm/jrockit/jrdocs/refman/intro.html BIOS Configuration- Power Regulator set to Static High
- Node Interleaving Disabled
- Independent Memory Channel Mode
- DRAM Prefetcher Disabled
- Hardware Prefetch Disabled
- Hardware Prefetch training on Software Prefetch set to Disabled
|
|
