Hardware |
|---|
| Hardware Vendor |
Fujitsu |
| Vendor URL |
http://www.fujitsu.com |
| Model |
PRIMERGY BX920 S1, Intel Xeon X5570, 2.93 GHz |
| Processor |
Intel Xeon X5570 (Intel Turbo Boost Technology up to 3.33 GHz) |
| MHz |
2933 |
| # of Chips |
2 |
| # of Cores |
8 |
| # of Cores/Chip |
4 |
| HW Threading Enabled? |
Yes |
| Procs Avail to Java |
16 |
| Memory (MB) |
24576 |
| Memory Details |
6x4GB PC3-10600R (CAS 9-9-9) |
| Primary cache |
32KB(I) + 32KB(D) on chip, per core |
| Secondary cache |
256KB(I+D) on chip, per core |
| Other cache |
8MB(I+D) on chip, per chip |
| Filesystem |
NTFS |
| Disks |
Seagate (2.5", SAS, 73GB, 10krpm) |
| Other hardware |
N/A |
|
|
Software |
|---|
| Software Vendor |
Oracle Corporation |
| Vendor URL |
http://www.oracle.com |
| JVM Version |
Oracle JRockit(R) 6 P28.0.0 (build P28.0.0-29-114096-1.6.0_11-20090427-1759-windows-x86_64) |
| JVM Command Line |
start /HIGH /AFFINITY [0x00FF,0xFF00] /B java -Xms3900m -Xmx3900m -Xns3300m -XXaggressive -Xlargepages -Xgc:genpar -XXcallprofiling -XXgcthreads=8 -XXtlasize:min=4k,preferred=1024k spec.jbb.JBBmain -propfile SPECjbb.props |
| JVM Initial Heap Memory (MB) |
3900 |
| JVM Maximum Heap Memory (MB) |
3900 |
| JVM Address bits |
64 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar;
|
| JVM BOOTCLASSPATH |
C:\JVM\jrockit-jdk1.6.0_11\jre\bin\jrockit\jrockit1.6.0.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\bin\jrockit\jmapi.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\bin\jrockit\jmxmapi.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\bin\jrockit\rmp.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\bin\jrockit\latency.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\lib\resources.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\lib\rt.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\lib\sunrsasign.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\lib\jsse.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\lib\jce.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\lib\charsets.jar;
C:\JVM\jrockit-jdk1.6.0_11\jre\classes |
| OS Version |
Microsoft Windows Server 2008 Enterprise x64 Edition + SP2 |
| Other software |
N/A |
|
|
Test Information |
|---|
| Tested by |
Fujitsu |
| SPEC license # |
19 |
| Test location |
Paderborn, Germany |
| Test date |
May 1, 2009 |
| H/w available |
May-2009 |
| JVM available |
May-2009 |
| OS available |
May-2009 |
| Other s/w available |
N/A |
|
|
Tuning |
|---|
- Turned off "Hardware Prefetch" in BIOS.
- Turned off "Adjacent Sector Prefetch" in BIOS.
- Each JVM instance was affinitized to a socket.
- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
|
|
