Hardware |
Hardware Vendor |
IBM Corporation |
Vendor URL |
http://www.ibm.com |
Model |
IBM System x3650 M2 |
Processor |
Intel Xeon X5570 (Intel Turbo Boost Technology up to 3.33 GHz) |
MHz |
2933 |
# of Chips |
2 |
# of Cores |
8 |
# of Cores/Chip |
4 |
HW Threading Enabled? |
Yes |
Procs Avail to Java |
16 |
Memory (MB) |
12288 |
Memory Details |
6 x PC3-10600R populated in slots 3, 6, 8, 11, 14 and 16 |
Primary cache |
32KB I + 32KB D on chip per core |
Secondary cache |
256KB I+D on chip per core |
Other cache |
8MB (I+D) on chip per chip |
Filesystem |
NTFS |
Disks |
1 x 32GB SSD SATA |
Other hardware |
None |
|
Software |
Software Vendor |
IBM Corporation |
Vendor URL |
http://www.ibm.com |
JVM Version |
IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr5-20090326_01(SR5) (JIT enabled, AOT enabled) |
JVM Command Line |
start /AFFINITY %HEX% java -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -Xmn1300m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -spec.jbb.JBBmain -propfile Test1 |
JVM Initial Heap Memory (MB) |
1875 |
JVM Maximum Heap Memory (MB) |
1875 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
c:\java6sr5_h\jre\lib\vm.jar; c:\java6sr5_h\jre\lib\annotation.jar; c:\java6sr5_h\jre\lib\beans.jar; c:\java6sr5_h\jre\lib\java.util.jar; c:\java6sr5_h\jre\lib\jndi.jar; c:\java6sr5_h\jre\lib\logging.jar; c:\java6sr5_h\jre\lib\security.jar; c:\java6sr5_h\jre\lib\sql.jar; c:\java6sr5_h\jre\lib\ibmorb.jar; c:\java6sr5_h\jre\lib\ibmorbapi.jar; c:\java6sr5_h\jre\lib\ibmcfw.jar; c:\java6sr5_h\jre\lib\rt.jar; c:\java6sr5_h\jre\lib\charsets.jar; c:\java6sr5_h\jre\lib\resources.jar; c:\java6sr5_h\jre\lib\ibmpkcs.jar; c:\java6sr5_h\jre\lib\ibmcertpathfw.jar; c:\java6sr5_h\jre\lib\ibmjgssfw.jar; c:\java6sr5_h\jre\lib\ibmjssefw.jar; c:\java6sr5_h\jre\lib\ibmsaslfw.jar; c:\java6sr5_h\jre\lib\ibmjcefw.jar; c:\java6sr5_h\jre\lib\ibmjgssprovider.jar; c:\java6sr5_h\jre\lib\ibmjsseprovider2.jar; c:\java6sr5_h\jre\lib\ibmcertpathprovider.jar; c:\java6sr5_h\jre\lib\ibmxmlcrypto.jar; c:\java6sr5_h\jre\lib\management-agent.jar; c:\java6sr5_h\jre\lib\xml.jar; c:\java6sr5_h\jre\lib\jlm.jar; c:\java6sr5_h\jre\lib\javascript.jar |
OS Version |
Microsoft Windows Server 2008 Enterprise Edition x64 SP1 |
Other software |
none |
|
Test Information |
Tested by |
IBM Corporation |
SPEC license # |
11 |
Test location |
RTP, NC |
Test date |
Mar 30, 2009 |
H/w available |
Jun-2009 |
JVM available |
Jun-2009 |
OS available |
Feb-2008 |
Other s/w available |
|
|
Tuning |
=- Affinity Masks set to 0xf000, 0x0f00, 0x00f0, 0x000f
- Lock Pages in memory enabled under Local Security Policies
- Processor Prefetches disabled in bios
- Processor C-States enabled in bios
|
|
