Hardware |
Hardware Vendor |
Fujitsu |
Vendor URL |
http://www.fujitsu.com |
Model |
PRIMERGY RX600 S4, Intel Xeon X7460, 2.66 GHz |
Processor |
Intel Xeon X7460 (2.66 GHz, 3x3MB L2, 1067 MHz system bus) |
MHz |
2667 |
# of Chips |
4 |
# of Cores |
24 |
# of Cores/Chip |
6 |
HW Threading Enabled? |
N/A |
Procs Avail to Java |
24 |
Memory (MB) |
65536 |
Memory Details |
16x4GB PC2-5300F (CAS 5-5-5) |
Primary cache |
32KB(I) + 32KB(D) on chip, per core |
Secondary cache |
9MB(I+D) on chip, per chip (3MB shared / 2 cores) |
Other cache |
16MB(I+D) on chip, per chip |
Filesystem |
NTFS |
Disks |
Seagate (2.5", SAS, 36GB, 10krpm) |
Other hardware |
N/A |
|
Software |
Software Vendor |
Oracle Corporation |
Vendor URL |
http://www.oracle.com |
JVM Version |
Oracle JRockit(R) 6 P28.0.0 (build P28.0.0-8-109238-1.6.0_05-20090130-1408-windows-x86_64) |
JVM Command Line |
start /AFFINITY [0x00003F,0x000FC0,0x03F000,0xFC0000] /B java -Xms3700m -Xmx3700m -Xns2800m -XXaggressive -Xlargepages -Xgc:genpar -XXcallprofiling -XXgcthreads=6 -XXtlasize:min=4k,preferred=1024k -XX:+UseStringCache spec.jbb.JBBmain -propfile SPECjbb.props |
JVM Initial Heap Memory (MB) |
3700 |
JVM Maximum Heap Memory (MB) |
3700 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\jrockit1.6.0.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\jmapi.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\jmxmapi.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\rmp.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\bin\jrockit\latency.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\resources.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\rt.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\sunrsasign.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\jsse.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\jce.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\lib\charsets.jar; C:\Program Files\Java\jrockit-jdk1.6.0_05\jre\classes |
OS Version |
Microsoft Windows Server 2003 R2 Enterprise x64 Edition |
Other software |
N/A |
|
Test Information |
Tested by |
Fujitsu Siemens Computers |
SPEC license # |
19 |
Test location |
Paderborn, Germany |
Test date |
Feb 6, 2009 |
H/w available |
Oct-2008 |
JVM available |
May-2009 |
OS available |
May-2005 |
Other s/w available |
N/A |
|
Tuning |
- Each JVM instance was affinitized to a socket.
- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
|
Notes |
The Fujitsu Siemens Computers PRIMERGY RX600 S4 and the Fujitsu PRIMERGY RX600 S4 are electronically equivalent. |
|
