Hardware |
Hardware Vendor |
Tyan |
Vendor URL |
http://www.tyan.com |
Model |
Transport TX46, AMD Opteron 8386 SE |
Processor |
AMD Opteron 8386 SE |
MHz |
2800 |
# of Chips |
4 |
# of Cores |
16 |
# of Cores/Chip |
4 |
HW Threading Enabled? |
No |
Procs Avail to Java |
16 |
Memory (MB) |
65536 |
Memory Details |
16 x 4GB DDR2-800 CL5 |
Primary cache |
64KBI+64KBD on chip per core |
Secondary cache |
512KB(I+D) on chip per core |
Other cache |
6MB on chip per chip |
Filesystem |
NTFS |
Disks |
1 x 250GB SATA |
Other hardware |
|
|
Software |
Software Vendor |
IBM |
Vendor URL |
http://www.ibm.com |
JVM Version |
IBM J9 VM (build 2.4, J2RE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460-20081105_25433 (JIT enabled, AOT enabled) |
JVM Command Line |
java /B /AFFINITY %CPUS% -Xcompressedrefs -Xlp -Xgcpolicy:gencon -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch |
JVM Initial Heap Memory (MB) |
1875 |
JVM Maximum Heap Memory (MB) |
1875 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\Program Files\IBM\WebSphere\AppServer1\java\jre\bin\compressedrefs\jclSC160\vm.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\annotation.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\beans.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\java.util.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\jndi.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\logging.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\security.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\sql.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmorb.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmorbapi.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmcfw.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\rt.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\charsets.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\resources.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmpkcs.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmcertpathfw.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmjgssfw.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmjssefw.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmsaslfw.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmjcefw.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmjgssprovider.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmjsseprovider2.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmcertpathprovider.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\ibmxmlcrypto.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\management-agent.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\xml.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\jlm.jar; C:\Program Files\IBM\WebSphere\AppServer1\java\jre\lib\javascript.jar |
OS Version |
Microsoft Windows Server 2008 Enterprise with SP1 (64-bit) |
Other software |
|
|
Test Information |
Tested by |
Advanced Micro Devices |
SPEC license # |
49 |
Test location |
Austin, TX |
Test date |
Dec 11, 2008 |
H/w available |
Jan-2009 |
JVM available |
Dec-2008 |
OS available |
Feb-2008 |
Other s/w available |
|
|
Tuning |
OS- The start command was used to affinitize each JVM to a socket.
- Using the Local Security Settings console, "lock pages in memory" was enabled for the user running the benchmark.
|
|
