Hardware |
Hardware Vendor |
IBM Corporation |
Vendor URL |
http://www.ibm.com |
Model |
IBM BladeCenter HS21 XM |
Processor |
Intel Xeon E5450 |
MHz |
3000 |
# of Chips |
2 |
# of Cores |
8 |
# of Cores/Chip |
4 |
HW Threading Enabled? |
No |
Procs Avail to Java |
8 |
Memory (MB) |
16384 |
Memory Details |
8 x 2GB PC2-5300F |
Primary cache |
32 KB I + 32 KB D |
Secondary cache |
12MB(I+D) on chip, 6MB per core pair |
Other cache |
None |
Filesystem |
NTFS |
Disks |
1 x 73GB SAS |
Other hardware |
None |
|
Software |
Software Vendor |
IBM Corporation |
Vendor URL |
http://www.ibm.com |
JVM Version |
IBM J9 2.4 JRE 1.6.0 (build pwa6460sr1-20080419_01(SR1)) |
JVM Command Line |
start /AFFINITY %HEX% java -Xcompressedrefs -Xlp -Xgcpolicy:gencon -Xmn1400m -Xms1875m -Xmx1875m -XlockReservation -Xnoloa -XtlhPrefetch |
JVM Initial Heap Memory (MB) |
1875 |
JVM Maximum Heap Memory (MB) |
1875 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\Program Files\IBM\Java60\jre\bin\compressedrefs\jclSC160\vm.jar; C:\Program Files\IBM\Java60\jre\lib\annotation.jar; C:\Program Files\IBM\Java60\jre\lib\beans.jar; C:\Program Files\IBM\Java60\jre\lib\java.util.jar; C:\Program Files\IBM\Java60\jre\lib\jndi.jar; C:\Program Files\IBM\Java60\jre\lib\logging.jar; C:\Program Files\IBM\Java60\jre\lib\security.jar; C:\Program Files\IBM\Java60\jre\lib\sql.jar; C:\Program Files\IBM\Java60\jre\lib\ibmorb.jar; C:\Program Files\IBM\Java60\jre\lib\ibmorbapi.jar; C:\Program Files\IBM\Java60\jre\lib\ibmcfw.jar; C:\Program Files\IBM\Java60\jre\lib\rt.jar; C:\Program Files\IBM\Java60\jre\lib\charsets.jar; C:\Program Files\IBM\Java60\jre\lib\resources.jar; C:\Program Files\IBM\Java60\jre\lib\ibmpkcs.jar; C:\Program Files\IBM\Java60\jre\lib\ibmcertpathfw.jar; C:\Program Files\IBM\Java60\jre\lib\ibmjgssfw.jar; C:\Program Files\IBM\Java60\jre\lib\ibmjssefw.jar; C:\Program Files\IBM\Java60\jre\lib\ibmsaslfw.jar; C:\Program Files\IBM\Java60\jre\lib\ibmjcefw.jar; C:\Program Files\IBM\Java60\jre\lib\ibmjgssprovider.jar; C:\Program Files\IBM\Java60\jre\lib\ibmjsseprovider2.jar; C:\Program Files\IBM\Java60\jre\lib\ibmcertpathprovider.jar; C:\Program Files\IBM\Java60\jre\lib\ibmxmlcrypto.jar; C:\Program Files\IBM\Java60\jre\lib\management-agent.jar; C:\Program Files\IBM\Java60\jre\lib\xml.jar; C:\Program Files\IBM\Java60\jre\lib\jlm.jar; C:\Program Files\IBM\Java60\jre\lib\javascript.jar |
OS Version |
Windows Server 2003 R2 Enterprise x64 Edition SP1 |
Other software |
None |
|
Test Information |
Tested by |
IBM Corporation |
SPEC license # |
11 |
Test location |
RTP, NC |
Test date |
May 22, 2008 |
H/w available |
Nov-2007 |
JVM available |
Jun-2008 |
OS available |
Dec-2007 |
Other s/w available |
|
|
Tuning |
Affinity Masks set to 0x03, 0x0C, 0x30, 0xC0Hardware Prefetch and Adjacent Sector Prefetch disabledLock Pages in memory enabled under Local Security Policies |
|
