Hardware |
Hardware Vendor |
Fujitsu Siemens Computers |
Vendor URL |
http://www.fujitsu-siemens.com |
Model |
PRIMERGY RX100 S5, Intel Xeon processor X3210, 2.13 GHz |
Processor |
Intel Xeon processor X3210 (2.13 GHz, 2x4MB L2, 1067 MHz system bus) |
MHz |
2133 |
# of Chips |
1 |
# of Cores |
4 |
# of Cores/Chip |
4 |
HW Threading Enabled? |
N/A |
Procs Avail to Java |
4 |
Memory (MB) |
8192 |
Memory Details |
4x2GB DDR2-RAM PC2-6400E (CAS 6-6-6) |
Primary cache |
32KB(I) + 32KB(D) on chip, per core |
Secondary cache |
8MB(I+D) on chip, per chip (4MB shared / 2 cores) |
Other cache |
N/A |
Filesystem |
NTFS |
Disks |
Seagtae ST373454SS (73 GB, SAS, 15.4 krpm) |
Other hardware |
N/A |
|
Software |
Software Vendor |
Bea Systems, Inc |
Vendor URL |
http://www.bea.com |
JVM Version |
BEA JRockit(R) 6.0 P27.4.0 (build P27.4.0-10-90053-1.6.0_02-20071009-1827-windows-x86_64) |
JVM Command Line |
start /AFFINITY %CPUs% /B java -Xms3500m -Xns2800m -Xmx3500m -Xlargepages -XXaggressive -XXthroughputcompaction -XXlazyunlocking -XXcallprofiling -Xgc:genpar -XXgcthreads=2 -XXtlasize:min=4k,preferred=512k spec.jbb.JBBmain -propfile SPECjbb.props |
JVM Initial Heap Memory (MB) |
3500 |
JVM Maximum Heap Memory (MB) |
3500 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\Program Files\java\jrockit-jdk1.6.0_02\jre\bin\jrockit\jrockit1.6.0.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\bin\jrockit\jmapi.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\bin\jrockit\jmxmapi.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\bin\jrockit\rmp.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\bin\jrockit\latency.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\lib\resources.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\lib\rt.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\lib\sunrsasign.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\lib\jsse.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\lib\jce.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\lib\charsets.jar; C:\Program Files\java\jrockit-jdk1.6.0_02\jre\classes |
OS Version |
Microsoft Windows Server 2003 R2 Enterprise x64 Edition + SP1 |
Other software |
N/A |
|
Test Information |
Tested by |
Fujitsu Siemens Computers |
SPEC license # |
22 |
Test location |
Paderborn, Germany |
Test date |
19.11.2007 |
H/w available |
Dec-2007 |
JVM available |
Oct-2007 |
OS available |
May-2005 |
Other s/w available |
N/A |
|
Tuning |
- Each JVM instance was affinitized to 2 cores of a socket sharing the L2.
- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
|
|
