Hardware |
Hardware Vendor |
SuperMicro, Inc. |
Vendor URL |
http://www.supermicro.com/ |
Model |
X7DBE |
Processor |
Intel Xeon 5160 |
MHz |
3000 |
# of Chips |
2 |
# of Cores |
4 |
# of Cores/Chip |
2 |
HW Threading Enabled? |
No |
Procs Avail to Java |
4 |
Memory (MB) |
8192 |
Memory Details |
8 x 1GB DDR2-667 CL5 FBDIMM |
Primary cache |
32KB(I) + 32KB(D) on chip, per core |
Secondary cache |
4096KB(I+D) on chip, shared |
Other cache |
|
Filesystem |
NTFS |
Disks |
1 x 250GB SATA |
Other hardware |
|
|
Software |
Software Vendor |
IBM Corporation |
Vendor URL |
http://www.ibm.com/ |
JVM Version |
IBM J9 VM (build 2.3, J2RE 1.5.0 IBM J9 2.3 Windows Server 2003 x86-32 j9vmwi3223-20060919 (JIT enabled) |
JVM Command Line |
start /B %JAVA% -Xgcpolicy:gencon -Xjvm:perf -XlockReservation -Xlp -Xmn1000m -Xms1500m -Xmx1500m -Xnoloa -XtlhPrefetch spec.jbb.JBBmain -propfile %PROPFILE% |
JVM Initial Heap Memory (MB) |
1536 |
JVM Maximum Heap Memory (MB) |
1536 |
JVM Address bits |
32 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\java\IBM32-sdk-50-2.0.2\jre\bin\perf\jclSC150\vm.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\core.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\charsets.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\graphics.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\security.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmpkcs.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmorb.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmcfw.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmorbapi.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjcefw.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjgssprovider.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjsseprovider2.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjaaslm.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmjaasactivelm.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\ibmcertpathprovider.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\server.jar; C:\java\IBM32-sdk-50-2.0.2\jre\lib\xml.jar |
OS Version |
Microsoft Windows Server 2003 Enterprise x64 Edition SP1 (64-bit) |
Other software |
|
|
Test Information |
Tested by |
Advanced Micro Devices |
SPEC license # |
49 |
Test location |
Austin, TX |
Test date |
Oct 11, 2006 |
H/w available |
Jul-2006 |
JVM available |
Oct-2006 |
OS available |
Mar-2005 |
Other s/w available |
|
|
Tuning |
- BIOS
- Hardware Prefetcher : [Disabled]
- OS
- Using the local Security Settings console, "Lock pages in memory" was enabled for the user running the benchmark.
|
Notes |
SUT requires a SuperMicro X7DBE motherboard (BIOS rev 1.1a), 8GB of PC2-5300 memory (8 x 1GB CL5 FBDIMMs), a Western Digital WD2500 SATA drive, a SSI EEB 3.51 specification compliant form-factor case, and a Zippy/Emacs 700 watt PSL-6701P Power Supply. |
|
