Hardware |
Hardware Vendor |
Fujitsu Siemens Computers |
Vendor URL |
http://www.fujitsu-siemens.com |
Model |
PRIMERGY TX600 S3, Intel Xeon 7140M processor, 3.40 GHz |
Processor |
Intel Xeon 7140M processor (3.40 GHz, 2x1MB L2, 16MB L3, 800 MHz system bus) |
MHz |
3400 |
# of Chips |
4 |
# of Cores |
8 |
# of Cores/Chip |
2 |
HW Threading Enabled? |
Yes |
Procs Avail to Java |
16 |
Memory (MB) |
32768 |
Memory Details |
16x2GB DDRII-RAM PC2-3200R (CAS 3-3-3) |
Primary cache |
12k micro-ops I + 16KBD on chip, per core |
Secondary cache |
1024KB(I+D) on chip, per core |
Other cache |
16MB on chip, per chip |
Filesystem |
NTFS |
Disks |
Fujitsu MAS3367NC (SCSI, 15krpm, 36GB) |
Other hardware |
none |
|
Software |
Software Vendor |
BEA Systems, Inc |
Vendor URL |
http://www.bea.com |
JVM Version |
BEA JRockit(R) 5.0 P26.4.1 (build P26.4.1-5-64782-1.5.0_06-20060726-0014-win-x86_64) |
JVM Command Line |
java -Xms3700m -Xmx3700m -XXaggressive -XXthroughputCompaction -XXallocPrefetch -XXallocRedoPrefetch -XXcompressedRefs -XXlazyUnlocking -XXtlasize128k spec.jbb.JBBmain -propfile SPECjbb.props |
JVM Initial Heap Memory (MB) |
3700 |
JVM Maximum Heap Memory (MB) |
3700 |
JVM Address bits |
64 |
JVM CLASSPATH |
.\jbb.jar; .\check.jar;
|
JVM BOOTCLASSPATH |
C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\bin\jrockit\jrockit.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\bin\jrockit\managementapi.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\lib\managementapi.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\lib\rt.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\lib\i18n.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\lib\sunrsasign.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\lib\jsse.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\lib\jce.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\lib\charsets.jar; C:\SPECjbb2005\JVM\jrockit-jdk1.5.0_06\jre\classes |
OS Version |
Microsoft Windows Server 2003 Enterprise x64 Edition + SP1 (64-bit) |
Other software |
none |
|
Test Information |
Tested by |
Fujitsu Siemens Computers |
SPEC license # |
22 |
Test location |
Paderborn, Germany |
Test date |
Jul 31, 2006 |
H/w available |
Aug-2006 |
JVM available |
Nov-2006 |
OS available |
Mar-2005 |
Other s/w available |
n/a |
|
Tuning |
- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
- Each JVM instance was bound to the CPUs of one node.
|
Notes |
- turned on 'Adjacent Sector Prefetcher' in BIOS
- turned off 'Memory Scrubbing' in BIOS
- Command line options are described at:
http://edocs.bea.com/jrockit/jrdocs/refman/intro.html - This result was measured on the PRIMERGY RX600 S3. The PRIMERGY TX600 S3 and the PRIMERGY RX600 S3 are electronically equivalent.
|
|
