Hardware |
|---|
| Hardware Vendor |
Fujitsu Siemens Computers |
| Vendor URL |
http://www.fujitsu-siemens.com |
| Model |
PRIMERGY RX220, AMD Opteron(TM) 285 processor |
| Processor |
AMD Opteron(TM) 285 processor, 2.60GHz, 2x1MB L2 |
| MHz |
2600 |
| # of Chips |
2 |
| # of Cores |
4 |
| # of Cores/Chip |
2 |
| HW Threading Enabled? |
n/a |
| Procs Avail to Java |
4 |
| Memory (MB) |
16384 |
| Memory Details |
8x2GB DDR-RAM PC2-3200R (CAS 3-3-3) |
| Primary cache |
64KBI + 64KBD on chip, per core |
| Secondary cache |
1MB(I+D) on chip, per core |
| Other cache |
n/a |
| Filesystem |
NTFS |
| Disks |
1 x 80GB, Maxtor (SATA) |
| Other hardware |
none |
|
|
Software |
|---|
| Software Vendor |
BEA Systems, Inc |
| Vendor URL |
http://www.bea.com |
| JVM Version |
BEA JRockit(R) 5.0 P26.4.0 (build P26.4.0-10-62459-1.5.0_06-20060529-2101-win-x86_64) |
| JVM Command Line |
start /AFFINITY %NODE_CPUs% /B java -Xms3700m -Xmx3700m -XXaggressive -XXthroughputCompaction -XXallocPrefetch -XXallocRedoPrefetch -XXcompressedRefs -XXlazyUnlocking -XXtlasize128k spec.jbb.JBBmain -propfile SPECjbb.props |
| JVM Initial Heap Memory (MB) |
3700 |
| JVM Maximum Heap Memory (MB) |
3700 |
| JVM Address bits |
64 |
| JVM CLASSPATH |
.\jbb.jar;
.\check.jar;
|
| JVM BOOTCLASSPATH |
C:\SPECjbb2005\JVM\P26.4.0\jre\bin\jrockit\jrockit.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\bin\jrockit\managementapi.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\lib\managementapi.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\lib\rt.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\lib\i18n.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\lib\sunrsasign.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\lib\jsse.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\lib\jce.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\lib\charsets.jar;
C:\SPECjbb2005\JVM\P26.4.0\jre\classes |
| OS Version |
Microsoft Windows Server 2003 Enterprise x64 Edition + SP1 (64-bit) |
| Other software |
none |
|
|
Test Information |
|---|
| Tested by |
Fujitsu Siemens Computers |
| SPEC license # |
22 |
| Test location |
Paderborn, Germany |
| Test date |
Aug 4, 2006 |
| H/w available |
Aug-2006 |
| JVM available |
Jun-2006 |
| OS available |
Mar-2005 |
| Other s/w available |
n/a |
|
|
Tuning |
|---|
Operating system tunings- Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark.
- JVM instance 0 was bound to the CPUs 0,1 of node 0<\li>
- JVM instance 1 was bound to CPUs 2,3 of node 1<\li>
|
|
