SPECjbb2005 SPECjbb2005 bops = 326651, SPECjbb2005 bops/JVM = 40831
IBM Corporation IBM System p5 570 (2200 MHz, 16 Cores)
IBM Corporation J2RE 1.5.0 (32-bit) IBM J9 2.3 AIX ppc-32 j9vmap3223-20060114

JVM run JVM Scores
140350
241591
339810
441497
539950
640880
741235
841338
SPECjbb2005 bops = 326651, SPECjbb2005 bops/JVM = 40831

Hardware
Hardware Vendor IBM Corporation
Vendor URL http://www.ibm.com
Model IBM System p5 570 (2200 MHz, 16 Cores)
Processor POWER5+
MHz 2200
# of Chips 8
# of Cores 16
# of Cores/Chip 2
HW Threading Enabled? Yes
Procs Avail to Java 32
Memory (MB) 131072
Memory Details
Primary cache 64KBI+32KBD (on chip)/core
Secondary cache 1920KB unified (on chip)/chip
Other cache 36MB unified (off chip)/DCM, 8 DCMs in SUT
Filesystem JFS
Disks 1 x 36GB SCSI
Other hardware
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version J2RE 1.5.0 (32-bit) IBM J9 2.3 AIX ppc-32 j9vmap3223-20060114
JVM Command Line execrset -c processor_set_number -e java -cp jbb.jar:check.jar -Xlp -Xcompactgc -Xgcpolicy:subpool -Xms3g -Xmx3g spec.jbb.JBBmain -propfile SPECjbb.props -id JVM_number
JVM Initial Heap Memory (MB) 3072
JVM Maximum Heap Memory (MB) 3072
JVM Address bits 32
JVM CLASSPATH jbb.jar:
check.jar
JVM BOOTCLASSPATH /java/pap32dev-20060114/jre/lib/vm.jar:
/java/pap32dev-20060114/jre/lib/core.jar:
/java/pap32dev-20060114/jre/lib/charsets.jar:
/java/pap32dev-20060114/jre/lib/graphics.jar:
/java/pap32dev-20060114/jre/lib/security.jar:
/java/pap32dev-20060114/jre/lib/ibmpkcs.jar:
/java/pap32dev-20060114/jre/lib/ibmorb.jar:
/java/pap32dev-20060114/jre/lib/ibmcfw.jar:
/java/pap32dev-20060114/jre/lib/ibmorbapi.jar:
/java/pap32dev-20060114/jre/lib/ibmjcefw.jar:
/java/pap32dev-20060114/jre/lib/ibmjgssprovider.jar:
/java/pap32dev-20060114/jre/lib/ibmjsseprovider2.jar:
/java/pap32dev-20060114/jre/lib/ibmjaaslm.jar:
/java/pap32dev-20060114/jre/lib/ibmcertpathprovider.jar:
/java/pap32dev-20060114/jre/lib/server.jar:
/java/pap32dev-20060114/jre/lib/xml.jar
OS Version AIX 5L V5.3
Other software
Test Information
Tested by IBM Corporation
SPEC license # 11
Test location Austin, TX
Test date Jan 15, 2006
H/w available Feb-2006
JVM available Mar-2006
OS available Feb-2006
Other s/w available
AOT Compilation

Tuning
Operating system tunings<UL><LI>vmo -o lgpg_regions=6400 -o lgpg_size=16777216</LI><LI>vmo -o v_pinshm=1</LI><LI>SPINLOOPTIME=1000</LI><LI>MEMORY_AFFINITY=MCM</LI></UL>
Notes
Each JVM was run in its own processor set containing 2 cores


JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 13402
2 25217
3 34513
4 41307 *
5 40903 *
6 40421 *
7 39865 *
8 39253 *
SPECjbb2005 (from 4 to 8) 40350 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 15, 2006


JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 13392
2 27887
3 34952
4 42723 *
5 42204 *
6 41628 *
7 41160 *
8 40239 *
SPECjbb2005 (from 4 to 8) 41591 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 15, 2006


JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 12660
2 28623
3 34340
4 40822 *
5 40264 *
6 39877 *
7 39271 *
8 38813 *
SPECjbb2005 (from 4 to 8) 39810 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 15, 2006


JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 12934
2 26065
3 35090
4 42389 *
5 42069 *
6 41518 *
7 40863 *
8 40646 *
SPECjbb2005 (from 4 to 8) 41497 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 15, 2006


JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 13376
2 28172
3 34106
4 40742 *
5 40605 *
6 40120 *
7 39569 *
8 38714 *
SPECjbb2005 (from 4 to 8) 39950 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 15, 2006


JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 12377
2 28051
3 34556
4 41801 *
5 41399 *
6 40961 *
7 40395 *
8 39844 *
SPECjbb2005 (from 4 to 8) 40880 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 15, 2006


JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 12073
2 28089
3 35087
4 42334 *
5 41862 *
6 41140 *
7 40660 *
8 40181 *
SPECjbb2005 (from 4 to 8) 41235 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 15, 2006


JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 13062
2 25875
3 34309
4 41617 *
5 42144 *
6 41697 *
7 41000 *
8 40230 *
SPECjbb2005 (from 4 to 8) 41338 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Jan 15, 2006

SPECjbb2005 Version: [SPECjbb2005 1.06, January 5, 2006]
Reporting page, Copyright © 2005 SPEC. All rights reserved

First published at SPEC.org on 02-Mar-2006
