SPEC® CINT2006 Result
Copyright 2006-2016 Standard Performance Evaluation Corporation
Bull SAS
bullion S16 ( E7-8890 v3 )
The numactl mechanism was used to bind copies to processors. The config file option 'submit'
was used to generate numactl commands to bind each copy to a specific processor.
For details, please see the config file.
SPEC files placed in /spec2006, with /spec2006
mounted as tmpfs with mpol=interleave, size=1200G
Stack size set to unlimited using "ulimit -s unlimited"
Turbo mode set with:
cpupower -c all frequency-set -g performance
To run the Intel binaries based off the Intel 16.0 compiler (with SLES11 SP4), the following software was updated:
gcc to version 4.3-62.200.2
gcc43 to version 4.3.4_20091019-0.37.30
glibc to version 2.14.1-14.12.5
glibc-devel to version 2.14.1-14.12.5
glibc-locale to version 2.14.1-14.12.5
libstdc++43-devel to version 4.3.4_20091019-0.37.30
libstdc++-devel to version 4.3-62.200.2
BIOS configuration:
Set Efficiency Policy to Performance
Energy perf BIAS cfg mode = PERF
Set Memory RAS to Performance
Set Patrol Scrub to disable
Baseboard Management Controller used to Force Full Fan Speed
Sysinfo program /specRam/config/sysinfo.rev6914
$Rev: 6914 $ $Date:: 2014-06-25 #$ e3fbb8667b5a285932ceab81e28219e1
running on borsalino Tue Dec 15 17:16:22 2015
This section contains SUT (System Under Test) info as seen by
some common utilities. To remove or add to this section, see:
http://www.spec.org/cpu2006/Docs/config.html#sysinfo
From /proc/cpuinfo
model name : Intel(R) Xeon(R) CPU E7-8890 v3 @ 2.50GHz
16 "physical id"s (chips)
576 "processors"
cores, siblings (Caution: counting these is hw and system dependent. The
following excerpts from /proc/cpuinfo might not be reliable. Use with
caution.)
cpu cores : 18
siblings : 36
physical 0: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 1: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 2: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 3: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 4: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 5: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 6: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 7: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 8: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 9: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 10: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 11: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 12: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 13: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 14: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 15: cores 0 1 2 3 4 8 9 10 11 16 17 18 19 20 24 25 26 27
cache size : 46080 KB
From /proc/meminfo
MemTotal: 4235810492 kB
HugePages_Total: 0
Hugepagesize: 2048 kB
/usr/bin/lsb_release -d
SUSE Linux Enterprise Server 11 (x86_64)
From /etc/*release* /etc/*version*
SuSE-release:
SUSE Linux Enterprise Server 11 (x86_64)
VERSION = 11
PATCHLEVEL = 4
os-release:
NAME="SLES"
VERSION="11.4"
VERSION_ID="11.4"
PRETTY_NAME="SUSE Linux Enterprise Server 11 SP4"
ID="sles"
ANSI_COLOR="0;32"
CPE_NAME="cpe:/o:suse:sles:11:4"
uname -a:
Linux borsalino 3.0.101-63-default #1 SMP Tue Jun 23 16:02:31 UTC 2015
(4b89d0c) x86_64 x86_64 x86_64 GNU/Linux
run-level 5 Dec 15 11:51 last=S
SPEC is set to: /specRam
Filesystem Type Size Used Avail Use% Mounted on
none tmpfs 1.2T 3.8G 1.2T 1% /specRam
Additional information from dmidecode:
Warning: Use caution when you interpret this section. The 'dmidecode' program
reads system data which is "intended to allow hardware to be accurately
determined", but the intent may not be met, as there are frequent changes to
hardware, firmware, and the "DMTF SMBIOS" standard.
BIOS Bull AR08.031.00.101 11/19/2015
Memory:
128x NO DIMM Unknown
256x Samsung M393A2G40DB0-CPB 16 GB 2 rank , configured at 1600 MHz
(End of data from sysinfo program)
BIOS egineering version number AR08.031.00.101 is identical to
public version number BIOSX08.31.00.102
Environment variables set by runspec before the start of the run:
LD_LIBRARY_PATH = "/specRam/libs/32:/specRam/libs/64:/specRam/sh"
Binaries compiled on a system with 1x Intel Core i5-4670K CPU + 32GB
memory using RedHat EL 7.1
Transparent Huge Pages enabled with:
echo always > /sys/kernel/mm/transparent_hugepage/enabled
Filesystem page cache cleared with:
echo 1> /proc/sys/vm/drop_caches
runspec command invoked through numactl i.e.:
numactl --interleave=all runspec <etc>
