SPEC® CFP2006 Result

Copyright 2006-2014 Standard Performance Evaluation Corporation

Supermicro

Motherboard PDSMU

CPU2006 license: 001176 Test date: Apr-2007
Test sponsor: Supermicro Hardware Availability: Dec-2006
Tested by: Supermicro Software Availability: Mar-2007
Benchmark results graph
Hardware
CPU Name: Intel Core 2 Duo E4300
CPU Characteristics: 1.8 GHz, 800 MHz bus
CPU MHz: 1800
FPU: Integrated
CPU(s) enabled: 2 cores, 1 chip, 2 cores/chip
CPU(s) orderable: 1 chip
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 2 MB I+D on chip per chip
L3 Cache: None
Other Cache: None
Memory: 4 GB (2 X 2GB ECC, CL4, 533MHz, UBDIMM)
Disk Subsystem: 250GB SATA, 7200RPM
Other Hardware: None
Software
Operating System: Windows Server 2003 Enterprise Edition w/ SP1
Compiler: Intel C++ Compiler for IA32 version 9.1
Build no 20070322Z
Microsoft Visual Studio .Net 2003 (for libraries)
Auto Parallel: Yes
File System: NTFS
System State: Default
Base Pointers: 32-bit
Peak Pointers: 32-bit
Other Software: SmartHeap Library Version 8.0

Results Table

Benchmark Base Peak
Copies Seconds Ratio Seconds Ratio Seconds Ratio Copies Seconds Ratio Seconds Ratio Seconds Ratio
Results appear in the order in which they were run. Bold underlined text indicates a median measurement.
410.bwaves 2 1340 20.3 1340 20.3 1338 20.3 2 1278 21.3 1278 21.3 1280 21.2
416.gamess 2 1843 21.3 1842 21.3 1843 21.3 2 1964 19.9 1971 19.9 1971 19.9
433.milc 2 1446 12.7 1447 12.7 1446 12.7 2 1443 12.7 1442 12.7 1442 12.7
434.zeusmp 2 912 20.0 912 20.0 912 20.0 2 912 20.0 912 20.0 912 20.0
435.gromacs 2 697 20.5 696 20.5 696 20.5 2 697 20.5 698 20.5 696 20.5
436.cactusADM 2 970 24.6 971 24.6 967 24.7 2 970 24.6 971 24.6 967 24.7
437.leslie3d 2 1429 13.2 1428 13.2 1425 13.2 2 1428 13.2 1428 13.2 1428 13.2
444.namd 2 881 18.2 881 18.2 881 18.2 2 867 18.5 867 18.5 867 18.5
447.dealII 2 948 24.1 947 24.2 954 24.0 2 863 26.5 866 26.4 864 26.5
450.soplex 2 1202 13.9 1201 13.9 1202 13.9 2 1169 14.3 1167 14.3 1169 14.3
453.povray 2 424 25.1 425 25.1 425 25.1 2 331 32.2 331 32.2 331 32.2
454.calculix 2 994 16.6 994 16.6 994 16.6 2 989 16.7 988 16.7 988 16.7
459.GemsFDTD 2 1745 12.2 1744 12.2 1745 12.2 2 1745 12.2 1744 12.2 1745 12.2
465.tonto 2 1450 13.6 1452 13.6 1453 13.5 2 1450 13.6 1452 13.6 1453 13.5
470.lbm 2 2260 12.2 2259 12.2 2260 12.2 2 2260 12.2 2259 12.2 2260 12.2
481.wrf 2 1188 18.8 1202 18.6 1201 18.6 2 1188 18.8 1202 18.6 1201 18.6
482.sphinx3 2 1865 20.9 1863 20.9 1863 20.9 2 1716 22.7 1713 22.8 1716 22.7

General Notes

 Tested systems can be used with CSE-815TQ-R450U case.
 For a general system, a 420W (minimum) ATX12V power supply [8-pin +12V AND 24-pin is recommended
 to assure system stability].
 Product description located as of
 http://www.supermicro.com/products/motherboard/Xeon3000/3010/PDSMU.cfm
 The system bus runs at 800 MHz.

Base Compiler Invocation

C benchmarks:

 icl   -Qvc7.1   -Qc99

C++ benchmarks:

 icl   -Qvc7.1

Fortran benchmarks:

 ifort

Benchmarks using both Fortran and C:

 icl   -Qvc7.1   -Qc99   ifort

Base Portability Flags

436.cactusADM:  -Qlowercase   /assume:underscore
444.namd:  -TP
447.dealII:  -DDEAL_II_MEMBER_VAR_SPECIALIZATION_BUG   -DBOOST_NO_INTRINSIC_WCHAR_T
453.povray:  -DSPEC_CPU_WINDOWS_ICL
454.calculix:  -DSPEC_CPU_NOZMODIFIER   -Qlowercase
481.wrf:  -DSPEC_CPU_WINDOWS_ICL

Base Optimization Flags

C benchmarks:

 -fast   /F950000000   shlw32m.lib    -link /FORCE:MULTIPLE

C++ benchmarks:

 -fast   -Qcxx_features   /F950000000   shlw32m.lib    -link /FORCE:MULTIPLE

Fortran benchmarks:

 -fast   /F950000000    -link /FORCE:MULTIPLE

Benchmarks using both Fortran and C:

 -fast   /F950000000    -link /FORCE:MULTIPLE

Peak Compiler Invocation

C benchmarks:

 icl   -Qvc7.1   -Qc99

C++ benchmarks:

 icl   -Qvc7.1

Fortran benchmarks:

 ifort

Benchmarks using both Fortran and C:

 icl   -Qvc7.1   -Qc99   ifort

Peak Portability Flags

436.cactusADM:  -Qlowercase   /assume:underscore
444.namd:  -TP
447.dealII:  -DDEAL_II_MEMBER_VAR_SPECIALIZATION_BUG   -DBOOST_NO_INTRINSIC_WCHAR_T
453.povray:  -DSPEC_CPU_WINDOWS_ICL
454.calculix:  -DSPEC_CPU_NOZMODIFIER   -Qlowercase
481.wrf:  -DSPEC_CPU_WINDOWS_ICL

Peak Optimization Flags

C benchmarks:

433.milc:  -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -fast   /F950000000   shlw32m.lib    -link /FORCE:MULTIPLE
470.lbm:  basepeak = yes
482.sphinx3:  -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -QxB   -Qipo   -O3   -Qprec-div-   /F950000000   shlw32m.lib    -link /FORCE:MULTIPLE

C++ benchmarks:

 -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -fast   -Qcxx_features   /F950000000   shlw32m.lib    -link /FORCE:MULTIPLE

Fortran benchmarks:

410.bwaves:  -QxW   -Qparallel   -Qipo   -O3   -Qprec-div-   /F950000000   libguide.lib   libguide40.lib    -link /FORCE:MULTIPLE
416.gamess:  Same as 410.bwaves
434.zeusmp:  basepeak = yes
437.leslie3d:  -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -fast   /F950000000    -link /FORCE:MULTIPLE
459.GemsFDTD:  basepeak = yes
465.tonto:  basepeak = yes

Benchmarks using both Fortran and C:

435.gromacs:  -QxW   -Qparallel   -Qipo   -O3   -Qprec-div-   /F950000000   shlw32m.lib   libguide.lib   libguide40.lib    -link /FORCE:MULTIPLE
436.cactusADM:  basepeak = yes
454.calculix:  -Qprof_gen(pass 1)   -Qprof_use(pass 2)   -fast   /F950000000    -link /FORCE:MULTIPLE
481.wrf:  basepeak = yes

The flags file that was used to format this result can be browsed at
http://www.spec.org/cpu2006/flags/Intel-ic91-ia32-flags.html.

You can also download the XML flags source by saving the following link:
http://www.spec.org/cpu2006/flags/Intel-ic91-ia32-flags.xml.
