| Server Configuration and Availability |
|---|
| Vendor | NEC Corporation |
| Hardware Available | January 2006 |
| Software Available | January 2006 |
| Date Tested | September 2006 |
| SFS License Number | 89 |
| Licensee Locations | Tokyo, Japan |
| CPU, Memory and Power |
|---|
| Model Name | NV7300, 2 node active/active cluster |
| Processor | 3.8GHz Xeon |
| # of Processors | 4 cores, 4 chips, 1 core/chip (2 cores per node) |
| Primary Cache | 12 KuOPs + 16 KB D |
| Secondary Cache | 2048 KB on chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 16 GB (8 GB per node) |
| NVRAM Size | 1 GB (512 MB per node) |
| NVRAM Type | DIMMs on PCI express cards |
| NVRAM Description | 3-day battery |
| Server Software |
|---|
| OS Name and Version | SC-LX V5.1 |
| Other Software | N/A |
| File System | SXFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 256 |
| Fileset Size | 464.2 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | 1000/100/10BASE-T (Copper) |
| Number Networks | 1 |
| Number Network Controllers | 2 (1 per node) |
| Protocol Type | TCP |
| Switch Type | Extreme Summit7i |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 (1 per node) |
| Number of Disks | 235 |
| Number of Filesystems | 2 |
| File System Creation Ops | 4-GB Journal size (See notes below) |
| File System Config | See notes below. |
| Disk Controller | Integrated dual-channel 4Gbps FC controller |
| # of Controller Type | 2 |
| Number of Disks | 235 |
| Disk Type | 147GB 10K RPM x 3, 147GB 15K RPM x 232 |
| File Systems on Disks | Operating System, F1 F2 |
| Special Config Notes | 2GB write cache on the DAC. See notes below. |
|
