| Server Configuration and Availability |
|---|
| Vendor | Hewlett-Packard |
| Hardware Available | February 2007 |
| Software Available | February 2007 |
| Date Tested | February 2007 |
| SFS License Number | 3 |
| Licensee Locations | Richardson, Texas |
| CPU, Memory and Power |
|---|
| Model Name | HP ProLiant DL585 G2 Storage Server |
| Processor | AMD Opteron 8220SE, Dual-Core (2.8 GHz, 120 Watts) |
| # of Processors | 8 cores, 4 chips, 2 cores/chip |
| Primary Cache | 64 KB + 64 KB (I + D) |
| Secondary Cache | 1 MB |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | HP StorageWorks SAN Switch 4/32 |
| Memory Size | 32 GB |
| NVRAM Size | 8 GB |
| NVRAM Type | 8 GB mirrored battery backed NVRAM (96 hours) |
| NVRAM Description | See notes below |
| Server Software |
|---|
| OS Name and Version | Microsoft® Windows Unified Data Storage Server(tm) 2003, Enterprise x64 Edition |
| Other Software | -- |
| File System | NTFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 64 |
| Fileset Size | 367.6 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | NC371i Multifunction Gigabit Network Adapter (embedded) |
| Number Networks | 2 |
| Number Network Controllers | 2 |
| Protocol Type | UDP |
| Switch Type | HP ProCurve Switch 2900-48G |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 3 |
| Number of Disks | 338 |
| Number of Filesystems | 14 |
| File System Creation Ops | /q /fs:ntfs /x |
| File System Config | chkdsk /l:65536 |
| Disk Controller | HP Smart Array P400 with 512MB Battery-Backed Write Cache (BBWC) |
| # of Controller Type | 1 |
| Number of Disks | 2 |
| Disk Type | 36GB, 10000 rpm SFF SAS |
| File Systems on Disks | os, pagefile |
| Special Config Notes | Configured in RAID1 |
| Disk Controller | HP StorageWorks FC1242 Dual Channel 4Gb PCI-E HBA |
| # of Controller Type | 2 |
| Number of Disks | 336 |
| Disk Type | 72GB, 15000 rpm and 36GB, 15000 rpm |
| File Systems on Disks | F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,F13,F14 |
| Special Config Notes | See notes below. |
|
