| Server Configuration and Availability |
|---|
| Vendor | Hewlett-Packard |
| Hardware Available | November 2004 |
| Software Available | March 2005 |
| Date Tested | March 2005 |
| SFS License Number | 3 |
| Licensee Locations | Richardson, Texas |
| CPU, Memory and Power |
|---|
| Model Name | hp ProLiant DL380 G4 Storage Server SAN Storage Model |
| Processor | Intel Xeon DP @ 3.4 GHz |
| # of Processors | 2 cores, 2 chips, 1 core/chip (Hyper-Threading Technology enabled) |
| Primary Cache | 12 KB + 8 KB (I + D) |
| Secondary Cache | 1 MB |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | 2 hp 8b Fibre Channel Switches |
| Memory Size | 6 GB |
| NVRAM Size | 6GB (2GB/VA7410 *3) |
| NVRAM Type | 3 day battery backed NVRAM |
| NVRAM Description | VA7410 Array controller |
| Server Software |
|---|
| OS Name and Version | Microsoft® Windows® Storage Server 2003 Enterprise Edition |
| Other Software | hp ProLiant Storage Server Service Release 5.4 |
| File System | NTFS |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 64 |
| Fileset Size | 148.9 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | NC7782 Dual Port PCI-X Gigabit Server Adapter (embedded) |
| Number Networks | 2 |
| Number Network Controllers | 2 |
| Protocol Type | UDP |
| Switch Type | ExtremeNetworks Summit 7i |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 3 |
| Number of Disks | 128 |
| Number of Filesystems | 7 |
| File System Creation Ops | /q /fs:ntfs /v: /a:16k /x |
| File System Config | chkdsk /l:65536 |
| Disk Controller | Integrated Ultra320 Smart Array 6i Controller with 128MB Battery-Backed Write Cache (BBWC) |
| # of Controller Type | 1 |
| Number of Disks | 2 |
| Disk Type | 36GB, 15000 rpm Ultra320 SCSI |
| File Systems on Disks | os, pagefile |
| Special Config Notes | Configured in RAID1 |
| Disk Controller | Fibre Channel FCA2404 |
| # of Controller Type | 2 |
| Number of Disks | 63/63 |
| Disk Type | 18GB, 15000 rpm (A6191A) |
| File Systems on Disks | F1,F3,F5 / F2,F4,F6 |
| Special Config Notes | See notes below. |
|
