| Server Configuration and Availability |
|---|
| Vendor | Hitachi Data Systems |
| Hardware Available | Nov 2003 |
| Software Available | Nov 2003 |
| Date Tested | Nov 2003 |
| SFS License Number | 45 |
| Licensee Locations | San Diego, USA |
| CPU, Memory and Power |
|---|
| Model Name | Lightning NAS Blade - 2 Cluster |
| Processor | Intel Pentium-IV Xeon 1.60Ghz |
| # of Processors | 4 cores, 4 chips, 1 core/chip (1 per NAS Blade) |
| Primary Cache | 12KB (I + 8KB D) on chip |
| Secondary Cache | 512KB (I + D) on chip |
| Other Cache | N/A |
| UPS | Integrated into Lightning 9980V System |
| Other Hardware | N/A |
| Memory Size | 79448MB (9980V Cache + NAS Embedded Cache - See Notes) |
| NVRAM Size | 65536MB (9980V Cache) |
| NVRAM Type | UPS-Protected DRAM |
| NVRAM Description | See Notes |
| Server Software |
|---|
| OS Name and Version | NAS Software Version 02.00 (based on Linux kernel 2.4.17) |
| Other Software | N/A |
| File System | HIXFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 512 (128 per NAS Blade) |
| Fileset Size | 696.3 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet : Jumbo Frame Gigabit (9000 byte frames) |
| Network Controller Desc. | Intel PRO/1000MT (2 per NAS Blade) |
| Number Networks | 1 |
| Number Network Controllers | 4 Ethernet Ports (See Notes) |
| Protocol Type | UDP |
| Switch Type | Cisco Catalyst 6506 |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 1 |
| Number of Disks | 128 |
| Number of Filesystems | 32 (fs00, fs01, .., fs31) |
| File System Creation Ops | default |
| File System Config | RAID Level 0+1, 128 Physical Disks, 4 Disks per File System |
| Disk Controller | Integrated into Lightning NAS Blade |
| # of Controller Type | 1 |
| Number of Disks | 128 |
| Disk Type | Hitachi DKR2D-J072FC, 72GB 10K RPM |
| File Systems on Disks | fs00, fs01, .., fs31 |
| Special Config Notes | See Notes |
|
