| Server Configuration and Availability |
|---|
| Vendor | Hewlett-Packard |
| Hardware Available | Oct 2002 |
| Software Available | Oct 2002 |
| Date Tested | Oct 2002 |
| SFS License Number | 3 |
| Licensee Locations | Richardson, Texas |
| CPU, Memory and Power |
|---|
| Model Name | hp StorageWorks NAS 8000 |
| Processor | Intel Xeon MP @ 1.6 GHz |
| # of Processors | 4 |
| Primary Cache | 12 KB + 8 KB (I + D) |
| Secondary Cache | 256 K |
| Other Cache | L3 Cache 1 MB |
| UPS | N/A |
| Other Hardware | 2 HP16B Fibre Channel Switches |
| Memory Size | 2 GB |
| NVRAM Size | 3 GB (1 GB/VA7410 * 3) |
| NVRAM Type | 1 GB battery backed NVRAM (3 day) |
| NVRAM Description | VA7410 Array controller |
| Server Software |
|---|
| OS Name and Version | hp NAS 8000 operating system 1.5.0-214 |
| Other Software | N/A |
| File System | hp NAS 8000 filesystem |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 128 |
| Fileset Size | 111.2 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet Jumbo Frame |
| Network Controller Desc. | NC7770 (PCI-X 1000Base-T) |
| Number Networks | 2 |
| Number Network Controllers | 2 |
| Protocol Type | UDP |
| Switch Type | Extreme Alpine 3808 |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 3 |
| Number of Disks | 128 |
| Number of Filesystems | 31 |
| File System Creation Ops | default |
| File System Config | N/A |
| Disk Controller | Integrated Smart Array 5i Plus (Builtin) |
| # of Controller Type | 1 |
| Number of Disks | 2 |
| Disk Type | 18.2GB, 10000 rpm Ultra3 SCSI |
| File Systems on Disks | os, swap |
| Special Config Notes | Configured in RAID1 |
| Disk Controller | Fibre Channel FCA2101 |
| # of Controller Type | 1 |
| Number of Disks | 63 |
| Disk Type | 18GB, 15000 rpm (A6191A) |
| File Systems on Disks | F1,F3,F5,F7..F29 |
| Special Config Notes | See notes below. |
| Disk Controller | Fibre Channel FCA2101 |
| # of Controller Type | 1 |
| Number of Disks | 63 |
| Disk Type | 18GB, 15000 rpm (A6191A) |
| File Systems on Disks | F2,F4,F6,F8..F30 |
| Special Config Notes | See notes below. |
|
