| Server Configuration and Availability |
|---|
| Vendor | Sun Microsystems |
| Hardware Available | Dec 2001 |
| Software Available | May 2002 |
| Date Tested | May 2002 |
| SFS License Number | 6 |
| Licensee Locations | Palo Alto, CA |
| CPU, Memory and Power |
|---|
| Model Name | Sun Fire 280R |
| Processor | 900 MHz UltraSPARC III Cu |
| # of Processors | 2 |
| Primary Cache | 32KBI+64KBD on chip |
| Secondary Cache | 8MB(I+D) off chip |
| Other Cache | none |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 8 GB |
| NVRAM Size | 2.5GB (256MB per Sun StorEdge T3 Controller) |
| NVRAM Type | Sun StorEdge T3 write cache |
| NVRAM Description | auto-sensing WB/WT depending on battery charge |
| Server Software |
|---|
| OS Name and Version | Solaris 9 |
| Other Software | N/A |
| File System | UFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | dynamic |
| # NFS Processes | 1024 |
| Fileset Size | 117.0 GB |
|
| Network Subsystem |
|---|
| Network Type | Sun GigabitEthernet PCI adapter 2.0 |
| Network Controller Desc. | Gigabit Ethernet |
| Number Networks | 1 (N1) |
| Number Network Controllers | 1 |
| Protocol Type | TCP |
| Switch Type | Cisco Catalyst 4912G Switch |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 3 |
| Number of Disks | 91 |
| Number of Filesystems | 10 (F1-F10) |
| File System Creation Ops | Default |
| File System Config | Striped across 9 disk luns with a 49GB filesystem |
| Disk Controller | On-board FC-AL |
| # of Controller Type | 1 |
| Number of Disks | 1 |
| Disk Type | Seagate Cheetah 36GB 10K RPM |
| File Systems on Disks | OS, swap |
| Special Config Notes | N/A |
| Disk Controller | Sun cPCI Dual FC-AL Network Adapter (1 Gbit/port) |
| # of Controller Type | 2 |
| Number of Disks | 90 |
| Disk Type | Seagate Cheetah 18GB 10K RPM |
| File Systems on Disks | F1-5, F6-10 |
| Special Config Notes | Filesystems on RAID 0 LUNs (see "Other Notes") |
|
