| Server Configuration and Availability |
|---|
| Vendor | Hewlett-Packard |
| Hardware Available | June 2001 |
| Software Available | June 2001 |
| Date Tested | Sept 2001 |
| SFS License Number | 3 |
| Licensee Locations | Richardson, Texas |
| CPU, Memory and Power |
|---|
| Model Name | hp server rx4610 |
| Processor | Itanium 800 Mhz |
| # of Processors | 4 |
| Primary Cache | 16KB Instruction, 16KB data |
| Secondary Cache | 96KB I+D |
| Other Cache | L3 cache 4 MB |
| UPS | N/A |
| Other Hardware | Brocade Silkworm 2800 FC switch (16 port) |
| Memory Size | 16 GB |
| NVRAM Size | 2 GB (256MB*8) |
| NVRAM Type | 256 MB NVRAM 5 Day battery |
| NVRAM Description | FC60 Array controller |
| Server Software |
|---|
| OS Name and Version | HP-UX 11.20 |
| Other Software | N/A |
| File System | JFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic with ceiling at 65 percent |
| # NFS Processes | 192 |
| Fileset Size | 159.5 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | PCI 1000Base-SX Model #A4926A-60001 |
| Number Networks | 4 |
| Number Network Controllers | 4 |
| Protocol Type | UDP |
| Switch Type | HP Procurve 4000M Gigabit |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 4 |
| Number of Disks | 193 |
| Number of Filesystems | 96 |
| File System Creation Ops | mkfs -F vxfs -o logsize=2048 -bs 8192 |
| File System Config | N/A |
| Disk Controller | QLogic 12160 dual Ultra3 SCSI |
| # of Controller Type | 1 |
| Number of Disks | 1 |
| Disk Type | QUANTUM ATLAS_V_18_SCA |
| File Systems on Disks | os, swap, dump |
| Special Config Notes | N/A |
| Disk Controller | PCI FiberChannel A3740A Shortwave |
| # of Controller Type | 4 |
| Number of Disks | 192 |
| Disk Type | 9GB, 10000 rpm |
| File Systems on Disks | F1,F5..F93 F2,F6..F94 F3,F7..F95 F4,F8..F96 |
| Special Config Notes | See notes below. |
|
