| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | March 2001 |
| Software Available | July 2001 |
| Date Tested | September 2001 |
| SFS License Number | 33 |
| Licensee Locations | Sunnyvale, CA |
| CPU, Memory and Power |
|---|
| Model Name | F820c Failover Cluster (UDP, 52x36GB FCAL, 2xGbE) |
| Processor | 733-MHz Intel Pentium III Coppermine |
| # of Processors | 2 cores, 2 chips, 1 core/chip (1 per node) |
| Primary Cache | 16 KB I + 16 KB D |
| Secondary Cache | 256 KB on-die |
| Other Cache | N/A |
| UPS | none |
| Other Hardware | X1920A cluster adapter card (see notes) |
| Memory Size | 2048 MB (1024 MB per node) |
| NVRAM Size | 256 MB (128 MB per node) |
| NVRAM Type | DIMMs on PCI cards |
| NVRAM Description | 15-day battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | Data ONTAP 6.1.1 |
| Other Software | Cluster Option |
| File System | WAFL |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | default |
| # NFS Processes | N/A |
| Fileset Size | 139.3 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | X1025B PCI adapter card |
| Number Networks | 1 (N1) |
| Number Network Controllers | 2 (1 per node) |
| Protocol Type | UDP |
| Switch Type | Extreme Summit4 (N1) |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 4 |
| Number of Disks | 52 |
| Number of Filesystems | 2 |
| File System Creation Ops | default |
| File System Config | 3 RAID-groups of 8 disks each |
| Disk Controller | X2040B FC-AL adapter card (128 KB RAM standard) |
| # of Controller Type | 4 |
| Number of Disks | 26/26 |
| Disk Type | X231A 36GB FC-AL |
| File Systems on Disks | F1/F2 |
| Special Config Notes | 2 primary controllers, 2 secondaries (see notes) |
|
