SPECpower_ssj2008

Dell Inc. PowerEdge XR5610 (Intel Xeon Gold 6421N, 1.80 GHz)			SPECpower_ssj2008 = 9,779 overall ssj_ops/watt
Test Sponsor:	Dell Inc.	SPEC License #:	6573	Test Method:	Single Node
Tested By:	Dell Inc.	Test Location:	Round Rock, TX, USA	Test Date:	Jul 18, 2023
Hardware Availability:	May-2023	Software Availability:	Jul-2023	Publication:	Aug 16, 2023
System Source:	Single Supplier	System Designation:	Server	Power Provisioning:	Line-powered

Hardware
Hardware Vendor:	Dell Inc.
Model:	PowerEdge XR5610 (Intel Xeon Gold 6421N, 1.80 GHz)
Form Factor:	2U
CPU Name:	Intel Xeon Gold 6421N
CPU Characteristics:	32-Core, 1.80GHz, 60MB L3 Cache
CPU Frequency (MHz):	1800
CPU(s) Enabled:	32 cores, 1 chip, 32 cores/chip
Hardware Threads:	64 (2 / core)
CPU(s) Orderable:	1 chip1
Primary Cache:	32 KB I + 48 KB D on chip per core
Secondary Cache:	2 MB I+D on chip per core
Tertiary Cache:	60 MB I+D on chip per chip
Other Cache:	None
Memory Amount (GB):	128
# and size of DIMM:	8 x 16 GB
Memory Details:	16GB 2Rx8 PC5-4800-R. Slots A1-8 populated
Power Supply Quantity and Rating (W):	1 x 1100
Power Supply Details:	1100W 80Plus Titanium, Dell p/n 450-AKLD
Disk Drive:	1 x 480 GB SSD SATA, Dell p/n 400-BBIE
Disk Controller:	Onboard SATA
# and type of Network Interface Cards (NICs) Installed:	Onboard 1 x Dual Port Intel E810
NICs Enabled in Firmware / OS / Connected:	2/2/1
Network Speed (Mbit):	1000
Keyboard:	None
Mouse:	None
Monitor:	None
Optical Drives:	No
Other Hardware:	None

Software
Power Management:	Power saver power plan enabled in OS
Operating System (OS):	Microsoft Windows Server 2022 Datacenter
OS Version:	Version 21H2(OS Build 20348.1726)
Filesystem:	NTFS
JVM Vendor:	Oracle Corporation
JVM Version:	Java HotSpot(TM) 64-Bit Server VM 18.9(build 11.0.20, mixed mode)
JVM Command-line Options:	-server -Xms3328m -Xmx3584m -Xmn3584m -XX:SurvivorRatio=8 -XX:TargetSurvivorRatio=99 -XX:ParallelGCThreads=2 -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=4 -XX:LoopUnrollLimit=45 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:InlineSmallCode=3900 -XX:MaxInlineSize=270 -XX:FreqInlineSize=2500 -XX:+UseLargePages -XX:+UseParallelOldGC -XX:UseAVX=0 -XX:-UseAdaptiveSizePolicy -XX:-ThreadLocalHandshakes
JVM Affinity:	start /NODE [0,1] /AFFINITY [0x3,0xC,0x30,0xC0,0x300,0xC00,0x3000,0xC000,0x30000,0xC0000,0x300000,0xC00000,0x3000000,0xC000000,0x30000000,0xC0000000]
JVM Instances:	32
JVM Initial Heap (MB):	3584
JVM Maximum Heap (MB):	3584
JVM Address Bits:	64
Boot Firmware Version:	1.0.6
Management Firmware Version:	6.10.80.00 (Build 3)
Workload Version:	SSJ 1.2.10
Director Location:	Controller
Other Software:	None

none

Each JVM instance was bound to 2 logical processors
Using the local security settings console, "lock pages in memory" was enabled for the user running the benchmark
Run initiated via Windows Remote Desktop Connection
Hard Disk set to turn off after 1 minute
Display set to turn off after 1 minute
SPECpower_ssj.props input.load_level.number_warehouses set to 64 due to a known inconsistency in processor reporting with this Java version
Power Plan Minimum processor state set to 0%
Power Plan Maximum processor state set to 100%
Yes: The test sponsor attests, as of date of publication, that CVE-2017-5754 (Meltdown) is mitigated in the system as tested and documented.
Yes: The test sponsor attests, as of date of publication, that CVE-2017-5753 (Spectre variant 1) is mitigated in the system as tested and documented.
Yes: The test sponsor attests, as of date of publication, that CVE-2017-5715 (Spectre variant 2) is mitigated in the system as tested and documented.

Software
Operating System (OS):	Windows Server 2022 Datacenter
JVM Vendor:	Oracle Corporation
JVM Version:	Java HotSpot(TM) 64-Bit Server VM (build 15.0.2+7-27, mixed mode)
CCS Version:	1.2.6

Power Analyzer pwr1
Hardware Vendor:	Yokogawa Meters and Instruments Corporation
Model:	WT210
Serial Number:	91JB09482
Connectivity:	RS-232
Input Connection:	Default
Metrology Institute:	NIST
Accredited by:	TesCom
Calibration Label:	T97126
Date of Calibration:	25-Oct-2022
PTDaemon Host System:	same as CCS
PTDaemon Host OS:	same as CCS
PTDaemon Version:	1.10.0-82175bac-20220817
Setup Description:	Connected to power supply

Temperature Sensor temp1
Hardware Vendor:	Digi International Inc.
Model:	Watchport/H
Driver Version:	6.5.1.0
Connectivity:	USB
PTDaemon Host System:	same as CCS
PTDaemon Host OS:	same as CCS
Setup Description:	25 mm in front of SUT main airflow intake

None

Target Load	Average Active Power (W)	Minimum Ambient Temperature (°C)
100%	256	22.0
90%	244	21.9
80%	231	21.9
70%	219	21.9
60%	209	21.9
50%	198	21.9
40%	186	21.8
30%	171	21.8
20%	155	21.8
10%	145	21.8
Active Idle	124	21.8

Line Standard	Minimum Temperature (°C)	Elevation (m)
208V / 60 Hz / 1 phase / 2 wires	21.8	255

See the Power/Temperature Details Report for additional details.

See the Host Performance Report for additional details.

SPECpower_ssj2008 Reporter Version: [SSJ 1.2.10, May 9, 2012]
