Lenovo Global Technology ThinkSystem SN550 V2 ssj_ops@100% = 5,405,862
ssj_ops@100% per JVM = 84,467
Test Sponsor: Lenovo Global Technology SPEC License #: 9017 Test Method: Multi Node
Tested By: Lenovo Global Technology Test Location: Beijing, China Test Date: Apr 20, 2022
Hardware Availability: Jul-2021 Software Availability: Dec-2019 Publication: May 24, 2022
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     5,406,778
Calibration 2     5,424,446
Calibration 3     5,420,888
ssj_ops@calibrated=5,422,667
100% 99.7% 5,422,667 5,405,862
90% 90.0% 4,880,400 4,877,821
80% 79.8% 4,338,134 4,325,723
70% 70.1% 3,795,867 3,799,477
60% 59.9% 3,253,600 3,248,664
50% 49.9% 2,711,334 2,708,362
40% 39.9% 2,169,067 2,165,928
30% 30.0% 1,626,800 1,628,176
20% 20.0% 1,084,533 1,086,493
10% 10.0% 542,267 543,198
Active Idle   0 0
Graph of results
System Under Test
Set: 'sut'
Set Identifier: sut
Set Description: System Under Test
# of Identical Nodes: 14
Comment: 'SUT'
Hardware
Hardware Vendor: Lenovo Global Technology
Model: ThinkSystem SN550 V2
Form Factor: 10U
CPU Name: Intel Xeon Platinum 8352M
CPU Characteristics: 32 Core, 2.30GHz, 48MB L3 Cache
CPU Frequency (MHz): 2300
CPU(s) Enabled: 64 cores, 2 chips, 32 cores/chip
Hardware Threads: 128 (2 / core)
CPU(s) Orderable: 1,2 chips
Primary Cache: 32 KB I + 48 KB D on chip per core
Secondary Cache: 1280 KB I+D on chip per core
Tertiary Cache: 48 MB I+D on chip per chip
Other Cache: None
Memory Amount (GB): 256
# and size of DIMM: 16 x 16 GB
Memory Details: 16GB 2Rx8 PC4-3200AA-RE2-12-MH1; slots 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15 and 16 for each processor
Power Supply Quantity and Rating (W): None
Power Supply Details: Shared
Disk Drive: 1 x 128GB M.2 SSD P/N:7N47A00130 M.2 Module P/N:4Y37A09738
Disk Controller: Integrated SATA controller
# and type of Network Interface Cards (NICs) Installed: 1 x Flex System CN4052S 2-port 10Gb Virtual Fabric Adapter P/N:00AG540
NICs Enabled in Firmware / OS / Connected: 2/2/1
Network Speed (Mbit): 10000
Keyboard: None
Mouse: None
Monitor: None
Optical Drives: No
Other Hardware: None
Software
Power Management: Enabled (see SUT Notes)
Operating System (OS): Suse Linux Enterprise Server 12 SP5
OS Version: 4.12.14-120-default
Filesystem: btrfs
JVM Vendor: Oracle Corporation
JVM Version: Java HotSpot(TM) 64-Bit Server VM 18.9 (build 11.0.5+10-LTS, mixed mode)
JVM Command-line Options: -server -Xss256k -Xmn1700m -Xms1950m -Xmx1950m -XX:UseSSE=4 -XX:UseAVX=1 -XX:SurvivorRatio=1 -XX:TargetSurvivorRatio=99 -XX:ParallelGCThreads=2 -XX:AllocatePrefetchDistance=256 -XX:AllocatePrefetchLines=4 -XX:LoopUnrollLimit=45 -XX:InitialTenuringThreshold=12 -XX:MaxTenuringThreshold=15 -XX:InlineSmallCode=4000 -XX:MaxInlineSize=300 -XX:FreqInlineSize=2500 -XX:+UseLargePages -XX:+UseParallelOldGC -XX:LargePageSizeInBytes=2m -XX:+UseBiasedLocking -XX:+UseHugeTLBFS -XX:+UseTransparentHugePages
JVM Affinity: for each physicalCore { numactl -C physicalCoreId, physicalCoreId + 1, physicalCoreId + 64, physicalCoreId + 65 }
JVM Instances: 64
JVM Initial Heap (MB): 1950
JVM Maximum Heap (MB): 1950
JVM Address Bits: 64
Boot Firmware Version: U8E115M
Management Firmware Version: TGBT29S
Workload Version: SSJ 1.2.10
Director Location: Controller
Other Software: None
Boot Firmware Settings
Management Firmware Settings
none
System Under Test Notes
Notes
SPECpower_ssj.props input.load_level.number_warehouses set to 128 due to a known inconsistency in processor reporting with this Java version.
JVM Instance Summary
JVM Instance ssj_ops@100%
linux-node8.001 88,077
linux-node8.002 88,068
linux-node8.003 88,733
linux-node8.004 88,118
linux-node8.005 80,572
linux-node8.006 84,002
linux-node8.007 85,099
linux-node8.008 82,827
linux-node8.009 84,098
linux-node8.010 81,944
linux-node8.011 78,178
linux-node8.012 82,089
linux-node8.013 81,184
linux-node8.014 79,620
linux-node8.015 87,421
linux-node8.016 85,935
linux-node8.017 87,665
linux-node8.018 87,143
linux-node8.019 87,141
linux-node8.020 83,153
linux-node8.021 83,806
linux-node8.022 81,764
linux-node8.023 80,597
linux-node8.024 88,236
linux-node8.025 90,028
linux-node8.026 81,783
linux-node8.027 88,069
linux-node8.028 86,234
linux-node8.029 80,134
linux-node8.030 78,959
linux-node8.031 88,069
linux-node8.032 87,024
linux-node8.033 87,686
linux-node8.034 88,022
linux-node8.035 78,952
linux-node8.036 87,002
linux-node8.037 89,635
linux-node8.038 88,387
linux-node8.039 80,012
linux-node8.040 86,026
linux-node8.041 89,354
linux-node8.042 80,313
linux-node8.043 83,893
linux-node8.044 87,145
linux-node8.045 83,859
linux-node8.046 79,127
linux-node8.047 81,262
linux-node8.048 84,455
linux-node8.049 84,470
linux-node8.050 80,719
linux-node8.051 80,565
linux-node8.052 88,880
linux-node8.053 84,046
linux-node8.054 88,039
linux-node8.055 88,092
linux-node8.056 88,498
linux-node8.057 79,914
linux-node8.058 87,444
linux-node8.059 80,020
linux-node8.060 80,605
linux-node8.061 79,017
linux-node8.062 83,456
linux-node8.063 85,759
linux-node8.064 85,438
ssj_ops@100% 5,405,862
ssj_ops@100% per JVM 84,467
Graph of per-instance results
JVM 'linux-node8.001' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     87,069
Calibration 2     88,249
Calibration 3     87,824
ssj_ops@calibrated=88,037
100% 100.0% 88,037 88,077
90% 89.3% 79,233 78,597
80% 80.4% 70,429 70,764
70% 69.8% 61,626 61,410
60% 59.7% 52,822 52,555
50% 49.8% 44,018 43,833
40% 39.4% 35,215 34,723
30% 30.3% 26,411 26,679
20% 20.0% 17,607 17,609
10% 10.1% 8,804 8,887
Active Idle   0 0
Graph of results
JVM 'linux-node8.002' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     87,668
Calibration 2     88,008
Calibration 3     87,908
ssj_ops@calibrated=87,958
100% 100.1% 87,958 88,068
90% 90.8% 79,162 79,832
80% 79.4% 70,366 69,808
70% 69.4% 61,571 61,010
60% 60.0% 52,775 52,785
50% 50.6% 43,979 44,525
40% 40.5% 35,183 35,627
30% 30.1% 26,387 26,469
20% 20.2% 17,592 17,777
10% 10.1% 8,796 8,925
Active Idle   0 0
Graph of results
JVM 'linux-node8.003' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     88,787
Calibration 2     88,491
Calibration 3     88,680
ssj_ops@calibrated=88,585
100% 100.2% 88,585 88,733
90% 89.6% 79,727 79,348
80% 79.7% 70,868 70,604
70% 69.7% 62,010 61,777
60% 59.1% 53,151 52,323
50% 49.6% 44,293 43,908
40% 39.3% 35,434 34,846
30% 30.2% 26,576 26,716
20% 20.0% 17,717 17,723
10% 10.0% 8,859 8,900
Active Idle   0 0
Graph of results
JVM 'linux-node8.004' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     88,418
Calibration 2     88,036
Calibration 3     88,006
ssj_ops@calibrated=88,021
100% 100.1% 88,021 88,118
90% 90.3% 79,219 79,488
80% 79.7% 70,417 70,155
70% 69.4% 61,615 61,119
60% 59.3% 52,813 52,198
50% 49.7% 44,011 43,714
40% 39.5% 35,208 34,798
30% 30.4% 26,406 26,738
20% 20.0% 17,604 17,566
10% 10.2% 8,802 8,946
Active Idle   0 0
Graph of results
JVM 'linux-node8.005' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     79,908
Calibration 2     80,811
Calibration 3     81,272
ssj_ops@calibrated=81,042
100% 99.4% 81,042 80,572
90% 90.5% 72,937 73,335
80% 79.7% 64,833 64,578
70% 69.6% 56,729 56,405
60% 59.8% 48,625 48,484
50% 50.2% 40,521 40,653
40% 40.5% 32,417 32,839
30% 30.9% 24,312 25,070
20% 20.0% 16,208 16,196
10% 10.0% 8,104 8,064
Active Idle   0 0
Graph of results
JVM 'linux-node8.006' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,930
Calibration 2     83,929
Calibration 3     84,084
ssj_ops@calibrated=84,006
100% 100.0% 84,006 84,002
90% 90.2% 75,606 75,778
80% 79.6% 67,205 66,885
70% 70.7% 58,804 59,391
60% 59.9% 50,404 50,298
50% 50.0% 42,003 42,023
40% 40.5% 33,603 34,017
30% 29.9% 25,202 25,083
20% 20.1% 16,801 16,913
10% 9.6% 8,401 8,100
Active Idle   0 0
Graph of results
JVM 'linux-node8.007' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,768
Calibration 2     85,309
Calibration 3     85,720
ssj_ops@calibrated=85,515
100% 99.5% 85,515 85,099
90% 88.8% 76,963 75,918
80% 80.3% 68,412 68,659
70% 70.2% 59,860 60,011
60% 59.7% 51,309 51,032
50% 49.3% 42,757 42,143
40% 40.0% 34,206 34,179
30% 30.3% 25,654 25,911
20% 20.0% 17,103 17,124
10% 9.8% 8,551 8,408
Active Idle   0 0
Graph of results
JVM 'linux-node8.008' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,457
Calibration 2     83,782
Calibration 3     83,609
ssj_ops@calibrated=83,695
100% 99.0% 83,695 82,827
90% 90.1% 75,326 75,410
80% 78.9% 66,956 66,033
70% 69.3% 58,587 58,028
60% 60.3% 50,217 50,488
50% 49.7% 41,848 41,573
40% 40.1% 33,478 33,559
30% 29.9% 25,109 25,035
20% 20.1% 16,739 16,831
10% 9.9% 8,370 8,280
Active Idle   0 0
Graph of results
JVM 'linux-node8.009' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,125
Calibration 2     84,137
Calibration 3     84,185
ssj_ops@calibrated=84,161
100% 99.9% 84,161 84,098
90% 89.7% 75,745 75,505
80% 79.6% 67,329 67,008
70% 69.4% 58,913 58,438
60% 60.3% 50,497 50,741
50% 49.4% 42,080 41,604
40% 40.3% 33,664 33,928
30% 30.8% 25,248 25,896
20% 19.9% 16,832 16,777
10% 10.1% 8,416 8,471
Active Idle   0 0
Graph of results
JVM 'linux-node8.010' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     82,072
Calibration 2     81,945
Calibration 3     81,770
ssj_ops@calibrated=81,858
100% 100.1% 81,858 81,944
90% 89.2% 73,672 72,981
80% 80.0% 65,486 65,499
70% 70.7% 57,300 57,836
60% 59.5% 49,115 48,668
50% 50.6% 40,929 41,416
40% 40.9% 32,743 33,505
30% 30.7% 24,557 25,092
20% 20.6% 16,372 16,863
10% 10.0% 8,186 8,179
Active Idle   0 0
Graph of results
JVM 'linux-node8.011' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     78,433
Calibration 2     78,632
Calibration 3     78,699
ssj_ops@calibrated=78,665
100% 99.4% 78,665 78,178
90% 89.5% 70,799 70,439
80% 79.3% 62,932 62,421
70% 69.9% 55,066 54,958
60% 60.3% 47,199 47,442
50% 49.9% 39,333 39,250
40% 39.3% 31,466 30,919
30% 30.9% 23,600 24,269
20% 19.9% 15,733 15,685
10% 10.3% 7,867 8,087
Active Idle   0 0
Graph of results
JVM 'linux-node8.012' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,946
Calibration 2     82,049
Calibration 3     82,001
ssj_ops@calibrated=82,025
100% 100.1% 82,025 82,089
90% 89.5% 73,822 73,441
80% 79.8% 65,620 65,461
70% 70.7% 57,417 57,972
60% 58.5% 49,215 48,012
50% 50.0% 41,012 40,979
40% 39.7% 32,810 32,604
30% 30.3% 24,607 24,865
20% 19.9% 16,405 16,311
10% 10.0% 8,202 8,179
Active Idle   0 0
Graph of results
JVM 'linux-node8.013' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,050
Calibration 2     81,146
Calibration 3     80,883
ssj_ops@calibrated=81,015
100% 100.2% 81,015 81,184
90% 90.4% 72,913 73,249
80% 79.4% 64,812 64,291
70% 70.6% 56,710 57,221
60% 59.7% 48,609 48,347
50% 49.3% 40,507 39,917
40% 39.5% 32,406 32,001
30% 30.2% 24,304 24,444
20% 19.9% 16,203 16,137
10% 9.8% 8,101 7,917
Active Idle   0 0
Graph of results
JVM 'linux-node8.014' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     79,010
Calibration 2     79,832
Calibration 3     79,913
ssj_ops@calibrated=79,873
100% 99.7% 79,873 79,620
90% 90.7% 71,885 72,477
80% 80.3% 63,898 64,108
70% 69.9% 55,911 55,865
60% 60.5% 47,924 48,349
50% 50.4% 39,936 40,260
40% 39.5% 31,949 31,551
30% 30.3% 23,962 24,183
20% 19.9% 15,975 15,922
10% 9.8% 7,987 7,867
Active Idle   0 0
Graph of results
JVM 'linux-node8.015' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,848
Calibration 2     87,596
Calibration 3     87,902
ssj_ops@calibrated=87,749
100% 99.6% 87,749 87,421
90% 89.2% 78,974 78,238
80% 79.9% 70,199 70,153
70% 69.7% 61,424 61,163
60% 59.8% 52,649 52,474
50% 50.1% 43,875 43,921
40% 40.8% 35,100 35,807
30% 30.6% 26,325 26,852
20% 20.7% 17,550 18,145
10% 10.0% 8,775 8,808
Active Idle   0 0
Graph of results
JVM 'linux-node8.016' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,498
Calibration 2     86,156
Calibration 3     86,124
ssj_ops@calibrated=86,140
100% 99.8% 86,140 85,935
90% 89.7% 77,526 77,265
80% 80.6% 68,912 69,439
70% 70.3% 60,298 60,543
60% 60.0% 51,684 51,643
50% 50.1% 43,070 43,155
40% 40.3% 34,456 34,751
30% 30.2% 25,842 26,057
20% 19.8% 17,228 17,083
10% 9.8% 8,614 8,441
Active Idle   0 0
Graph of results
JVM 'linux-node8.017' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     87,941
Calibration 2     87,949
Calibration 3     88,004
ssj_ops@calibrated=87,976
100% 99.6% 87,976 87,665
90% 89.9% 79,179 79,108
80% 80.1% 70,381 70,487
70% 69.8% 61,583 61,419
60% 59.9% 52,786 52,689
50% 49.8% 43,988 43,814
40% 39.8% 35,190 34,981
30% 30.3% 26,393 26,649
20% 20.1% 17,595 17,658
10% 10.0% 8,798 8,837
Active Idle   0 0
Graph of results
JVM 'linux-node8.018' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,371
Calibration 2     87,261
Calibration 3     87,251
ssj_ops@calibrated=87,256
100% 99.9% 87,256 87,143
90% 90.0% 78,530 78,537
80% 80.0% 69,805 69,817
70% 70.2% 61,079 61,278
60% 60.4% 52,354 52,689
50% 50.1% 43,628 43,710
40% 40.6% 34,902 35,414
30% 29.8% 26,177 25,979
20% 20.1% 17,451 17,540
10% 10.3% 8,726 9,017
Active Idle   0 0
Graph of results
JVM 'linux-node8.019' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     87,194
Calibration 2     87,532
Calibration 3     87,226
ssj_ops@calibrated=87,379
100% 99.7% 87,379 87,141
90% 89.0% 78,641 77,726
80% 79.7% 69,903 69,684
70% 69.5% 61,165 60,735
60% 59.5% 52,427 51,961
50% 50.7% 43,690 44,341
40% 40.2% 34,952 35,164
30% 29.7% 26,214 25,994
20% 20.2% 17,476 17,644
10% 10.2% 8,738 8,905
Active Idle   0 0
Graph of results
JVM 'linux-node8.020' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     82,735
Calibration 2     83,521
Calibration 3     82,674
ssj_ops@calibrated=83,098
100% 100.1% 83,098 83,153
90% 90.3% 74,788 75,011
80% 80.4% 66,478 66,777
70% 70.1% 58,168 58,217
60% 59.3% 49,859 49,271
50% 49.9% 41,549 41,493
40% 40.6% 33,239 33,729
30% 30.6% 24,929 25,465
20% 20.3% 16,620 16,858
10% 9.9% 8,310 8,233
Active Idle   0 0
Graph of results
JVM 'linux-node8.021' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,282
Calibration 2     84,386
Calibration 3     84,178
ssj_ops@calibrated=84,282
100% 99.4% 84,282 83,806
90% 89.4% 75,854 75,390
80% 79.6% 67,426 67,056
70% 70.1% 58,998 59,068
60% 60.0% 50,569 50,584
50% 49.9% 42,141 42,022
40% 40.3% 33,713 33,964
30% 29.9% 25,285 25,186
20% 20.2% 16,856 17,027
10% 10.0% 8,428 8,463
Active Idle   0 0
Graph of results
JVM 'linux-node8.022' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,016
Calibration 2     81,393
Calibration 3     81,548
ssj_ops@calibrated=81,470
100% 100.4% 81,470 81,764
90% 90.3% 73,323 73,572
80% 79.9% 65,176 65,124
70% 70.2% 57,029 57,167
60% 60.5% 48,882 49,251
50% 50.5% 40,735 41,121
40% 40.1% 32,588 32,666
30% 29.9% 24,441 24,331
20% 20.3% 16,294 16,516
10% 10.3% 8,147 8,386
Active Idle   0 0
Graph of results
JVM 'linux-node8.023' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,695
Calibration 2     81,347
Calibration 3     81,120
ssj_ops@calibrated=81,234
100% 99.2% 81,234 80,597
90% 90.1% 73,110 73,198
80% 79.5% 64,987 64,612
70% 69.8% 56,864 56,681
60% 59.9% 48,740 48,651
50% 50.1% 40,617 40,685
40% 39.8% 32,493 32,336
30% 29.7% 24,370 24,150
20% 20.2% 16,247 16,398
10% 10.4% 8,123 8,471
Active Idle   0 0
Graph of results
JVM 'linux-node8.024' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     89,311
Calibration 2     89,162
Calibration 3     89,100
ssj_ops@calibrated=89,131
100% 99.0% 89,131 88,236
90% 90.3% 80,218 80,470
80% 80.0% 71,305 71,309
70% 71.3% 62,392 63,586
60% 60.1% 53,479 53,555
50% 50.7% 44,566 45,171
40% 40.4% 35,653 36,034
30% 29.9% 26,739 26,681
20% 19.9% 17,826 17,707
10% 10.2% 8,913 9,075
Active Idle   0 0
Graph of results
JVM 'linux-node8.025' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     89,964
Calibration 2     89,847
Calibration 3     89,756
ssj_ops@calibrated=89,801
100% 100.3% 89,801 90,028
90% 90.7% 80,821 81,444
80% 80.1% 71,841 71,949
70% 69.3% 62,861 62,241
60% 59.8% 53,881 53,695
50% 49.6% 44,901 44,522
40% 40.0% 35,921 35,921
30% 30.1% 26,940 26,992
20% 20.2% 17,960 18,121
10% 9.7% 8,980 8,720
Active Idle   0 0
Graph of results
JVM 'linux-node8.026' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,832
Calibration 2     82,511
Calibration 3     82,589
ssj_ops@calibrated=82,550
100% 99.1% 82,550 81,783
90% 89.6% 74,295 73,985
80% 80.1% 66,040 66,097
70% 70.0% 57,785 57,793
60% 60.2% 49,530 49,697
50% 50.3% 41,275 41,524
40% 40.0% 33,020 32,990
30% 30.2% 24,765 24,966
20% 19.9% 16,510 16,445
10% 10.1% 8,255 8,354
Active Idle   0 0
Graph of results
JVM 'linux-node8.027' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     88,639
Calibration 2     88,427
Calibration 3     88,424
ssj_ops@calibrated=88,426
100% 99.6% 88,426 88,069
90% 90.4% 79,583 79,938
80% 79.9% 70,741 70,632
70% 69.9% 61,898 61,792
60% 60.3% 53,055 53,287
50% 50.4% 44,213 44,523
40% 39.6% 35,370 35,029
30% 29.4% 26,528 26,030
20% 19.8% 17,685 17,487
10% 9.9% 8,843 8,783
Active Idle   0 0
Graph of results
JVM 'linux-node8.028' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,898
Calibration 2     86,717
Calibration 3     86,444
ssj_ops@calibrated=86,581
100% 99.6% 86,581 86,234
90% 90.8% 77,923 78,593
80% 79.6% 69,264 68,960
70% 70.7% 60,606 61,211
60% 60.1% 51,948 52,000
50% 49.6% 43,290 42,975
40% 39.8% 34,632 34,419
30% 29.9% 25,974 25,888
20% 19.8% 17,316 17,149
10% 10.3% 8,658 8,933
Active Idle   0 0
Graph of results
JVM 'linux-node8.029' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,646
Calibration 2     80,819
Calibration 3     80,585
ssj_ops@calibrated=80,702
100% 99.3% 80,702 80,134
90% 89.7% 72,632 72,362
80% 80.0% 64,562 64,592
70% 69.5% 56,491 56,099
60% 59.7% 48,421 48,184
50% 50.7% 40,351 40,887
40% 40.0% 32,281 32,310
30% 29.4% 24,211 23,761
20% 19.8% 16,140 15,968
10% 9.9% 8,070 7,971
Active Idle   0 0
Graph of results
JVM 'linux-node8.030' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     78,231
Calibration 2     78,906
Calibration 3     79,004
ssj_ops@calibrated=78,955
100% 100.0% 78,955 78,959
90% 90.3% 71,059 71,278
80% 79.6% 63,164 62,852
70% 70.8% 55,268 55,909
60% 59.2% 47,373 46,756
50% 50.0% 39,477 39,510
40% 40.4% 31,582 31,888
30% 30.7% 23,686 24,243
20% 20.4% 15,791 16,073
10% 9.8% 7,895 7,755
Active Idle   0 0
Graph of results
JVM 'linux-node8.031' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     88,885
Calibration 2     88,295
Calibration 3     88,015
ssj_ops@calibrated=88,155
100% 99.9% 88,155 88,069
90% 89.9% 79,339 79,220
80% 79.8% 70,524 70,359
70% 70.2% 61,708 61,883
60% 60.4% 52,893 53,227
50% 50.2% 44,077 44,211
40% 40.2% 35,262 35,464
30% 29.7% 26,446 26,164
20% 20.1% 17,631 17,712
10% 9.8% 8,815 8,637
Active Idle   0 0
Graph of results
JVM 'linux-node8.032' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     87,068
Calibration 2     87,172
Calibration 3     87,393
ssj_ops@calibrated=87,282
100% 99.7% 87,282 87,024
90% 89.2% 78,554 77,883
80% 79.8% 69,826 69,642
70% 69.8% 61,098 60,961
60% 59.2% 52,369 51,636
50% 49.8% 43,641 43,453
40% 39.9% 34,913 34,806
30% 30.1% 26,185 26,233
20% 20.1% 17,456 17,513
10% 9.9% 8,728 8,637
Active Idle   0 0
Graph of results
JVM 'linux-node8.033' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     88,000
Calibration 2     87,743
Calibration 3     87,541
ssj_ops@calibrated=87,642
100% 100.1% 87,642 87,686
90% 89.4% 78,878 78,376
80% 80.6% 70,113 70,636
70% 69.5% 61,349 60,911
60% 60.8% 52,585 53,297
50% 49.2% 43,821 43,117
40% 39.8% 35,057 34,874
30% 29.5% 26,293 25,896
20% 19.7% 17,528 17,274
10% 10.0% 8,764 8,806
Active Idle   0 0
Graph of results
JVM 'linux-node8.034' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     88,798
Calibration 2     89,095
Calibration 3     89,359
ssj_ops@calibrated=89,227
100% 98.7% 89,227 88,022
90% 90.0% 80,304 80,329
80% 81.2% 71,381 72,486
70% 69.5% 62,459 61,968
60% 59.7% 53,536 53,250
50% 49.5% 44,613 44,143
40% 39.9% 35,691 35,593
30% 29.5% 26,768 26,312
20% 19.9% 17,845 17,763
10% 9.8% 8,923 8,717
Active Idle   0 0
Graph of results
JVM 'linux-node8.035' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     79,883
Calibration 2     79,872
Calibration 3     79,641
ssj_ops@calibrated=79,756
100% 99.0% 79,756 78,952
90% 90.1% 71,781 71,895
80% 79.7% 63,805 63,571
70% 69.9% 55,829 55,752
60% 59.7% 47,854 47,633
50% 49.7% 39,878 39,654
40% 40.6% 31,902 32,396
30% 30.4% 23,927 24,217
20% 19.7% 15,951 15,741
10% 10.5% 7,976 8,371
Active Idle   0 0
Graph of results
JVM 'linux-node8.036' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     87,256
Calibration 2     87,519
Calibration 3     87,476
ssj_ops@calibrated=87,497
100% 99.4% 87,497 87,002
90% 88.6% 78,748 77,555
80% 79.3% 69,998 69,418
70% 69.4% 61,248 60,727
60% 59.7% 52,498 52,259
50% 49.3% 43,749 43,155
40% 39.4% 34,999 34,431
30% 30.4% 26,249 26,561
20% 20.3% 17,499 17,760
10% 9.8% 8,750 8,546
Active Idle   0 0
Graph of results
JVM 'linux-node8.037' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     89,488
Calibration 2     89,940
Calibration 3     89,868
ssj_ops@calibrated=89,904
100% 99.7% 89,904 89,635
90% 88.9% 80,914 79,955
80% 80.2% 71,923 72,068
70% 69.8% 62,933 62,762
60% 59.6% 53,942 53,559
50% 50.1% 44,952 45,038
40% 40.4% 35,962 36,360
30% 30.1% 26,971 27,054
20% 20.2% 17,981 18,148
10% 10.3% 8,990 9,304
Active Idle   0 0
Graph of results
JVM 'linux-node8.038' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     89,362
Calibration 2     89,586
Calibration 3     89,531
ssj_ops@calibrated=89,559
100% 98.7% 89,559 88,387
90% 90.1% 80,603 80,668
80% 79.9% 71,647 71,548
70% 68.7% 62,691 61,548
60% 59.7% 53,735 53,471
50% 50.5% 44,779 45,216
40% 39.7% 35,824 35,570
30% 30.3% 26,868 27,156
20% 20.1% 17,912 17,973
10% 9.9% 8,956 8,841
Active Idle   0 0
Graph of results
JVM 'linux-node8.039' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,522
Calibration 2     80,160
Calibration 3     80,055
ssj_ops@calibrated=80,108
100% 99.9% 80,108 80,012
90% 90.7% 72,097 72,659
80% 79.0% 64,086 63,257
70% 70.6% 56,075 56,536
60% 59.5% 48,065 47,655
50% 49.3% 40,054 39,479
40% 40.1% 32,043 32,110
30% 29.9% 24,032 23,950
20% 20.0% 16,022 15,986
10% 10.1% 8,011 8,054
Active Idle   0 0
Graph of results
JVM 'linux-node8.040' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     85,225
Calibration 2     85,891
Calibration 3     85,916
ssj_ops@calibrated=85,903
100% 100.1% 85,903 86,026
90% 91.1% 77,313 78,267
80% 80.1% 68,723 68,839
70% 69.6% 60,132 59,788
60% 60.6% 51,542 52,049
50% 50.1% 42,952 43,060
40% 39.3% 34,361 33,790
30% 30.4% 25,771 26,079
20% 20.4% 17,181 17,537
10% 10.2% 8,590 8,783
Active Idle   0 0
Graph of results
JVM 'linux-node8.041' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     89,595
Calibration 2     89,552
Calibration 3     89,622
ssj_ops@calibrated=89,587
100% 99.7% 89,587 89,354
90% 90.9% 80,628 81,430
80% 79.3% 71,670 70,998
70% 70.8% 62,711 63,399
60% 60.2% 53,752 53,906
50% 50.3% 44,794 45,078
40% 39.8% 35,835 35,613
30% 30.3% 26,876 27,157
20% 20.2% 17,917 18,108
10% 10.4% 8,959 9,347
Active Idle   0 0
Graph of results
JVM 'linux-node8.042' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,045
Calibration 2     80,149
Calibration 3     79,996
ssj_ops@calibrated=80,072
100% 100.3% 80,072 80,313
90% 90.1% 72,065 72,110
80% 79.9% 64,058 63,968
70% 70.5% 56,051 56,437
60% 59.8% 48,043 47,865
50% 49.7% 40,036 39,792
40% 39.9% 32,029 31,916
30% 30.2% 24,022 24,153
20% 20.1% 16,014 16,102
10% 10.0% 8,007 7,983
Active Idle   0 0
Graph of results
JVM 'linux-node8.043' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,242
Calibration 2     85,172
Calibration 3     84,770
ssj_ops@calibrated=84,971
100% 98.7% 84,971 83,893
90% 88.9% 76,474 75,525
80% 80.0% 67,977 67,998
70% 71.0% 59,480 60,301
60% 59.9% 50,982 50,860
50% 50.2% 42,485 42,652
40% 39.9% 33,988 33,867
30% 30.4% 25,491 25,810
20% 20.1% 16,994 17,104
10% 9.6% 8,497 8,192
Active Idle   0 0
Graph of results
JVM 'linux-node8.044' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,315
Calibration 2     87,532
Calibration 3     87,512
ssj_ops@calibrated=87,522
100% 99.6% 87,522 87,145
90% 90.4% 78,770 79,138
80% 80.2% 70,017 70,184
70% 70.2% 61,265 61,411
60% 61.3% 52,513 53,649
50% 50.2% 43,761 43,956
40% 39.5% 35,009 34,542
30% 30.3% 26,257 26,548
20% 20.0% 17,504 17,499
10% 10.2% 8,752 8,914
Active Idle   0 0
Graph of results
JVM 'linux-node8.045' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,049
Calibration 2     83,762
Calibration 3     83,786
ssj_ops@calibrated=83,774
100% 100.1% 83,774 83,859
90% 90.4% 75,397 75,690
80% 80.3% 67,019 67,302
70% 69.7% 58,642 58,414
60% 59.7% 50,264 49,996
50% 50.5% 41,887 42,295
40% 40.3% 33,510 33,783
30% 30.0% 25,132 25,140
20% 20.3% 16,755 16,976
10% 10.0% 8,377 8,377
Active Idle   0 0
Graph of results
JVM 'linux-node8.046' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     79,144
Calibration 2     79,140
Calibration 3     78,874
ssj_ops@calibrated=79,007
100% 100.2% 79,007 79,127
90% 90.4% 71,106 71,398
80% 80.1% 63,205 63,308
70% 70.2% 55,305 55,492
60% 60.1% 47,404 47,491
50% 50.8% 39,503 40,133
40% 39.2% 31,603 30,977
30% 29.2% 23,702 23,041
20% 19.7% 15,801 15,601
10% 10.4% 7,901 8,187
Active Idle   0 0
Graph of results
JVM 'linux-node8.047' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     81,516
Calibration 2     81,227
Calibration 3     81,270
ssj_ops@calibrated=81,248
100% 100.0% 81,248 81,262
90% 90.4% 73,124 73,413
80% 79.5% 64,999 64,590
70% 70.0% 56,874 56,849
60% 60.1% 48,749 48,844
50% 49.4% 40,624 40,176
40% 39.8% 32,499 32,319
30% 29.8% 24,375 24,220
20% 19.9% 16,250 16,162
10% 10.1% 8,125 8,222
Active Idle   0 0
Graph of results
JVM 'linux-node8.048' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,308
Calibration 2     84,881
Calibration 3     84,796
ssj_ops@calibrated=84,838
100% 99.5% 84,838 84,455
90% 90.1% 76,354 76,419
80% 79.3% 67,871 67,263
70% 70.5% 59,387 59,780
60% 59.2% 50,903 50,203
50% 50.5% 42,419 42,828
40% 39.6% 33,935 33,624
30% 29.0% 25,451 24,576
20% 19.4% 16,968 16,420
10% 10.0% 8,484 8,525
Active Idle   0 0
Graph of results
JVM 'linux-node8.049' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,953
Calibration 2     84,472
Calibration 3     84,468
ssj_ops@calibrated=84,470
100% 100.0% 84,470 84,470
90% 89.6% 76,023 75,651
80% 79.6% 67,576 67,253
70% 70.9% 59,129 59,849
60% 59.2% 50,682 49,971
50% 48.7% 42,235 41,134
40% 39.9% 33,788 33,739
30% 29.6% 25,341 24,984
20% 19.9% 16,894 16,798
10% 10.2% 8,447 8,575
Active Idle   0 0
Graph of results
JVM 'linux-node8.050' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,892
Calibration 2     80,910
Calibration 3     80,865
ssj_ops@calibrated=80,888
100% 99.8% 80,888 80,719
90% 89.3% 72,799 72,192
80% 79.8% 64,710 64,527
70% 70.5% 56,621 57,063
60% 60.7% 48,533 49,096
50% 50.1% 40,444 40,510
40% 40.3% 32,355 32,608
30% 30.0% 24,266 24,283
20% 20.3% 16,178 16,389
10% 9.5% 8,089 7,664
Active Idle   0 0
Graph of results
JVM 'linux-node8.051' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,321
Calibration 2     80,310
Calibration 3     80,064
ssj_ops@calibrated=80,187
100% 100.5% 80,187 80,565
90% 90.4% 72,168 72,509
80% 79.0% 64,149 63,316
70% 69.9% 56,131 56,058
60% 61.2% 48,112 49,079
50% 50.6% 40,093 40,593
40% 39.9% 32,075 31,975
30% 29.7% 24,056 23,828
20% 19.7% 16,037 15,792
10% 10.1% 8,019 8,104
Active Idle   0 0
Graph of results
JVM 'linux-node8.052' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     88,896
Calibration 2     89,017
Calibration 3     88,821
ssj_ops@calibrated=88,919
100% 100.0% 88,919 88,880
90% 89.6% 80,027 79,654
80% 79.9% 71,135 71,016
70% 70.1% 62,243 62,376
60% 59.3% 53,351 52,712
50% 50.0% 44,459 44,480
40% 39.4% 35,568 35,035
30% 29.8% 26,676 26,531
20% 19.9% 17,784 17,701
10% 10.1% 8,892 8,969
Active Idle   0 0
Graph of results
JVM 'linux-node8.053' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,020
Calibration 2     83,981
Calibration 3     83,864
ssj_ops@calibrated=83,923
100% 100.1% 83,923 84,046
90% 89.8% 75,530 75,374
80% 80.0% 67,138 67,107
70% 70.2% 58,746 58,887
60% 60.3% 50,354 50,575
50% 50.3% 41,961 42,200
40% 39.7% 33,569 33,315
30% 30.5% 25,177 25,589
20% 19.8% 16,785 16,651
10% 10.3% 8,392 8,625
Active Idle   0 0
Graph of results
JVM 'linux-node8.054' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     88,952
Calibration 2     89,047
Calibration 3     89,039
ssj_ops@calibrated=89,043
100% 98.9% 89,043 88,039
90% 89.3% 80,139 79,553
80% 79.4% 71,234 70,735
70% 70.5% 62,330 62,813
60% 59.8% 53,426 53,252
50% 49.2% 44,522 43,805
40% 39.7% 35,617 35,349
30% 30.2% 26,713 26,934
20% 20.1% 17,809 17,920
10% 9.8% 8,904 8,754
Active Idle   0 0
Graph of results
JVM 'linux-node8.055' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     87,932
Calibration 2     89,222
Calibration 3     89,284
ssj_ops@calibrated=89,253
100% 98.7% 89,253 88,092
90% 90.7% 80,328 80,918
80% 79.7% 71,402 71,105
70% 69.9% 62,477 62,419
60% 60.1% 53,552 53,619
50% 50.1% 44,627 44,721
40% 39.1% 35,701 34,902
30% 29.8% 26,776 26,564
20% 19.8% 17,851 17,711
10% 9.8% 8,925 8,724
Active Idle   0 0
Graph of results
JVM 'linux-node8.056' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     89,763
Calibration 2     89,581
Calibration 3     89,340
ssj_ops@calibrated=89,460
100% 98.9% 89,460 88,498
90% 90.5% 80,514 80,971
80% 79.8% 71,568 71,403
70% 70.6% 62,622 63,180
60% 60.1% 53,676 53,769
50% 50.1% 44,730 44,849
40% 40.4% 35,784 36,111
30% 29.1% 26,838 26,038
20% 19.6% 17,892 17,517
10% 10.1% 8,946 9,025
Active Idle   0 0
Graph of results
JVM 'linux-node8.057' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     79,550
Calibration 2     80,292
Calibration 3     80,684
ssj_ops@calibrated=80,488
100% 99.3% 80,488 79,914
90% 90.1% 72,439 72,493
80% 79.8% 64,391 64,234
70% 69.0% 56,342 55,546
60% 60.1% 48,293 48,399
50% 49.8% 40,244 40,084
40% 40.2% 32,195 32,377
30% 29.5% 24,146 23,726
20% 20.1% 16,098 16,204
10% 9.7% 8,049 7,842
Active Idle   0 0
Graph of results
JVM 'linux-node8.058' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,994
Calibration 2     87,560
Calibration 3     87,634
ssj_ops@calibrated=87,597
100% 99.8% 87,597 87,444
90% 90.0% 78,837 78,804
80% 79.2% 70,078 69,374
70% 70.9% 61,318 62,103
60% 59.3% 52,558 51,906
50% 49.6% 43,799 43,481
40% 40.0% 35,039 35,056
30% 29.9% 26,279 26,171
20% 20.2% 17,519 17,734
10% 9.8% 8,760 8,621
Active Idle   0 0
Graph of results
JVM 'linux-node8.059' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,594
Calibration 2     80,382
Calibration 3     80,286
ssj_ops@calibrated=80,334
100% 99.6% 80,334 80,020
90% 90.1% 72,301 72,389
80% 79.2% 64,267 63,651
70% 69.9% 56,234 56,174
60% 59.3% 48,200 47,631
50% 49.5% 40,167 39,800
40% 40.1% 32,134 32,243
30% 30.2% 24,100 24,258
20% 19.6% 16,067 15,775
10% 10.4% 8,033 8,371
Active Idle   0 0
Graph of results
JVM 'linux-node8.060' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     80,494
Calibration 2     80,634
Calibration 3     80,435
ssj_ops@calibrated=80,535
100% 100.1% 80,535 80,605
90% 89.5% 72,481 72,069
80% 79.8% 64,428 64,247
70% 70.4% 56,374 56,689
60% 60.3% 48,321 48,543
50% 50.4% 40,267 40,629
40% 39.6% 32,214 31,918
30% 29.4% 24,160 23,700
20% 19.9% 16,107 16,057
10% 9.6% 8,053 7,767
Active Idle   0 0
Graph of results
JVM 'linux-node8.061' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     78,620
Calibration 2     79,050
Calibration 3     79,168
ssj_ops@calibrated=79,109
100% 99.9% 79,109 79,017
90% 90.0% 71,198 71,204
80% 79.2% 63,287 62,668
70% 69.6% 55,376 55,031
60% 60.4% 47,465 47,814
50% 49.3% 39,555 38,977
40% 39.9% 31,644 31,530
30% 29.5% 23,733 23,328
20% 20.2% 15,822 16,002
10% 10.0% 7,911 7,912
Active Idle   0 0
Graph of results
JVM 'linux-node8.062' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     83,231
Calibration 2     83,548
Calibration 3     83,268
ssj_ops@calibrated=83,408
100% 100.1% 83,408 83,456
90% 90.4% 75,067 75,429
80% 78.9% 66,726 65,796
70% 70.3% 58,386 58,612
60% 60.3% 50,045 50,268
50% 49.3% 41,704 41,086
40% 39.6% 33,363 33,001
30% 30.5% 25,022 25,419
20% 20.6% 16,682 17,192
10% 10.1% 8,341 8,465
Active Idle   0 0
Graph of results
JVM 'linux-node8.063' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     86,365
Calibration 2     86,102
Calibration 3     85,923
ssj_ops@calibrated=86,012
100% 99.7% 86,012 85,759
90% 90.1% 77,411 77,492
80% 78.7% 68,810 67,706
70% 71.3% 60,208 61,334
60% 59.3% 51,607 51,005
50% 49.8% 43,006 42,814
40% 39.3% 34,405 33,819
30% 29.4% 25,804 25,249
20% 19.9% 17,202 17,112
10% 10.0% 8,601 8,637
Active Idle   0 0
Graph of results
JVM 'linux-node8.064' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     84,762
Calibration 2     85,765
Calibration 3     85,842
ssj_ops@calibrated=85,804
100% 99.6% 85,804 85,438
90% 90.1% 77,223 77,274
80% 79.6% 68,643 68,335
70% 70.0% 60,063 60,077
60% 60.7% 51,482 52,061
50% 49.6% 42,902 42,592
40% 40.1% 34,321 34,415
30% 29.9% 25,741 25,630
20% 20.2% 17,161 17,303
10% 9.7% 8,580 8,333
Active Idle   0 0
Graph of results
