Hewlett Packard Enterprise Synergy 480 Gen10 Plus Compute Module SPECpower_ssj2008 = 11,291 overall ssj_ops/watt
Test Sponsor: Hewlett Packard Enterprise SPEC License #: 3 Test Method: Multi Node
Tested By: Hewlett Packard Enterprise Test Location: Houston, TX, USA Test Date: Jan 14, 2022
Hardware Availability: Apr-2021 Software Availability: Apr-2021 Publication: Feb 16, 2022
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Average Active Power (W) Minimum Ambient Temperature (°C)
Calibration 1 2,655 26.3
Calibration 2 3,365 26.2
Calibration 3 3,372 26.4
100% 3,370 26.7
90% 3,080 26.8
80% 2,363 26.7
70% 2,088 26.7
60% 1,839 26.8
50% 1,651 26.8
40% 1,496 26.6
30% 1,364 26.6
20% 1,225 26.6
10% 1,078 26.6
Active Idle 897 26.7
Graph of power and temperature
Measurement Devices
Power Analyzer pwr1
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91GB47168
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-F673T-80-1
Date of Calibration: 14-May-2021
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.9.2-3976349f-20201208
Setup Description: SUT Power Supplies 1 and 2
Power Analyzer pwr2
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91GB47169
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-F91A5-220-1
Date of Calibration: 26-Jun-2021
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.9.2-3976349f-20201208
Setup Description: SUT Power Supply 4
Power Analyzer pwr3
Hardware Vendor: Yokogawa
Model: WT210
Serial Number: 91K112854
Connectivity: GPIB vi NI GPIB-USB-HS
Input Connection: Default
Metrology Institute: NIST
Accredited by: TRANSCAT
Calibration Label: 5-F673T-40-1
Date of Calibration: 15-May-2021
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
PTDaemon Version: 1.9.2-3976349f-20201208
Setup Description: SUT Power Supply 6
Temperature Sensor temp1
Hardware Vendor: Digi International Inc.
Model: Watchport/H
Driver Version: 5.70.105.0
Connectivity: USB
PTDaemon Host System: same as CCS
PTDaemon Host OS: same as CCS
Setup Description: 5 mm in front of SUT main intake
Notes
None
Power Details for Device pwr1
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 215 300.0 4.36 10.0 0.984 899 0.5%
Calibration 2 215 300.0 5.33 10.0 0.992 1,136 0.4%
Calibration 3 215 300.0 5.34 10.0 0.992 1,138 0.4%
100% 215 300.0 5.34 10.0 0.992 1,137 0.4%
90% 215 300.0 4.89 10.0 0.990 1,042 0.5%
80% 215 300.0 3.78 10.0 0.984 797 0.6%
70% 215 300.0 3.35 10.0 0.980 705 0.6%
60% 215 300.0 2.99 5.0 0.975 627 0.4%
50% 215 300.0 2.71 5.0 0.971 566 0.5%
40% 215 300.0 2.52 5.0 0.965 524 0.5%
30% 215 300.0 2.31 5.0 0.953 473 0.5%
20% 215 300.0 2.03 5.0 0.936 407 0.6%
10% 215 300.0 1.75 5.0 0.911 342 0.7%
Active Idle 215 300.0 1.56 2.0 0.916 306 0.4%
Power details for pwr1
Power Details for Device pwr2
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 213 300.0 4.28 10.0 0.959 852 0.6%
Calibration 2 213 300.0 5.25 10.0 0.977 1,092 0.5%
Calibration 3 213 300.0 5.26 10.0 0.977 1,094 0.5%
100% 213 300.0 5.25 10.0 0.977 1,093 0.5%
90% 213 300.0 4.83 10.0 0.973 998 0.5%
80% 212 300.0 3.75 5.0 0.958 759 0.4%
70% 212 300.0 3.30 5.0 0.949 662 0.4%
60% 212 300.0 2.88 5.0 0.938 572 0.5%
50% 212 300.0 2.57 5.0 0.927 504 0.5%
40% 212 300.0 2.27 5.0 0.912 440 0.6%
30% 212 300.0 2.14 5.0 0.901 409 0.6%
20% 212 300.0 1.99 2.0 0.892 377 0.4%
10% 212 300.0 1.86 2.0 0.880 347 0.4%
Active Idle 212 300.0 1.39 2.0 0.845 249 0.5%
Power details for pwr2
Power Details for Device pwr3
Target Load Voltage (V) Current (A) Avg Power Factor Avg Active Power (W) Power Measurement Uncertainty (%)
Avg Range Avg Range
Calibration 1 215 300.0 4.39 10.0 0.979 904 0.5%
Calibration 2 215 300.0 5.35 10.0 0.989 1,138 0.4%
Calibration 3 215 300.0 5.36 10.0 0.989 1,140 0.4%
100% 215 300.0 5.36 10.0 0.989 1,140 0.4%
90% 215 300.0 4.89 10.0 0.987 1,040 0.5%
80% 215 300.0 3.84 10.0 0.979 807 0.6%
70% 215 300.0 3.45 5.0 0.974 721 0.4%
60% 215 300.0 3.08 5.0 0.968 640 0.4%
50% 215 300.0 2.81 5.0 0.962 581 0.5%
40% 215 300.0 2.60 5.0 0.953 532 0.5%
30% 215 300.0 2.39 5.0 0.939 483 0.5%
20% 215 300.0 2.21 5.0 0.927 441 0.6%
10% 215 300.0 2.00 5.0 0.907 389 0.6%
Active Idle 215 300.0 1.77 2.0 0.898 342 0.4%
Power details for pwr3
