Hewlett Packard Enterprise Apollo XL225n Gen10 Plus ssj_ops@100% = 10,924,860
ssj_ops@100% per JVM = 170,701
Test Sponsor: Hewlett Packard Enterprise SPEC License #: 3 Test Method: Multi Node
Tested By: Hewlett Packard Enterprise Test Location: Houston, TX, USA Test Date: Apr 6, 2020
Hardware Availability: Jun-2020 Software Availability: Mar-2020 Publication: Apr 22, 2020
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     10,984,711
Calibration 2     10,970,815
Calibration 3     10,977,817
ssj_ops@calibrated=10,974,316
100% 99.5% 10,974,316 10,924,860
90% 90.0% 9,876,884 9,881,074
80% 80.0% 8,779,453 8,781,857
70% 70.1% 7,682,021 7,688,846
60% 59.9% 6,584,590 6,578,753
50% 50.0% 5,487,158 5,486,679
40% 40.0% 4,389,726 4,391,387
30% 30.0% 3,292,295 3,290,431
20% 20.1% 2,194,863 2,200,641
10% 10.0% 1,097,432 1,098,454
Active Idle   0 0
Graph of results
System Under Test
Set: 'SUT'
Set Identifier: SUT
Set Description: System Under Test
# of Identical Nodes: 4
Comment: SUT
Hardware
Hardware Vendor: Hewlett Packard Enterprise
Model: Apollo XL225n Gen10 Plus
Form Factor: Blade
CPU Name: AMD EPYC 7742 2.25 GHz
CPU Characteristics: 64-Core, 2.25 GHz, 256MB L3 Cache
CPU Frequency (MHz): 2250
CPU(s) Enabled: 128 cores, 2 chips, 64 cores/chip
Hardware Threads: 256 (2 / core)
CPU(s) Orderable: 1,2 chips
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 512 KB I+D on chip per core
Tertiary Cache: 256 MB I+D on chip per chip
Other Cache: None
Memory Amount (GB): 256
# and size of DIMM: 16 x 16384 MB
Memory Details: 16 GB 2Rx8 PC4-3200AA-R; all slots populated
Power Supply Quantity and Rating (W): None
Power Supply Details: Shared
Disk Drive: 1 x HPE 480GB SATA 6G SSD (P05976-B21)
Disk Controller: Embedded SATA Controller
# and type of Network Interface Cards (NICs) Installed: 1 x Intel Ethernet I350 4-Port 1Gb NIC
NICs Enabled in Firmware / OS / Connected: 1/1/1
Network Speed (Mbit): 1000
Keyboard: None
Mouse: None
Monitor: None
Optical Drives: No
Other Hardware: None
Software
Power Management: Enabled (see SUT Notes)
Operating System (OS): Windows Server 2019 Datacenter
OS Version: Version 1809 (OS Build 17763.1132)
Filesystem: NTFS
JVM Vendor: Oracle Corporation
JVM Version: Oracle Java HotSpot(TM) 64-Bit Server VM (build 13.0.2+8, mixed mode, sharing); version 13.0.2
JVM Command-line Options: -server -Xmn1200m -Xms1400m -Xmx1400m -XX:MaxTenuringThreshold=1 -XX:ParallelGCThreads=2 -XX:InlineSmallCode=4000 -XX:MaxInlineSize=300 -XX:FreqInlineSize=3000 -XX:+UseParallelOldGC -XX:+UseLargePages
JVM Affinity: start /NODE [0-31] /AFFINITY [0xF, 0xF0]
JVM Instances: 64
JVM Initial Heap (MB): 1400
JVM Maximum Heap (MB): 1400
JVM Address Bits: 64
Boot Firmware Version: A46 v1.20 (02/28/2020)
Management Firmware Version: 2.14 Feb 11 2020
Workload Version: SSJ 1.2.10
Director Location: Controller
Other Software: 1.KB4539571, 2.KB4554354 (patched: 24. March, 2020)
Boot Firmware Settings
Management Firmware Settings
See SUT Notes
System Under Test Notes
Notes
None
JVM Instance Summary
JVM Instance ssj_ops@100%
NODE-01.001 165,685
NODE-01.002 165,983
NODE-01.003 166,499
NODE-01.004 172,438
NODE-01.005 172,888
NODE-01.006 174,103
NODE-01.007 166,946
NODE-01.008 168,226
NODE-01.009 171,286
NODE-01.010 175,127
NODE-01.011 167,724
NODE-01.012 168,931
NODE-01.013 168,366
NODE-01.014 171,319
NODE-01.015 170,899
NODE-01.016 172,331
NODE-01.017 171,904
NODE-01.018 170,861
NODE-01.019 173,772
NODE-01.020 169,861
NODE-01.021 172,875
NODE-01.022 170,330
NODE-01.023 177,124
NODE-01.024 171,254
NODE-01.025 172,785
NODE-01.026 169,011
NODE-01.027 169,009
NODE-01.028 175,710
NODE-01.029 167,153
NODE-01.030 173,444
NODE-01.031 170,872
NODE-01.032 175,854
NODE-01.033 172,368
NODE-01.034 174,360
NODE-01.035 170,522
NODE-01.036 171,368
NODE-01.037 172,468
NODE-01.038 170,990
NODE-01.039 170,742
NODE-01.040 170,604
NODE-01.041 172,658
NODE-01.042 169,344
NODE-01.043 172,039
NODE-01.044 170,447
NODE-01.045 168,534
NODE-01.046 163,272
NODE-01.047 172,467
NODE-01.048 170,275
NODE-01.049 165,692
NODE-01.050 171,482
NODE-01.051 169,008
NODE-01.052 171,940
NODE-01.053 172,340
NODE-01.054 165,880
NODE-01.055 172,828
NODE-01.056 171,382
NODE-01.057 171,157
NODE-01.058 172,339
NODE-01.059 169,741
NODE-01.060 170,567
NODE-01.061 171,985
NODE-01.062 167,205
NODE-01.063 170,284
NODE-01.064 168,004
ssj_ops@100% 10,924,860
ssj_ops@100% per JVM 170,701
Graph of per-instance results
JVM 'NODE-01.001' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     167,304
Calibration 2     165,911
Calibration 3     166,095
ssj_ops@calibrated=166,003
100% 99.8% 166,003 165,685
90% 90.4% 149,402 150,088
80% 80.0% 132,802 132,767
70% 69.8% 116,202 115,813
60% 60.1% 99,602 99,698
50% 50.3% 83,001 83,475
40% 39.4% 66,401 65,345
30% 30.2% 49,801 50,056
20% 19.9% 33,201 32,980
10% 9.9% 16,600 16,500
Active Idle   0 0
Graph of results
JVM 'NODE-01.002' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     165,104
Calibration 2     166,703
Calibration 3     167,188
ssj_ops@calibrated=166,946
100% 99.4% 166,946 165,983
90% 88.8% 150,251 148,304
80% 80.5% 133,557 134,404
70% 70.1% 116,862 116,964
60% 59.7% 100,167 99,730
50% 50.2% 83,473 83,764
40% 40.2% 66,778 67,086
30% 30.1% 50,084 50,299
20% 20.2% 33,389 33,759
10% 10.1% 16,695 16,927
Active Idle   0 0
Graph of results
JVM 'NODE-01.003' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     169,193
Calibration 2     167,534
Calibration 3     167,552
ssj_ops@calibrated=167,543
100% 99.4% 167,543 166,499
90% 90.3% 150,789 151,326
80% 80.2% 134,035 134,382
70% 70.3% 117,280 117,715
60% 59.1% 100,526 98,953
50% 49.6% 83,772 83,112
40% 39.5% 67,017 66,103
30% 30.4% 50,263 50,933
20% 20.2% 33,509 33,885
10% 9.8% 16,754 16,400
Active Idle   0 0
Graph of results
JVM 'NODE-01.004' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,094
Calibration 2     172,731
Calibration 3     172,924
ssj_ops@calibrated=172,827
100% 99.8% 172,827 172,438
90% 89.7% 155,545 155,096
80% 79.4% 138,262 137,207
70% 69.5% 120,979 120,061
60% 60.1% 103,696 103,918
50% 50.3% 86,414 86,847
40% 40.2% 69,131 69,500
30% 30.6% 51,848 52,872
20% 19.9% 34,565 34,332
10% 10.2% 17,283 17,544
Active Idle   0 0
Graph of results
JVM 'NODE-01.005' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     174,508
Calibration 2     174,208
Calibration 3     174,341
ssj_ops@calibrated=174,275
100% 99.2% 174,275 172,888
90% 89.5% 156,847 156,034
80% 80.3% 139,420 139,935
70% 70.1% 121,992 122,159
60% 60.3% 104,565 105,062
50% 50.0% 87,137 87,177
40% 40.0% 69,710 69,723
30% 29.5% 52,282 51,463
20% 20.2% 34,855 35,260
10% 10.0% 17,427 17,441
Active Idle   0 0
Graph of results
JVM 'NODE-01.006' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,069
Calibration 2     174,234
Calibration 3     174,493
ssj_ops@calibrated=174,363
100% 99.9% 174,363 174,103
90% 89.7% 156,927 156,446
80% 80.0% 139,491 139,481
70% 70.4% 122,054 122,805
60% 59.9% 104,618 104,428
50% 50.3% 87,182 87,686
40% 40.2% 69,745 70,067
30% 30.0% 52,309 52,248
20% 19.5% 34,873 33,922
10% 9.9% 17,436 17,264
Active Idle   0 0
Graph of results
JVM 'NODE-01.007' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     165,655
Calibration 2     165,833
Calibration 3     166,395
ssj_ops@calibrated=166,114
100% 100.5% 166,114 166,946
90% 89.8% 149,503 149,142
80% 80.4% 132,891 133,563
70% 70.6% 116,280 117,325
60% 60.0% 99,668 99,747
50% 49.7% 83,057 82,522
40% 40.3% 66,446 66,998
30% 30.0% 49,834 49,785
20% 20.0% 33,223 33,192
10% 9.9% 16,611 16,508
Active Idle   0 0
Graph of results
JVM 'NODE-01.008' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     169,785
Calibration 2     169,338
Calibration 3     169,179
ssj_ops@calibrated=169,258
100% 99.4% 169,258 168,226
90% 89.6% 152,333 151,619
80% 79.8% 135,407 135,036
70% 70.4% 118,481 119,164
60% 59.9% 101,555 101,334
50% 49.9% 84,629 84,447
40% 39.5% 67,703 66,895
30% 29.7% 50,778 50,247
20% 19.7% 33,852 33,382
10% 10.0% 16,926 17,000
Active Idle   0 0
Graph of results
JVM 'NODE-01.009' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,960
Calibration 2     172,782
Calibration 3     172,688
ssj_ops@calibrated=172,735
100% 99.2% 172,735 171,286
90% 90.4% 155,462 156,173
80% 80.1% 138,188 138,301
70% 70.4% 120,915 121,527
60% 59.6% 103,641 102,976
50% 49.7% 86,368 85,842
40% 40.0% 69,094 69,104
30% 29.7% 51,821 51,323
20% 20.2% 34,547 34,954
10% 9.7% 17,274 16,829
Active Idle   0 0
Graph of results
JVM 'NODE-01.010' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     175,891
Calibration 2     176,006
Calibration 3     175,522
ssj_ops@calibrated=175,764
100% 99.6% 175,764 175,127
90% 89.8% 158,188 157,881
80% 79.7% 140,611 140,053
70% 70.3% 123,035 123,575
60% 59.9% 105,459 105,322
50% 49.7% 87,882 87,368
40% 39.9% 70,306 70,120
30% 30.2% 52,729 53,083
20% 19.6% 35,153 34,489
10% 9.7% 17,576 17,003
Active Idle   0 0
Graph of results
JVM 'NODE-01.011' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     169,344
Calibration 2     168,236
Calibration 3     168,508
ssj_ops@calibrated=168,372
100% 99.6% 168,372 167,724
90% 90.2% 151,535 151,906
80% 80.2% 134,698 135,046
70% 70.2% 117,861 118,281
60% 59.9% 101,023 100,864
50% 50.2% 84,186 84,556
40% 39.4% 67,349 66,255
30% 30.2% 50,512 50,846
20% 20.3% 33,674 34,144
10% 9.9% 16,837 16,696
Active Idle   0 0
Graph of results
JVM 'NODE-01.012' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     168,730
Calibration 2     169,475
Calibration 3     169,524
ssj_ops@calibrated=169,500
100% 99.7% 169,500 168,931
90% 89.7% 152,550 152,030
80% 79.3% 135,600 134,405
70% 70.2% 118,650 119,009
60% 60.3% 101,700 102,251
50% 49.8% 84,750 84,397
40% 39.6% 67,800 67,079
30% 30.0% 50,850 50,811
20% 20.2% 33,900 34,234
10% 10.2% 16,950 17,283
Active Idle   0 0
Graph of results
JVM 'NODE-01.013' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     166,884
Calibration 2     168,336
Calibration 3     168,376
ssj_ops@calibrated=168,356
100% 100.0% 168,356 168,366
90% 90.4% 151,520 152,110
80% 81.0% 134,685 136,303
70% 69.9% 117,849 117,661
60% 59.6% 101,013 100,396
50% 50.1% 84,178 84,410
40% 40.1% 67,342 67,558
30% 30.0% 50,507 50,423
20% 20.2% 33,671 33,956
10% 9.9% 16,836 16,736
Active Idle   0 0
Graph of results
JVM 'NODE-01.014' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,437
Calibration 2     172,693
Calibration 3     172,535
ssj_ops@calibrated=172,614
100% 99.3% 172,614 171,319
90% 90.8% 155,352 156,781
80% 79.3% 138,091 136,914
70% 69.9% 120,830 120,592
60% 59.7% 103,568 103,102
50% 49.7% 86,307 85,818
40% 39.7% 69,046 68,535
30% 29.6% 51,784 51,161
20% 20.0% 34,523 34,523
10% 10.0% 17,261 17,210
Active Idle   0 0
Graph of results
JVM 'NODE-01.015' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,533
Calibration 2     171,880
Calibration 3     171,991
ssj_ops@calibrated=171,935
100% 99.4% 171,935 170,899
90% 90.3% 154,742 155,329
80% 80.5% 137,548 138,438
70% 70.6% 120,355 121,384
60% 60.1% 103,161 103,328
50% 50.0% 85,968 86,015
40% 40.2% 68,774 69,141
30% 30.3% 51,581 52,048
20% 19.9% 34,387 34,181
10% 9.9% 17,194 16,999
Active Idle   0 0
Graph of results
JVM 'NODE-01.016' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     174,219
Calibration 2     173,286
Calibration 3     173,001
ssj_ops@calibrated=173,143
100% 99.5% 173,143 172,331
90% 90.6% 155,829 156,783
80% 80.4% 138,515 139,232
70% 70.0% 121,200 121,184
60% 60.3% 103,886 104,342
50% 49.9% 86,572 86,412
40% 40.1% 69,257 69,395
30% 30.1% 51,943 52,156
20% 20.1% 34,629 34,732
10% 10.3% 17,314 17,762
Active Idle   0 0
Graph of results
JVM 'NODE-01.017' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,410
Calibration 2     172,605
Calibration 3     172,458
ssj_ops@calibrated=172,531
100% 99.6% 172,531 171,904
90% 89.7% 155,278 154,792
80% 81.0% 138,025 139,771
70% 69.9% 120,772 120,513
60% 60.1% 103,519 103,687
50% 50.2% 86,266 86,693
40% 41.1% 69,012 70,826
30% 29.7% 51,759 51,299
20% 19.8% 34,506 34,164
10% 10.0% 17,253 17,302
Active Idle   0 0
Graph of results
JVM 'NODE-01.018' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,765
Calibration 2     171,072
Calibration 3     171,191
ssj_ops@calibrated=171,132
100% 99.8% 171,132 170,861
90% 89.9% 154,019 153,806
80% 79.7% 136,905 136,376
70% 69.3% 119,792 118,551
60% 60.3% 102,679 103,135
50% 50.7% 85,566 86,793
40% 39.8% 68,453 68,146
30% 30.1% 51,340 51,441
20% 20.0% 34,226 34,276
10% 9.9% 17,113 17,019
Active Idle   0 0
Graph of results
JVM 'NODE-01.019' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     175,130
Calibration 2     173,984
Calibration 3     174,326
ssj_ops@calibrated=174,155
100% 99.8% 174,155 173,772
90% 89.9% 156,740 156,611
80% 80.2% 139,324 139,696
70% 70.0% 121,909 121,836
60% 59.9% 104,493 104,296
50% 50.0% 87,078 87,126
40% 39.9% 69,662 69,438
30% 29.8% 52,247 51,940
20% 20.2% 34,831 35,098
10% 9.9% 17,416 17,260
Active Idle   0 0
Graph of results
JVM 'NODE-01.020' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     170,036
Calibration 2     170,138
Calibration 3     170,373
ssj_ops@calibrated=170,255
100% 99.8% 170,255 169,861
90% 90.4% 153,230 153,832
80% 80.0% 136,204 136,181
70% 69.9% 119,179 118,966
60% 60.4% 102,153 102,752
50% 50.1% 85,128 85,297
40% 39.9% 68,102 67,989
30% 29.9% 51,077 50,872
20% 20.2% 34,051 34,382
10% 10.4% 17,026 17,630
Active Idle   0 0
Graph of results
JVM 'NODE-01.021' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,703
Calibration 2     173,479
Calibration 3     173,385
ssj_ops@calibrated=173,432
100% 99.7% 173,432 172,875
90% 89.5% 156,089 155,232
80% 79.9% 138,745 138,637
70% 70.2% 121,402 121,791
60% 60.0% 104,059 104,118
50% 50.1% 86,716 86,870
40% 39.9% 69,373 69,168
30% 30.4% 52,030 52,722
20% 19.9% 34,686 34,496
10% 9.8% 17,343 17,058
Active Idle   0 0
Graph of results
JVM 'NODE-01.022' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,383
Calibration 2     171,496
Calibration 3     171,583
ssj_ops@calibrated=171,540
100% 99.3% 171,540 170,330
90% 90.2% 154,386 154,774
80% 79.2% 137,232 135,794
70% 70.2% 120,078 120,413
60% 59.8% 102,924 102,580
50% 50.5% 85,770 86,581
40% 40.5% 68,616 69,494
30% 30.1% 51,462 51,680
20% 20.3% 34,308 34,758
10% 10.1% 17,154 17,291
Active Idle   0 0
Graph of results
JVM 'NODE-01.023' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     178,190
Calibration 2     177,291
Calibration 3     177,497
ssj_ops@calibrated=177,394
100% 99.8% 177,394 177,124
90% 90.5% 159,655 160,488
80% 80.2% 141,915 142,186
70% 69.6% 124,176 123,537
60% 60.1% 106,436 106,635
50% 49.7% 88,697 88,198
40% 40.2% 70,958 71,225
30% 30.2% 53,218 53,494
20% 19.8% 35,479 35,189
10% 10.0% 17,739 17,687
Active Idle   0 0
Graph of results
JVM 'NODE-01.024' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     170,388
Calibration 2     171,750
Calibration 3     171,846
ssj_ops@calibrated=171,798
100% 99.7% 171,798 171,254
90% 90.8% 154,618 155,929
80% 80.2% 137,438 137,819
70% 69.7% 120,258 119,788
60% 59.5% 103,079 102,301
50% 49.9% 85,899 85,718
40% 40.1% 68,719 68,875
30% 29.8% 51,539 51,263
20% 20.2% 34,360 34,620
10% 10.3% 17,180 17,626
Active Idle   0 0
Graph of results
JVM 'NODE-01.025' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,925
Calibration 2     173,328
Calibration 3     173,410
ssj_ops@calibrated=173,369
100% 99.7% 173,369 172,785
90% 89.7% 156,032 155,489
80% 79.4% 138,695 137,726
70% 70.5% 121,358 122,254
60% 59.8% 104,021 103,657
50% 50.2% 86,684 87,069
40% 40.7% 69,347 70,516
30% 29.7% 52,011 51,509
20% 20.1% 34,674 34,798
10% 10.1% 17,337 17,595
Active Idle   0 0
Graph of results
JVM 'NODE-01.026' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     170,531
Calibration 2     170,904
Calibration 3     170,919
ssj_ops@calibrated=170,911
100% 98.9% 170,911 169,011
90% 90.0% 153,820 153,904
80% 80.4% 136,729 137,341
70% 69.6% 119,638 118,903
60% 59.3% 102,547 101,404
50% 50.1% 85,456 85,607
40% 40.0% 68,364 68,417
30% 30.0% 51,273 51,274
20% 20.0% 34,182 34,146
10% 9.9% 17,091 16,870
Active Idle   0 0
Graph of results
JVM 'NODE-01.027' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     170,641
Calibration 2     170,047
Calibration 3     170,635
ssj_ops@calibrated=170,341
100% 99.2% 170,341 169,009
90% 90.3% 153,307 153,833
80% 79.4% 136,273 135,236
70% 70.3% 119,239 119,759
60% 60.2% 102,205 102,461
50% 50.1% 85,171 85,384
40% 40.0% 68,136 68,207
30% 29.7% 51,102 50,514
20% 20.0% 34,068 34,139
10% 10.1% 17,034 17,253
Active Idle   0 0
Graph of results
JVM 'NODE-01.028' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     176,915
Calibration 2     175,593
Calibration 3     176,109
ssj_ops@calibrated=175,851
100% 99.9% 175,851 175,710
90% 90.2% 158,266 158,567
80% 80.4% 140,681 141,437
70% 69.9% 123,096 122,963
60% 59.8% 105,510 105,207
50% 49.9% 87,925 87,820
40% 39.3% 70,340 69,042
30% 29.9% 52,755 52,522
20% 19.9% 35,170 35,027
10% 10.1% 17,585 17,732
Active Idle   0 0
Graph of results
JVM 'NODE-01.029' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     166,496
Calibration 2     167,473
Calibration 3     167,494
ssj_ops@calibrated=167,484
100% 99.8% 167,484 167,153
90% 90.2% 150,736 151,134
80% 79.7% 133,987 133,495
70% 70.4% 117,239 117,858
60% 59.6% 100,490 99,850
50% 50.2% 83,742 84,133
40% 40.3% 66,994 67,446
30% 29.9% 50,245 50,031
20% 19.8% 33,497 33,081
10% 10.1% 16,748 16,847
Active Idle   0 0
Graph of results
JVM 'NODE-01.030' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     177,046
Calibration 2     175,233
Calibration 3     175,476
ssj_ops@calibrated=175,355
100% 98.9% 175,355 173,444
90% 90.4% 157,819 158,509
80% 79.4% 140,284 139,220
70% 69.5% 122,748 121,817
60% 59.8% 105,213 104,819
50% 49.8% 87,677 87,382
40% 39.9% 70,142 70,031
30% 30.1% 52,606 52,816
20% 20.2% 35,071 35,344
10% 10.1% 17,535 17,791
Active Idle   0 0
Graph of results
JVM 'NODE-01.031' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,095
Calibration 2     171,360
Calibration 3     171,339
ssj_ops@calibrated=171,349
100% 99.7% 171,349 170,872
90% 89.6% 154,214 153,481
80% 80.1% 137,079 137,331
70% 69.8% 119,944 119,659
60% 60.2% 102,810 103,143
50% 50.2% 85,675 86,098
40% 40.2% 68,540 68,915
30% 30.1% 51,405 51,603
20% 20.2% 34,270 34,562
10% 10.2% 17,135 17,453
Active Idle   0 0
Graph of results
JVM 'NODE-01.032' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     177,397
Calibration 2     176,694
Calibration 3     176,695
ssj_ops@calibrated=176,694
100% 99.5% 176,694 175,854
90% 90.5% 159,025 159,883
80% 79.9% 141,355 141,151
70% 70.3% 123,686 124,144
60% 60.1% 106,017 106,154
50% 49.8% 88,347 88,044
40% 39.6% 70,678 70,037
30% 29.9% 53,008 52,881
20% 20.4% 35,339 36,021
10% 10.0% 17,669 17,628
Active Idle   0 0
Graph of results
JVM 'NODE-01.033' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,298
Calibration 2     172,548
Calibration 3     172,623
ssj_ops@calibrated=172,586
100% 99.9% 172,586 172,368
90% 89.8% 155,327 154,973
80% 79.7% 138,069 137,610
70% 70.2% 120,810 121,229
60% 59.8% 103,551 103,133
50% 49.5% 86,293 85,363
40% 39.9% 69,034 68,843
30% 29.7% 51,776 51,271
20% 20.0% 34,517 34,561
10% 10.1% 17,259 17,451
Active Idle   0 0
Graph of results
JVM 'NODE-01.034' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     177,147
Calibration 2     175,225
Calibration 3     175,388
ssj_ops@calibrated=175,306
100% 99.5% 175,306 174,360
90% 90.3% 157,776 158,249
80% 79.8% 140,245 139,848
70% 70.2% 122,714 123,114
60% 60.0% 105,184 105,156
50% 50.4% 87,653 88,362
40% 39.9% 70,123 70,003
30% 30.2% 52,592 52,922
20% 20.2% 35,061 35,395
10% 9.9% 17,531 17,361
Active Idle   0 0
Graph of results
JVM 'NODE-01.035' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,392
Calibration 2     171,220
Calibration 3     171,637
ssj_ops@calibrated=171,429
100% 99.5% 171,429 170,522
90% 89.9% 154,286 154,106
80% 80.5% 137,143 138,077
70% 70.2% 120,000 120,395
60% 59.8% 102,857 102,558
50% 49.8% 85,714 85,338
40% 40.1% 68,571 68,774
30% 30.0% 51,429 51,355
20% 19.9% 34,286 34,099
10% 9.9% 17,143 16,908
Active Idle   0 0
Graph of results
JVM 'NODE-01.036' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,326
Calibration 2     172,319
Calibration 3     172,561
ssj_ops@calibrated=172,440
100% 99.4% 172,440 171,368
90% 89.4% 155,196 154,232
80% 79.5% 137,952 137,104
70% 69.3% 120,708 119,492
60% 60.3% 103,464 103,917
50% 50.2% 86,220 86,551
40% 39.9% 68,976 68,827
30% 30.1% 51,732 51,856
20% 20.1% 34,488 34,684
10% 10.0% 17,244 17,182
Active Idle   0 0
Graph of results
JVM 'NODE-01.037' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,026
Calibration 2     173,546
Calibration 3     173,633
ssj_ops@calibrated=173,589
100% 99.4% 173,589 172,468
90% 90.8% 156,231 157,596
80% 80.1% 138,872 139,059
70% 69.9% 121,513 121,341
60% 59.7% 104,154 103,626
50% 50.1% 86,795 86,943
40% 40.2% 69,436 69,767
30% 30.1% 52,077 52,314
20% 20.2% 34,718 35,043
10% 9.9% 17,359 17,211
Active Idle   0 0
Graph of results
JVM 'NODE-01.038' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,258
Calibration 2     170,930
Calibration 3     170,855
ssj_ops@calibrated=170,892
100% 100.1% 170,892 170,990
90% 90.0% 153,803 153,864
80% 80.7% 136,714 137,917
70% 70.3% 119,625 120,124
60% 60.1% 102,535 102,638
50% 49.4% 85,446 84,452
40% 40.0% 68,357 68,321
30% 29.4% 51,268 50,163
20% 20.2% 34,178 34,444
10% 10.1% 17,089 17,325
Active Idle   0 0
Graph of results
JVM 'NODE-01.039' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,171
Calibration 2     171,541
Calibration 3     171,246
ssj_ops@calibrated=171,394
100% 99.6% 171,394 170,742
90% 89.9% 154,254 154,075
80% 79.5% 137,115 136,266
70% 70.2% 119,976 120,250
60% 59.9% 102,836 102,726
50% 49.8% 85,697 85,347
40% 39.7% 68,557 67,970
30% 29.9% 51,418 51,204
20% 19.9% 34,279 34,150
10% 10.0% 17,139 17,095
Active Idle   0 0
Graph of results
JVM 'NODE-01.040' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     169,619
Calibration 2     171,002
Calibration 3     171,143
ssj_ops@calibrated=171,072
100% 99.7% 171,072 170,604
90% 91.1% 153,965 155,919
80% 79.9% 136,858 136,652
70% 70.3% 119,751 120,249
60% 59.7% 102,643 102,184
50% 49.3% 85,536 84,352
40% 40.0% 68,429 68,367
30% 30.4% 51,322 51,950
20% 20.4% 34,214 34,935
10% 9.9% 17,107 16,920
Active Idle   0 0
Graph of results
JVM 'NODE-01.041' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,912
Calibration 2     172,030
Calibration 3     172,059
ssj_ops@calibrated=172,044
100% 100.4% 172,044 172,658
90% 90.3% 154,840 155,436
80% 80.8% 137,635 138,940
70% 70.6% 120,431 121,454
60% 60.7% 103,227 104,358
50% 50.6% 86,022 87,077
40% 40.6% 68,818 69,771
30% 30.1% 51,613 51,780
20% 20.0% 34,409 34,490
10% 10.0% 17,204 17,253
Active Idle   0 0
Graph of results
JVM 'NODE-01.042' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     169,960
Calibration 2     170,847
Calibration 3     171,049
ssj_ops@calibrated=170,948
100% 99.1% 170,948 169,344
90% 90.2% 153,853 154,204
80% 80.2% 136,758 137,026
70% 70.1% 119,664 119,859
60% 60.5% 102,569 103,490
50% 50.2% 85,474 85,836
40% 39.9% 68,379 68,194
30% 29.9% 51,284 51,134
20% 19.9% 34,190 34,022
10% 10.1% 17,095 17,225
Active Idle   0 0
Graph of results
JVM 'NODE-01.043' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,243
Calibration 2     172,997
Calibration 3     173,119
ssj_ops@calibrated=173,058
100% 99.4% 173,058 172,039
90% 90.2% 155,752 156,086
80% 80.0% 138,446 138,365
70% 70.0% 121,141 121,226
60% 59.4% 103,835 102,771
50% 49.6% 86,529 85,806
40% 39.6% 69,223 68,547
30% 29.7% 51,917 51,338
20% 20.5% 34,612 35,538
10% 9.8% 17,306 17,036
Active Idle   0 0
Graph of results
JVM 'NODE-01.044' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     173,277
Calibration 2     171,301
Calibration 3     171,574
ssj_ops@calibrated=171,438
100% 99.4% 171,438 170,447
90% 90.2% 154,294 154,663
80% 80.0% 137,150 137,106
70% 70.0% 120,006 119,984
60% 59.3% 102,863 101,619
50% 50.1% 85,719 85,889
40% 40.1% 68,575 68,804
30% 29.9% 51,431 51,233
20% 20.3% 34,288 34,766
10% 10.2% 17,144 17,495
Active Idle   0 0
Graph of results
JVM 'NODE-01.045' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     167,735
Calibration 2     168,701
Calibration 3     168,739
ssj_ops@calibrated=168,720
100% 99.9% 168,720 168,534
90% 90.1% 151,848 152,068
80% 79.0% 134,976 133,226
70% 70.0% 118,104 118,067
60% 60.1% 101,232 101,454
50% 49.7% 84,360 83,783
40% 40.2% 67,488 67,900
30% 30.0% 50,616 50,535
20% 20.0% 33,744 33,767
10% 10.0% 16,872 16,881
Active Idle   0 0
Graph of results
JVM 'NODE-01.046' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     163,028
Calibration 2     163,994
Calibration 3     164,572
ssj_ops@calibrated=164,283
100% 99.4% 164,283 163,272
90% 90.4% 147,855 148,455
80% 79.7% 131,426 131,004
70% 70.1% 114,998 115,177
60% 60.0% 98,570 98,550
50% 49.3% 82,142 80,979
40% 40.0% 65,713 65,635
30% 29.8% 49,285 48,900
20% 20.0% 32,857 32,776
10% 9.9% 16,428 16,282
Active Idle   0 0
Graph of results
JVM 'NODE-01.047' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     174,739
Calibration 2     174,294
Calibration 3     174,368
ssj_ops@calibrated=174,331
100% 98.9% 174,331 172,467
90% 90.7% 156,898 158,135
80% 80.0% 139,465 139,477
70% 69.9% 122,032 121,914
60% 60.0% 104,599 104,672
50% 50.4% 87,166 87,812
40% 39.9% 69,732 69,531
30% 29.9% 52,299 52,105
20% 19.9% 34,866 34,727
10% 9.9% 17,433 17,182
Active Idle   0 0
Graph of results
JVM 'NODE-01.048' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,943
Calibration 2     170,632
Calibration 3     170,806
ssj_ops@calibrated=170,719
100% 99.7% 170,719 170,275
90% 90.0% 153,647 153,643
80% 80.5% 136,575 137,347
70% 69.6% 119,503 118,736
60% 60.4% 102,432 103,092
50% 50.3% 85,360 85,940
40% 40.3% 68,288 68,880
30% 30.2% 51,216 51,521
20% 20.3% 34,144 34,644
10% 9.9% 17,072 16,823
Active Idle   0 0
Graph of results
JVM 'NODE-01.049' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     167,742
Calibration 2     166,311
Calibration 3     166,568
ssj_ops@calibrated=166,440
100% 99.6% 166,440 165,692
90% 90.4% 149,796 150,444
80% 80.8% 133,152 134,458
70% 69.8% 116,508 116,126
60% 60.0% 99,864 99,782
50% 49.7% 83,220 82,651
40% 40.1% 66,576 66,792
30% 29.8% 49,932 49,556
20% 20.4% 33,288 33,927
10% 9.9% 16,644 16,547
Active Idle   0 0
Graph of results
JVM 'NODE-01.050' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,210
Calibration 2     171,779
Calibration 3     171,549
ssj_ops@calibrated=171,664
100% 99.9% 171,664 171,482
90% 90.0% 154,498 154,535
80% 80.5% 137,331 138,117
70% 70.1% 120,165 120,378
60% 59.4% 102,998 102,007
50% 50.0% 85,832 85,892
40% 39.9% 68,666 68,533
30% 29.8% 51,499 51,164
20% 20.1% 34,333 34,493
10% 10.1% 17,166 17,420
Active Idle   0 0
Graph of results
JVM 'NODE-01.051' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     169,477
Calibration 2     169,912
Calibration 3     169,970
ssj_ops@calibrated=169,941
100% 99.5% 169,941 169,008
90% 89.9% 152,947 152,761
80% 80.3% 135,953 136,533
70% 69.3% 118,959 117,728
60% 60.5% 101,965 102,898
50% 49.5% 84,970 84,086
40% 40.1% 67,976 68,160
30% 30.0% 50,982 50,959
20% 20.0% 33,988 33,921
10% 10.2% 16,994 17,256
Active Idle   0 0
Graph of results
JVM 'NODE-01.052' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,684
Calibration 2     172,706
Calibration 3     172,872
ssj_ops@calibrated=172,789
100% 99.5% 172,789 171,940
90% 89.5% 155,510 154,640
80% 79.9% 138,231 138,035
70% 70.4% 120,952 121,559
60% 59.8% 103,674 103,247
50% 49.9% 86,395 86,198
40% 40.3% 69,116 69,656
30% 30.2% 51,837 52,209
20% 20.1% 34,558 34,775
10% 10.2% 17,279 17,636
Active Idle   0 0
Graph of results
JVM 'NODE-01.053' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,226
Calibration 2     172,286
Calibration 3     172,599
ssj_ops@calibrated=172,443
100% 99.9% 172,443 172,340
90% 88.9% 155,198 153,267
80% 80.7% 137,954 139,079
70% 69.7% 120,710 120,188
60% 59.6% 103,466 102,824
50% 50.1% 86,221 86,467
40% 40.7% 68,977 70,146
30% 29.8% 51,733 51,466
20% 20.0% 34,489 34,479
10% 9.9% 17,244 17,145
Active Idle   0 0
Graph of results
JVM 'NODE-01.054' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     167,522
Calibration 2     167,398
Calibration 3     167,106
ssj_ops@calibrated=167,252
100% 99.2% 167,252 165,880
90% 91.2% 150,527 152,515
80% 80.2% 133,801 134,159
70% 70.1% 117,076 117,254
60% 59.7% 100,351 99,810
50% 49.5% 83,626 82,779
40% 40.2% 66,901 67,237
30% 30.3% 50,176 50,616
20% 19.8% 33,450 33,152
10% 10.0% 16,725 16,695
Active Idle   0 0
Graph of results
JVM 'NODE-01.055' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,628
Calibration 2     173,514
Calibration 3     173,373
ssj_ops@calibrated=173,444
100% 99.6% 173,444 172,828
90% 89.1% 156,099 154,525
80% 79.9% 138,755 138,561
70% 69.6% 121,410 120,689
60% 59.8% 104,066 103,662
50% 49.8% 86,722 86,396
40% 39.6% 69,377 68,740
30% 30.1% 52,033 52,261
20% 20.1% 34,689 34,827
10% 10.3% 17,344 17,921
Active Idle   0 0
Graph of results
JVM 'NODE-01.056' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,318
Calibration 2     172,131
Calibration 3     172,631
ssj_ops@calibrated=172,381
100% 99.4% 172,381 171,382
90% 89.3% 155,143 153,980
80% 80.0% 137,905 137,966
70% 69.7% 120,667 120,140
60% 60.3% 103,429 103,892
50% 50.5% 86,191 87,071
40% 39.9% 68,952 68,700
30% 30.2% 51,714 52,113
20% 20.2% 34,476 34,758
10% 9.9% 17,238 17,119
Active Idle   0 0
Graph of results
JVM 'NODE-01.057' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     174,313
Calibration 2     172,681
Calibration 3     172,723
ssj_ops@calibrated=172,702
100% 99.1% 172,702 171,157
90% 90.0% 155,432 155,472
80% 79.7% 138,161 137,697
70% 70.4% 120,891 121,562
60% 60.3% 103,621 104,081
50% 50.5% 86,351 87,128
40% 39.8% 69,081 68,663
30% 30.0% 51,811 51,896
20% 20.1% 34,540 34,722
10% 9.9% 17,270 17,145
Active Idle   0 0
Graph of results
JVM 'NODE-01.058' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     174,043
Calibration 2     172,474
Calibration 3     172,736
ssj_ops@calibrated=172,605
100% 99.8% 172,605 172,339
90% 89.4% 155,345 154,249
80% 80.0% 138,084 138,064
70% 70.0% 120,824 120,848
60% 60.6% 103,563 104,651
50% 50.4% 86,303 86,996
40% 40.0% 69,042 69,015
30% 30.1% 51,782 51,964
20% 19.8% 34,521 34,162
10% 10.0% 17,261 17,344
Active Idle   0 0
Graph of results
JVM 'NODE-01.059' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,617
Calibration 2     170,872
Calibration 3     171,067
ssj_ops@calibrated=170,970
100% 99.3% 170,970 169,741
90% 89.7% 153,873 153,288
80% 80.3% 136,776 137,209
70% 70.6% 119,679 120,739
60% 60.3% 102,582 103,151
50% 50.1% 85,485 85,709
40% 40.1% 68,388 68,595
30% 30.0% 51,291 51,214
20% 20.0% 34,194 34,227
10% 9.8% 17,097 16,802
Active Idle   0 0
Graph of results
JVM 'NODE-01.060' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     171,880
Calibration 2     171,386
Calibration 3     171,259
ssj_ops@calibrated=171,322
100% 99.6% 171,322 170,567
90% 90.5% 154,190 155,104
80% 79.8% 137,058 136,744
70% 70.5% 119,925 120,773
60% 59.7% 102,793 102,363
50% 49.8% 85,661 85,369
40% 40.0% 68,529 68,462
30% 29.9% 51,397 51,227
20% 20.0% 34,264 34,329
10% 10.0% 17,132 17,108
Active Idle   0 0
Graph of results
JVM 'NODE-01.061' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     172,028
Calibration 2     173,417
Calibration 3     173,361
ssj_ops@calibrated=173,389
100% 99.2% 173,389 171,985
90% 89.1% 156,050 154,526
80% 80.4% 138,711 139,365
70% 70.2% 121,372 121,731
60% 59.5% 104,033 103,173
50% 49.8% 86,694 86,365
40% 40.1% 69,356 69,451
30% 29.9% 52,017 51,872
20% 20.0% 34,678 34,760
10% 10.2% 17,339 17,718
Active Idle   0 0
Graph of results
JVM 'NODE-01.062' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     168,040
Calibration 2     168,901
Calibration 3     168,760
ssj_ops@calibrated=168,830
100% 99.0% 168,830 167,205
90% 89.7% 151,947 151,386
80% 79.6% 135,064 134,445
70% 70.1% 118,181 118,331
60% 59.8% 101,298 100,930
50% 49.9% 84,415 84,191
40% 39.7% 67,532 67,049
30% 30.3% 50,649 51,195
20% 20.0% 33,766 33,699
10% 9.9% 16,883 16,762
Active Idle   0 0
Graph of results
JVM 'NODE-01.063' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     170,660
Calibration 2     171,602
Calibration 3     171,632
ssj_ops@calibrated=171,617
100% 99.2% 171,617 170,284
90% 90.1% 154,455 154,574
80% 79.6% 137,293 136,693
70% 70.6% 120,132 121,212
60% 60.1% 102,970 103,148
50% 50.1% 85,808 85,975
40% 40.2% 68,647 68,932
30% 29.4% 51,485 50,454
20% 20.1% 34,323 34,572
10% 9.9% 17,162 17,061
Active Idle   0 0
Graph of results
JVM 'NODE-01.064' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     170,489
Calibration 2     168,687
Calibration 3     169,190
ssj_ops@calibrated=168,938
100% 99.4% 168,938 168,004
90% 90.4% 152,045 152,791
80% 79.8% 135,151 134,839
70% 70.4% 118,257 119,009
60% 60.1% 101,363 101,540
50% 50.3% 84,469 84,916
40% 40.5% 67,575 68,449
30% 30.2% 50,682 51,072
20% 20.0% 33,788 33,772
10% 10.1% 16,894 16,998
Active Idle   0 0
Graph of results
