Huawei Technologies Co., Ltd RH2288H V2-8 Rack Server ssj_ops@100% = 1,759,570
ssj_ops@100% per JVM = 175,957
Test Sponsor: Huawei Technologies Co., Ltd SPEC License #: 3175 Test Method: Single Node
Tested By: Huawei Technologies Co., Ltd Test Location: Shenzhen, Guangdong, China Test Date: Aug 19, 2013
Hardware Availability: Sep-2013 Software Availability: Jun-2012 Publication: Oct 2, 2013
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     1,588,652
Calibration 2     1,761,194
Calibration 3     1,758,225
ssj_ops@calibrated=1,759,710
100% 100.0% 1,759,710 1,759,570
90% 90.1% 1,583,739 1,586,027
80% 79.8% 1,407,768 1,404,642
70% 70.0% 1,231,797 1,232,106
60% 60.0% 1,055,826 1,056,126
50% 50.1% 879,855 880,764
40% 40.2% 703,884 706,600
30% 30.0% 527,913 527,056
20% 19.9% 351,942 350,534
10% 10.0% 175,971 176,401
Active Idle   0 0
Graph of results
System Under Test
Set: 'sut'
Set Identifier: sut
Set Description: System Under Test
# of Identical Nodes: 1
Comment: None
Hardware
Hardware Vendor: Huawei Technologies Co., Ltd
Model: RH2288H V2-8 Rack Server
Form Factor: 2U
CPU Name: Intel Xeon E5-2660V2
CPU Characteristics: 10-Core, 2.2GHz, 25MB L3 Cache (Intel Turbo Boost Technology up to 3.0GHz)
CPU Frequency (MHz): 2200
CPU(s) Enabled: 20 cores, 2 chips, 10 cores/chip
Hardware Threads: 40 (2 / core)
CPU(s) Orderable: 1,2 chips
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 256 KB I+D on chip per core
Tertiary Cache: 25 MB I+D on chip per chip
Other Cache: None
Memory Amount (GB): 24
# and size of DIMM: 6 x 4 GB
Memory Details: 4GB 2Rx8 PC3L-10600R ECC RDIMM,Slots 1A1 1B1, 1C1,2A1,2B1,2C1 populated
Power Supply Quantity and Rating (W): 1 x 460
Power Supply Details: Huawei P/N 02130957
Disk Drive: 1 x 160GB SSD 2.5" SATA Huawei P/N 02310TFY
Disk Controller: Integrated SATA controller
# and type of Network Interface Cards (NICs) Installed: 1 x Dual-port Intel 82580 Gigabit Ethernet controller
NICs Enabled in Firmware / OS / Connected: 2/2/1
Network Speed (Mbit): 1000
Keyboard: None
Mouse: None
Monitor: None
Optical Drives: No
Other Hardware: None
Software
Power Management: Power Saver Mode enabled in OS
Operating System (OS): Microsoft Windows Server 2008 Enterprise x64 Edition
OS Version: R2 SP1 (64-bit)
Filesystem: NTFS
JVM Vendor: IBM Corporation
JVM Version: IBM J9 VM (build 2.6,JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120322_106209 (JIT enabled, AOT enabled)
JVM Command-line Options: -Xaggressive -Xcompressedrefs -Xmx1875m -Xms1875m -Xmn1400m -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -Xconcurrentlevel0
JVM Affinity: start /affinity [F,F0,F00,F000,F0000,F00000,F000000,F0000000,F00000000,F000000000]
JVM Instances: 10
JVM Initial Heap (MB): 1875
JVM Maximum Heap (MB): 1875
JVM Address Bits: 64
Boot Firmware Version: V063
Management Firmware Version: 3.87
Workload Version: SSJ 1.2.10
Director Location: Controller
Other Software: IBM SDK Java Technology Edition Version 7.0 for windows x64
Boot Firmware Settings
Management Firmware Settings
none
System Under Test Notes
Notes
None
JVM Instance Summary
JVM Instance ssj_ops@100%
WIN-1NGEQ3NTDG4.001 175,508
WIN-1NGEQ3NTDG4.002 177,120
WIN-1NGEQ3NTDG4.003 178,880
WIN-1NGEQ3NTDG4.004 174,692
WIN-1NGEQ3NTDG4.005 175,816
WIN-1NGEQ3NTDG4.006 175,407
WIN-1NGEQ3NTDG4.007 173,778
WIN-1NGEQ3NTDG4.008 176,142
WIN-1NGEQ3NTDG4.009 176,033
WIN-1NGEQ3NTDG4.010 176,194
ssj_ops@100% 1,759,570
ssj_ops@100% per JVM 175,957
Graph of per-instance results
JVM 'WIN-1NGEQ3NTDG4.001' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     159,246
Calibration 2     175,338
Calibration 3     175,021
ssj_ops@calibrated=175,180
100% 100.2% 175,180 175,508
90% 90.1% 157,662 157,793
80% 80.5% 140,144 141,075
70% 70.6% 122,626 123,758
60% 59.9% 105,108 104,936
50% 50.0% 87,590 87,529
40% 40.0% 70,072 70,078
30% 29.6% 52,554 51,906
20% 19.8% 35,036 34,631
10% 10.0% 17,518 17,528
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.002' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     159,127
Calibration 2     175,267
Calibration 3     176,362
ssj_ops@calibrated=175,814
100% 100.7% 175,814 177,120
90% 90.9% 158,233 159,740
80% 79.7% 140,651 140,186
70% 70.1% 123,070 123,219
60% 60.4% 105,489 106,171
50% 49.8% 87,907 87,562
40% 40.2% 70,326 70,734
30% 30.0% 52,744 52,727
20% 20.1% 35,163 35,260
10% 10.0% 17,581 17,600
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.003' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     161,921
Calibration 2     179,266
Calibration 3     178,081
ssj_ops@calibrated=178,673
100% 100.1% 178,673 178,880
90% 89.9% 160,806 160,584
80% 79.4% 142,939 141,916
70% 70.1% 125,071 125,242
60% 60.0% 107,204 107,127
50% 50.6% 89,337 90,343
40% 40.7% 71,469 72,802
30% 29.9% 53,602 53,369
20% 20.0% 35,735 35,702
10% 10.0% 17,867 17,921
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.004' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     156,664
Calibration 2     175,042
Calibration 3     175,444
ssj_ops@calibrated=175,243
100% 99.7% 175,243 174,692
90% 89.9% 157,719 157,605
80% 79.6% 140,194 139,532
70% 69.4% 122,670 121,675
60% 59.9% 105,146 104,956
50% 50.3% 87,621 88,076
40% 40.3% 70,097 70,613
30% 30.2% 52,573 52,992
20% 19.7% 35,049 34,561
10% 10.0% 17,524 17,470
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.005' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     157,604
Calibration 2     176,112
Calibration 3     175,840
ssj_ops@calibrated=175,976
100% 99.9% 175,976 175,816
90% 90.0% 158,378 158,357
80% 80.0% 140,781 140,731
70% 69.9% 123,183 122,946
60% 59.9% 105,585 105,381
50% 50.6% 87,988 88,967
40% 40.3% 70,390 70,876
30% 30.0% 52,793 52,752
20% 19.9% 35,195 35,091
10% 10.1% 17,598 17,799
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.006' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     159,441
Calibration 2     175,843
Calibration 3     175,465
ssj_ops@calibrated=175,654
100% 99.9% 175,654 175,407
90% 89.8% 158,088 157,782
80% 79.3% 140,523 139,232
70% 70.6% 122,958 124,002
60% 60.2% 105,392 105,701
50% 49.8% 87,827 87,441
40% 39.8% 70,261 69,893
30% 30.0% 52,696 52,637
20% 19.9% 35,131 34,950
10% 9.9% 17,565 17,379
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.007' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     157,395
Calibration 2     174,296
Calibration 3     174,712
ssj_ops@calibrated=174,504
100% 99.6% 174,504 173,778
90% 90.5% 157,054 157,874
80% 80.0% 139,603 139,537
70% 70.2% 122,153 122,448
60% 60.1% 104,702 104,925
50% 49.8% 87,252 86,828
40% 40.2% 69,802 70,107
30% 30.2% 52,351 52,699
20% 19.8% 34,901 34,473
10% 9.7% 17,450 16,851
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.008' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     160,744
Calibration 2     176,545
Calibration 3     176,209
ssj_ops@calibrated=176,377
100% 99.9% 176,377 176,142
90% 90.0% 158,740 158,764
80% 79.6% 141,102 140,468
70% 69.5% 123,464 122,565
60% 59.7% 105,826 105,301
50% 49.8% 88,189 87,861
40% 39.9% 70,551 70,339
30% 29.8% 52,913 52,563
20% 20.2% 35,275 35,612
10% 10.1% 17,638 17,793
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.009' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     158,545
Calibration 2     176,558
Calibration 3     175,523
ssj_ops@calibrated=176,040
100% 100.0% 176,040 176,033
90% 90.1% 158,436 158,680
80% 80.1% 140,832 141,051
70% 70.0% 123,228 123,192
60% 60.0% 105,624 105,637
50% 49.9% 88,020 87,799
40% 39.8% 70,416 70,149
30% 30.0% 52,812 52,882
20% 20.0% 35,208 35,291
10% 10.1% 17,604 17,840
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-1NGEQ3NTDG4.010' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     157,966
Calibration 2     176,927
Calibration 3     175,570
ssj_ops@calibrated=176,248
100% 100.0% 176,248 176,194
90% 90.1% 158,624 158,847
80% 80.0% 140,999 140,913
70% 69.8% 123,374 123,058
60% 60.1% 105,749 105,990
50% 50.1% 88,124 88,358
40% 40.3% 70,499 71,007
30% 29.8% 52,875 52,530
20% 19.8% 35,250 34,962
10% 10.3% 17,625 18,221
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
