| Server Configuration and Availability |
|---|
| Vendor | EMC Corporation |
| Hardware Available | October 1999 |
| Software Available | December 1999 |
| Date Tested | October 1999 |
| SFS License Number | 47 |
| Licensee Locations | Hopkinton, MA |
| CPU, Memory and Power |
|---|
| Model Name | EMC Celerra File Server, Cluster Model 506 |
| Processor | 450 MHz Pentium III Slot 1 |
| # of Processors | 2 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 512KB(I+D) off chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | 1 Control Station |
| Memory Size | 1024 MB (512 MB per node) |
| NVRAM Size | N/A |
| NVRAM Type | N/A |
| NVRAM Description | N/A |
| Server Software |
|---|
| OS Name and Version | Data Access in Real Time (DART) v1.2.41.200 |
| Other Software | UnixWare v2.1.3 on Control Station |
| File System | UxFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 192 (96 per node) |
| Fileset Size | 100.6 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet (jumbo frames) |
| Network Controller Desc. | Alteon AceNIC |
| Number Networks | 1 (N1) |
| Number Network Controllers | 2 |
| Protocol Type | TCP |
| Switch Type | 1 Alteon ACEswitch 180 |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 |
| Number of Disks | 66 |
| Number of Filesystems | 16 (F1-F16) |
| File System Creation Ops | default |
| File System Config | See Other Notes |
| Disk Controller | Symmetrix Model 3430, Ultra-Wide Differential SCSI |
| # of Controller Type | 2 |
| Number of Disks | 66 (64 data, 2 other) |
| Disk Type | Seagate Cheetah 18GB drives |
| File Systems on Disks | Root file system, server logs, file systems F1,F2...F16 |
| Special Config Notes | 4GB mem per Symmetrix, code 5265.39.24 Rev 7 |
|
