| Server Configuration and Availability |
|---|
| Vendor | EMC Corporation |
| Hardware Available | April 1999 |
| Software Available | July 1999 |
| Date Tested | April 1999 |
| SFS License Number | 47 |
| Licensee Locations | Hopkinton, MA |
| CPU, Memory and Power |
|---|
| Model Name | EMC Celerra File Server, Cluster Model 505 |
| Processor | 333 MHz Pentium II |
| # of Processors | 4 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 512KB(I+D) off chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | 1 Control Station |
| Memory Size | 2 GB (512 MB per data mover) |
| NVRAM Size | N/A |
| NVRAM Type | N/A |
| NVRAM Description | N/A |
| Server Software |
|---|
| OS Name and Version | Data Access in Real Time (DART) v1.2.21.991 |
| Other Software | UnixWare v2.1.3 on Control Station |
| File System | UxFS |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 96 per data mover |
| Fileset Size | 138.3 GB |
|
| Network Subsystem |
|---|
| Network Type | FDDI |
| Network Controller Desc. | DEC FDDI Controller (DEFPA-AA) |
| Number Networks | 2 (N1-N2) |
| Number Network Controllers | 8 |
| Protocol Type | TCP |
| Switch Type | 1 DEC FDDI GIGAswitch (DEFGA-BA) |
| Bridge Type | N/A |
| Hub Type | 4 x DEC 900MX, 4 x Bay Networks 5904 |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 4 |
| Number of Disks | 69 |
| Number of Filesystems | 32 (F1-F32) |
| File System Creation Ops | default |
| File System Config | See Other Notes |
| Disk Controller | Symmetrix Model 3430, Ultra-Wide Differential SCSI |
| # of Controller Type | 2 |
| Number of Disks | 37 (for the pair) |
| Disk Type | Seagate Cheetah 18G |
| File Systems on Disks | RootFS & server logs (5 disks); F1,F3...F31 (32 disks) |
| Special Config Notes | 4GB/Symmetrix,version 5265.21.14 Rev 053-260-020 Rev A |
| Disk Controller | Symmetrix Model 3430, Ultra-Wide Differential SCSI |
| # of Controller Type | 2 |
| Number of Disks | 32 (for the pair) |
| Disk Type | Seagate Cheetah 18G |
| File Systems on Disks | File systems F2,F4...F32 |
| Special Config Notes | 4GB/Symmetrix,version 5265.21.14 Rev 053-260-020 Rev A |
|
