| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | August 1998 |
| Software Available | April 1999 |
| Date Tested | April 1999 |
| SFS License Number | 33 |
| Licensee Locations | Santa Clara, CA |
| CPU, Memory and Power |
|---|
| Model Name | NetApp F760 (UDP, 21x18GB FCAL, 2xGbE) |
| Processor | 600MHz Alpha 21164A |
| # of Processors | 1 |
| Primary Cache | 8 KB I + 8 KB D on-chip |
| Secondary Cache | 96 KB (I+D) on-chip |
| Other Cache | 2 MB (I+D) off-chip |
| UPS | none |
| Other Hardware | none |
| Memory Size | 1 GB |
| NVRAM Size | 32 MB |
| NVRAM Type | SIMMs on PCI card |
| NVRAM Description | 6-month battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | Data ONTAP 5.3 |
| Other Software | none |
| File System | WAFL |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | dynamic |
| # NFS Processes | 0 |
| Fileset Size | 75.4 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | X1025A PCI adapter card |
| Number Networks | 2 (N1,N2) |
| Number Network Controllers | 2 |
| Protocol Type | UDP |
| Switch Type | Extreme Summit4, all ports FDX |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 1 |
| Number of Disks | 21 (3x7-disk JBOD shelves) |
| Number of Filesystems | 1 |
| File System Creation Ops | default |
| File System Config | one RAID-group of 21 disks |
| Disk Controller | onboard FCAL adapter |
| # of Controller Type | 1 |
| Number of Disks | 21 |
| Disk Type | 18GB Seagate Cheetah (ST118202FC) |
| File Systems on Disks | F1 |
| Special Config Notes | none |
|
