Server Configuration and Availability |
Vendor | Sun Microsystems Inc. |
Hardware Available | Dec 1998 |
Software Available | Oct 1998 |
Date Tested | Mar 1999 |
SFS License Number | 6 |
Licensee Locations | Palo Alto, CA |
CPU, Memory and Power |
Model Name | Sun Enterprise 3500 |
Processor | 400 MHz UltraSPARC II |
# of Processors | 6 |
Primary Cache | 16KBI+16KBD on chip |
Secondary Cache | 4MB(I+D) off chip |
Other Cache | N/A |
UPS | N/A |
Other Hardware | N/A |
Memory Size | 6 GB |
NVRAM Size | N/A |
NVRAM Type | N/A |
NVRAM Description | N/A |
Server Software |
OS Name and Version | Solaris7_64bit |
Other Software | N/A |
File System | UFS |
NFS version | 2 |
Server Tuning |
Buffer Cache Size | Dynamic |
# NFS Processes | 559 |
Fileset Size | 146.2 GB |
|
Network Subsystem |
Network Type | 1000Mbit Sun GigabitEthernet |
Network Controller Desc. | Sun GigabitEthernet SBus adaptor 2.0 |
Number Networks | 2 (N1-N2) |
Number Network Controllers | 2 |
Protocol Type | UDP |
Switch Type | 2 SunSwitch |
Bridge Type | N/A |
Hub Type | N/A |
Other Network Hardware | N/A |
Disk Subsystem and Filesystems |
Number Disk Controllers | 5 |
Number of Disks | 228 |
Number of Filesystems | 224 (F1-F224) |
File System Creation Ops | default |
File System Config | default |
Disk Controller | On-board FC-AL/GBIC |
# of Controller Type | 1 |
Number of Disks | 4 |
Disk Type | 9GB 7200rpm FC-AL |
File Systems on Disks | OS, swap |
Special Config Notes | |
Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
# of Controller Type | 1 |
Number of Disks | 56 |
Disk Type | 9GB 7200rpm FC-AL |
File Systems on Disks | F1-F14, F15-F28, F29-F42, F43-F56 |
Special Config Notes | Sun StorEdge A5000 each w/ 14 FC-AL drives |
Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
# of Controller Type | 1 |
Number of Disks | 56 |
Disk Type | 9GB 7200rpm FC-AL |
File Systems on Disks | F57-F70, F71-F84, F85-F98, F99-F112 |
Special Config Notes | Sun StorEdge A5000 each w/ 14 FC-AL drives |
Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
# of Controller Type | 1 |
Number of Disks | 56 |
Disk Type | 9GB 7200rpm FC-AL |
File Systems on Disks | F113-F126, F127-F140, F141-F154, F155-F168 |
Special Config Notes | Sun StorEdge A5000 each w/ 14 FC-AL drives |
Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
# of Controller Type | 1 |
Number of Disks | 56 |
Disk Type | 9GB 7200rpm FC-AL |
File Systems on Disks | F169-F182, F183-F196, F197-F210, F211-F224 |
Special Config Notes | Sun StorEdge A5000 each w/ 14 FC-AL drives |
|
Testbed Configuration |
LG # | LG Type | Network | Target File Systems | Notes |
1/2/3/4 | LG1 | N1 | F1,F17,..,F209/F2,F18,..,F210/F3,F19,..,F211/F4,F20,..,F212 | N/A |
5/6/7/8 | LG1 | N1 | F5,F21,..,F213/F6,F22,..,F214/F7,F23,..,F215/F8,F24,..,F216 | N/A |
9/10/11/12 | LG1 | N2 | F9,F25,..,F217/F10,F26,..,F218/F11,F27,..,F219/F12,F28,..,F220 | N/A |
13/14/15/16 | LG1 | N2 | F13,F29,..,F221/F14,F30,..,F222/F15,F31,..,F223/F16,F32,..,F224 | N/A |
