| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | August 1998 |
| Software Available | August 1998 |
| Date Tested | July 1998 |
| SFS License Number | 33 |
| Licensee Locations | Santa Clara, CA |
| CPU, Memory and Power |
|---|
| Model Name | NetApp F740 (UDP, 28x9GB FCAL, GbE) |
| Processor | 400MHz Alpha 21164A |
| # of Processors | 1 |
| Primary Cache | 8 KB I + 8 KB D on chip |
| Secondary Cache | 96 KB (I+D) on chip |
| Other Cache | 1 MB (I+D) off chip |
| UPS | none |
| Other Hardware | none |
| Memory Size | 512 MB |
| NVRAM Size | 32 MB |
| NVRAM Type | NVRAM SIMMs on PCI card |
| NVRAM Description | 6-month battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | NetApp Release 5.1.1 |
| Other Software | none |
| File System | WAFL |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | dynamic |
| # NFS Processes | see notes |
| Fileset Size | 49.3 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | Gigabit PCI Adapter |
| Number Networks | 1 (N1) |
| Number Network Controllers | 1 |
| Protocol Type | UDP |
| Switch Type | 1 Foundry Networks FWS16 (N1) |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 1 |
| Number of Disks | 28 |
| Number of Filesystems | 1 |
| File System Creation Ops | default |
| File System Config | one RAID group of 28 disks |
| Disk Controller | onboard Fibre Channel adapter |
| # of Controller Type | 1 |
| Number of Disks | 28 (4x7-disk JBOD shelves) |
| Disk Type | 9GB Seagate Barracuda (ST19171FC) |
| File Systems on Disks | F1 |
| Special Config Notes | none |
|
