| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | June 1997 |
| Software Available | January 1998 |
| Date Tested | November 1997 |
| SFS License Number | 33 |
| Licensee Locations | Santa Clara, CA |
| CPU, Memory and Power |
|---|
| Model Name | NetApp F630 |
| Processor | 500MHz Alpha 21164A |
| # of Processors | 1 |
| Primary Cache | 8KBI+8KBD on chip |
| Secondary Cache | 96KB(I+D) on chip |
| Other Cache | 2MB(I+D) off chip |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 512 MB |
| NVRAM Size | 32MB |
| NVRAM Type | NVRAM SIMMs on PCI card |
| NVRAM Description | 6-month battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | NetApp OS version 5.0 beta |
| Other Software | N/A |
| File System | WAFL |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | see notes |
| Fileset Size | 29.0 GB |
|
| Network Subsystem |
|---|
| Network Type | FDDI |
| Network Controller Desc. | x1102 (SA TP) MLT3 FDDI Adaptor |
| Number Networks | 3 (N1-N3) |
| Number Network Controllers | 3 |
| Protocol Type | TCP |
| Switch Type | N/A |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | DEC Concentrator |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 |
| Number of Disks | 26 |
| Number of Filesystems | 1 |
| File System Creation Ops | default |
| File System Config | default |
| Disk Controller | Dual-Channel Fast/Wide/Differential SCSI |
| # of Controller Type | 2 |
| Number of Disks | 26 (2 X623 13-disk shelf-pairs) |
| Disk Type | 9-GB Seagate Barracuda |
| File Systems on Disks | F1 |
| Special Config Notes | two RAID groups (13 disks each) |
|
