| Server Configuration and Availability |
|---|
| Vendor | Sun Microsystems Inc. |
| Hardware Available | Aug 2000 |
| Software Available | Apr 2000 |
| Date Tested | Sep 2000 |
| SFS License Number | 6 |
| Licensee Locations | Palo Alto, CA |
| CPU, Memory and Power |
|---|
| Model Name | Sun Enterprise 4500 |
| Processor | 400 MHz UltraSPARC II |
| # of Processors | 10 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 8MB(I+D) off chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 12 GB |
| NVRAM Size | 9216MB (256MB per Sun StorEdge T3 controller) |
| NVRAM Type | Sun StorEdge T3 write cache |
| NVRAM Description | auto-sensing WB/WT depending battery charge |
| Server Software |
|---|
| OS Name and Version | Solaris8_64bit |
| Other Software | N/A |
| File System | UFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 512 |
| Fileset Size | 171.8 GB |
|
| Network Subsystem |
|---|
| Network Type | 1000Mbit Sun GigabitEthernet |
| Network Controller Desc. | Sun GigabitEthernet SBus adaptor 2.0 |
| Number Networks | 3 (N1-N3) |
| Number Network Controllers | 3 |
| Protocol Type | UDP |
| Switch Type | 3 Extremenetworks Summit2 switch |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 19 |
| Number of Disks | 330 |
| Number of Filesystems | 36 (F1-F36) |
| File System Creation Ops | default |
| File System Config | default |
| Disk Controller | On-board SCSI-2 |
| # of Controller Type | 1 |
| Number of Disks | 6 |
| Disk Type | 9GB 7200rpm |
| File Systems on Disks | OS, swap |
| Special Config Notes | |
| Disk Controller | FC-AL SBus Adapter (FC100/S)/GBIC |
| # of Controller Type | 18 (i=1,2,..,18) |
| Number of Disks | 9,9/9,9/../9,9 |
| Disk Type | 18GB 10000rpm FC-AL (ST118202FC) |
| File Systems on Disks | F1,F2/F3,F4/../F35,F36 |
| Special Config Notes | Filesystem on RAID5 LUNs (see "Other Notes") |
|
