| Server Configuration and Availability |
|---|
| Vendor | EMC Corporation |
| Hardware Available | July 2000 |
| Software Available | August 2000 |
| Date Tested | June 2000 |
| SFS License Number | 47 |
| Licensee Locations | Hopkinton, MA |
| CPU, Memory and Power |
|---|
| Model Name | Celerra 507 Cluster (1FS/Data Mover) |
| Processor | 700 MHz Pentium III, Slot I |
| # of Processors | 14 (1 per Data Mover) |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 256KB ATC on chip |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | 1 Control Station, Model 507 |
| Memory Size | 7 GB (512MB per Data Mover) |
| NVRAM Size | N/A |
| NVRAM Type | N/A |
| NVRAM Description | N/A |
| Server Software |
|---|
| OS Name and Version | Data Access in Real Time (DART) v2.1.15.200 |
| Other Software | UnixWare v2.1.3 on Control Station |
| File System | UxFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 1568 (112 per Data Mover) |
| Fileset Size | 1015.4 GB |
|
| Network Subsystem |
|---|
| Network Type | Jumbo Frame Gigabit |
| Network Controller Desc. | Alteon AceNIC Rev C |
| Number Networks | 1 (N1) |
| Number Network Controllers | 14 |
| Protocol Type | TCP |
| Switch Type | 1 Cisco Catalyst 6509 |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 6 |
| Number of Disks | 433 |
| Number of Filesystems | 14 (F1-F14) |
| File System Creation Ops | default |
| File System Config | Striped across 30 volumes with 8KB stripe unit |
| Disk Controller | Symmetrix Model 8430 |
| # of Controller Type | 1 |
| Number of Disks | 73 |
| Disk Type | Seagate Cheetah 36GB, split into 4 volumes |
| File Systems on Disks | RootFS (1), UxFS log (2), File System F1-F14 (70) |
| Special Config Notes | 16GB memory in Symmetrix, code 5266.23.18S.1 |
| Disk Controller | Symmetrix Model 8430 |
| # of Controller Type | 5 |
| Number of Disks | 72 (each Symmetrix) |
| Disk Type | Seagate Cheetah 36GB, split into 4 volumes |
| File Systems on Disks | UxFS log (2 each), File System F1-F14 (70 each) |
| Special Config Notes | 16GB memory in Symmetrix, code 5266.23.18S.1 |
|
