SPECjbb

SPECjbb2005		SPECjbb2005 bops = 2772103, SPECjbb2005 bops/JVM = 138605
HUAWEI Inc. HUAWEI RH5885 (Intel Xeon E7-8870, 2.40 GHz)
IBM IBM J9 VM (build 2.6, JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120322_106209 (JIT enabled, AOT enabled)

JVM run JVM Scores

1 138072

2 138660

3 138688

4 139983

5 138856

6 139689

7 139042

8 137842

9 139450

10 138261

11 139177

12 138171

13 139484

14 137482

15 139374

16 139649

17 138515

18 139538

19 137663

20 134507

SPECjbb2005 bops = 2772103, SPECjbb2005 bops/JVM = 138605

Hardware

Hardware Vendor HUAWEI Inc.

Vendor URL http://www.huawei.com

Model HUAWEI RH5885 (Intel Xeon E7-8870, 2.40 GHz)

Processor Intel Xeon E7-8870 2.40 GHz (Intel Turbo Boost Technology up to 2.80 GHz)

MHz 2400

# of Chips 4

# of Cores 40

# of Cores/Chip 10

HW Threading Enabled? yes

Procs Avail to Java 80

Memory (MB) 1048576

Memory Details 1024 (64 x 16 GB 4Rx4 PC3-8500R-7, ECC)

Primary cache 32 KB (I) + 32 KB (D)

Secondary cache 256 KB (I+D) on chip per core

Other cache 30 MB (I+D) L3 on chip per chip

Filesystem NTFS

Disks 1 x 96GB SSD

Other hardware N/A

Software

Software Vendor IBM

Vendor URL http://www.ibm.com

JVM Version IBM J9 VM (build 2.6, JRE 1.7.0 Windows Server 2008 R2 amd64-64 20120322_106209 (JIT enabled, AOT enabled)

JVM Command Line start /high /node [0,1,2,3] /affinity [F,F0,F00,F000,F0000] -Xms1700m -Xmx1700m -Xmn1375m -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -XlockReservation -Xnoloa -XtlhPrefetch -Xlp -Xconcurrentlevel0

JVM Initial Heap Memory (MB) 1700

JVM Maximum Heap Memory (MB) 1700

JVM Address bits 64

JVM CLASSPATH .\jbb.jar;
.\check.jar;

JVM BOOTCLASSPATH C:\1.70\lib\aggressive.jar;
C:\1.70\bin\compressedrefs\jclSC170\vm.jar;
C:\1.70\lib\se-service.jar;
C:\1.70\lib\math.jar;
C:\1.70\lib\jlm.jar;
C:\1.70\lib\ibmorb.jar;
C:\1.70\lib\ibmorbapi.jar;
C:\1.70\lib\ibmcfw.jar;
C:\1.70\lib\ibmpkcs.jar;
C:\1.70\lib\ibmcertpathfw.jar;
C:\1.70\lib\ibmjgssfw.jar;
C:\1.70\lib\ibmjssefw.jar;
C:\1.70\lib\ibmsaslfw.jar;
C:\1.70\lib\ibmjcefw.jar;
C:\1.70\lib\ibmjgssprovider.jar;
C:\1.70\lib\ibmjsseprovider2.jar;
C:\1.70\lib\ibmcertpathprovider.jar;
C:\1.70\lib\xmldsigfw.jar;
C:\1.70\lib\xml.jar;
C:\1.70\lib\charsets.jar;
C:\1.70\lib\resources.jar;
C:\1.70\lib\rt.jar

OS Version Microsoft Windows Server 2008 R2 Enterprise Edition SP1

Other software N/A

Test Information

Tested by Huawei

SPEC license #

Test location Hangzhou.RPC

Test date Oct 16, 2012

H/w available October-2012

JVM available Jun-2012

OS available Feb-2011

Other s/w available N/A

AOT Compilation

N/A

Tuning

Operating system tunings
Using the local security settings console, "Lock pages in memory" was enabled for the user running the benchmark
Hardware Prefetcher Disabled in BIOS.Adjacent Cache Line Prefetch Disabled in BIOS.Maximum Performance Mode selected in BIOS.Each JVM instance was affinitized to 1 chip.The parameter expected_peak_warehouse was set to 4.

Notes

Command line options are described at: http://publib.boulder.ibm.com/infocenter/java7sdk/v7r0/index.jsp

JVM 1 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	36417
2	102625
3	118671
4	140257	*
5	139129	*
6	138082	*
7	136831	*
8	136063	*
SPECjbb2005	(from 4 to 8)	138072 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 2 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	35917
2	104790
3	116826
4	140922	*
5	140380	*
6	138511	*
7	137477	*
8	136012	*
SPECjbb2005	(from 4 to 8)	138660 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 3 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	35805
2	104462
3	118679
4	140760	*
5	140084	*
6	138744	*
7	137705	*
8	136145	*
SPECjbb2005	(from 4 to 8)	138688 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 4 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38628
2	104792
3	122065
4	143153	*
5	142004	*
6	139686	*
7	138126	*
8	136947	*
SPECjbb2005	(from 4 to 8)	139983 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 5 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	35082
2	106289
3	125359
4	142561	*
5	140466	*
6	138141	*
7	137082	*
8	136031	*
SPECjbb2005	(from 4 to 8)	138856 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 6 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38652
2	106370
3	124201
4	143005	*
5	140462	*
6	140001	*
7	138003	*
8	136973	*
SPECjbb2005	(from 4 to 8)	139689 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 7 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	36592
2	106065
3	123834
4	141981	*
5	141126	*
6	138651	*
7	137027	*
8	136422	*
SPECjbb2005	(from 4 to 8)	139042 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 8 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37524
2	103598
3	126596
4	141161	*
5	139371	*
6	137653	*
7	135727	*
8	135299	*
SPECjbb2005	(from 4 to 8)	137842 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 9 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	41716
2	105128
3	128336
4	143093	*
5	140777	*
6	139719	*
7	136855	*
8	136806	*
SPECjbb2005	(from 4 to 8)	139450 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 10 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38402
2	105856
3	123609
4	141425	*
5	139670	*
6	138190	*
7	136607	*
8	135413	*
SPECjbb2005	(from 4 to 8)	138261 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 11 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38825
2	107053
3	127720
4	141985	*
5	140972	*
6	138766	*
7	137421	*
8	136742	*
SPECjbb2005	(from 4 to 8)	139177 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 12 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37684
2	99681
3	123232
4	141135	*
5	139292	*
6	138354	*
7	136646	*
8	135429	*
SPECjbb2005	(from 4 to 8)	138171 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 13 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	36772
2	102724
3	126375
4	142505	*
5	141229	*
6	139728	*
7	137662	*
8	136298	*
SPECjbb2005	(from 4 to 8)	139484 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 14 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37647
2	104935
3	121154
4	140595	*
5	139462	*
6	137496	*
7	135194	*
8	134663	*
SPECjbb2005	(from 4 to 8)	137482 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 15 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	35922
2	108203
3	126073
4	142718	*
5	141267	*
6	138859	*
7	137201	*
8	136823	*
SPECjbb2005	(from 4 to 8)	139374 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 16 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38602
2	101074
3	124756
4	143075	*
5	140857	*
6	139503	*
7	138112	*
8	136697	*
SPECjbb2005	(from 4 to 8)	139649 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 17 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38451
2	102712
3	121950
4	141018	*
5	140033	*
6	138581	*
7	136904	*
8	136041	*
SPECjbb2005	(from 4 to 8)	138515 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 18 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	37392
2	104281
3	119528
4	142102	*
5	140890	*
6	139555	*
7	138088	*
8	137055	*
SPECjbb2005	(from 4 to 8)	139538 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 19 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	38376
2	104182
3	122112
4	140700	*
5	138772	*
6	137677	*
7	136435	*
8	134731	*
SPECjbb2005	(from 4 to 8)	137663 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012

JVM 20 Scores:


Warehouses	SPECjbb2005 bops	Incl. in metric
1	36990
2	102722
3	116001
4	137103	*
5	136172	*
6	134263	*
7	132918	*
8	132077	*
SPECjbb2005	(from 4 to 8)	134507 SPECjbb2005 bops

SPEC license # MISSING

Tested by: Huawei

Test date: Oct 16, 2012
