SPECjbb2005 SPECjbb2005 bops = 3031184, SPECjbb2005 bops/JVM = 94725
IBM Corporation IBM Power 780 (4.14 GHz, 32 core)
IBM Corporation JRE 1.6.0 (32-bit) IBM J9 2.4 AIX [build jvmap3260sr7-20091214_49398(SR7)]

JVM run JVM Scores
194214
294450
395526
494365
594984
695043
793519
895286
994728
1094477
1194606
1294224
1395000
1494869
1594815
1696154
1793589
1893843
1995385
2095148
2195026
2295418
2395602
2494558
2593101
2695048
2794763
2895381
2994413
3094571
3194727
3294351
SPECjbb2005 bops = 3031184, SPECjbb2005 bops/JVM = 94725

Hardware
Hardware Vendor IBM Corporation
Vendor URL http://www.ibm.com
Model IBM Power 780 (4.14 GHz, 32 core)
Processor POWER7 (TurboCore mode)
MHz 4140
# of Chips 8
# of Cores 32
# of Cores/Chip 4
HW Threading Enabled? Yes
Procs Avail to Java 128
Memory (MB) 524288
Memory Details 64 x 8GB DDR3 1066 MHz
Primary cache 32 KB I + 32 KB D on chip per core
Secondary cache 256KB I+D on chip per core
Other cache 4MB I+D on chip per core; 16 MB I+D on chip per chip
Filesystem AIX/JFS2
Disks 1 x 146GB SAS 15K RPM
Other hardware
Software
Software Vendor IBM Corporation
Vendor URL http://www.ibm.com
JVM Version JRE 1.6.0 (32-bit) IBM J9 2.4 AIX [build jvmap3260sr7-20091214_49398(SR7)]
JVM Command Line execrset -c processor_set_number -e java -Xlp -Xgcpolicy:gencon -Xms2560m -Xmx2560m -Xmn2048m -Xaggressive -XtlhPrefetch -XlockReservation -Xgcthreads4 -Xnoloa spec.jbb.JBBmain -propfile SPECjbb.props
JVM Initial Heap Memory (MB) 2560
JVM Maximum Heap Memory (MB) 2560
JVM Address bits 32
JVM CLASSPATH jbb.jar:
check.jar
JVM BOOTCLASSPATH /spec/sr7/jre/lib/vm.jar:
/spec/sr7/jre/lib/annotation.jar:
/spec/sr7/jre/lib/beans.jar:
/spec/sr7/jre/lib/java.util.jar:
/spec/sr7/jre/lib/jndi.jar:
/spec/sr7/jre/lib/logging.jar:
/spec/sr7/jre/lib/security.jar:
/spec/sr7/jre/lib/sql.jar:
/spec/sr7/jre/lib/ibmorb.jar:
/spec/sr7/jre/lib/ibmorbapi.jar:
/spec/sr7/jre/lib/ibmcfw.jar:
/spec/sr7/jre/lib/rt.jar:
/spec/sr7/jre/lib/charsets.jar:
/spec/sr7/jre/lib/resources.jar:
/spec/sr7/jre/lib/ibmpkcs.jar:
/spec/sr7/jre/lib/ibmcertpathfw.jar:
/spec/sr7/jre/lib/ibmjgssfw.jar:
/spec/sr7/jre/lib/ibmjssefw.jar:
/spec/sr7/jre/lib/ibmsaslfw.jar:
/spec/sr7/jre/lib/ibmjcefw.jar:
/spec/sr7/jre/lib/ibmjgssprovider.jar:
/spec/sr7/jre/lib/ibmjsseprovider2.jar:
/spec/sr7/jre/lib/ibmcertpathprovider.jar:
/spec/sr7/jre/lib/ibmxmlcrypto.jar:
/spec/sr7/jre/lib/management-agent.jar:
/spec/sr7/jre/lib/xml.jar:
/spec/sr7/jre/lib/jlm.jar:
/spec/sr7/jre/lib/javascript.jar
OS Version IBM AIX V6.1 with the 6100-04 Technology Level and Service Pack 3
Other software
Test Information
Tested by IBM Corporation
SPEC license # 11
Test location Austin, TX
Test date Apr 2, 2010
H/w available Mar-2010
JVM available Dec-2009
OS available Mar-2010
Other s/w available
AOT Compilation

Tuning
Operating system tunings
  • vmo -o lgpg_regions=12288 -o lgpg_size=16777216 -o v_pinshm=1
  • dscrctl -n -s 1
  • MEMORY_AFFINITY=MCM
Notes
  • 32 JVMs were run in processor sets each containing 1 core

JVM 1 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38977
2 75128
3 77432
4 96441 *
5 95440 *
6 94362 *
7 91900 *
8 92929 *
SPECjbb2005 (from 4 to 8) 94214 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 2 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37426
2 75930
3 76872
4 96469 *
5 95429 *
6 94229 *
7 93554 *
8 92568 *
SPECjbb2005 (from 4 to 8) 94450 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 3 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 39278
2 74709
3 77973
4 97425 *
5 96484 *
6 95275 *
7 94681 *
8 93764 *
SPECjbb2005 (from 4 to 8) 95526 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 4 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 39941
2 75895
3 78565
4 96285 *
5 95150 *
6 94311 *
7 93558 *
8 92522 *
SPECjbb2005 (from 4 to 8) 94365 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 5 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37575
2 75013
3 78795
4 97119 *
5 95649 *
6 94921 *
7 93893 *
8 93337 *
SPECjbb2005 (from 4 to 8) 94984 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 6 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40898
2 74693
3 79504
4 97189 *
5 95949 *
6 94972 *
7 93988 *
8 93116 *
SPECjbb2005 (from 4 to 8) 95043 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 7 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38525
2 76635
3 76567
4 95432 *
5 94496 *
6 93582 *
7 92560 *
8 91523 *
SPECjbb2005 (from 4 to 8) 93519 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 8 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40698
2 75710
3 79176
4 97522 *
5 96215 *
6 95154 *
7 94307 *
8 93235 *
SPECjbb2005 (from 4 to 8) 95286 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 9 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38782
2 79928
3 78638
4 96453 *
5 95550 *
6 94687 *
7 94041 *
8 92908 *
SPECjbb2005 (from 4 to 8) 94728 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 10 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40385
2 75392
3 78737
4 96424 *
5 95327 *
6 94353 *
7 93592 *
8 92687 *
SPECjbb2005 (from 4 to 8) 94477 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 11 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 39668
2 77502
3 79916
4 96067 *
5 94894 *
6 94877 *
7 93961 *
8 93229 *
SPECjbb2005 (from 4 to 8) 94606 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 12 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38829
2 74866
3 78440
4 95945 *
5 95222 *
6 94148 *
7 93289 *
8 92515 *
SPECjbb2005 (from 4 to 8) 94224 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 13 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 36978
2 78514
3 76439
4 97131 *
5 95879 *
6 94852 *
7 94012 *
8 93127 *
SPECjbb2005 (from 4 to 8) 95000 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 14 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38163
2 77085
3 76417
4 97222 *
5 95911 *
6 94606 *
7 93601 *
8 93008 *
SPECjbb2005 (from 4 to 8) 94869 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 15 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 36861
2 73484
3 76433
4 96913 *
5 95790 *
6 94541 *
7 93882 *
8 92952 *
SPECjbb2005 (from 4 to 8) 94815 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 16 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37981
2 76979
3 79719
4 97714 *
5 97199 *
6 96155 *
7 95386 *
8 94318 *
SPECjbb2005 (from 4 to 8) 96154 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 17 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37982
2 75676
3 77442
4 95590 *
5 94455 *
6 93350 *
7 92718 *
8 91832 *
SPECjbb2005 (from 4 to 8) 93589 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 18 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 36724
2 74569
3 77424
4 95982 *
5 94873 *
6 93410 *
7 92801 *
8 92148 *
SPECjbb2005 (from 4 to 8) 93843 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 19 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38445
2 77767
3 77457
4 97138 *
5 96231 *
6 95217 *
7 94569 *
8 93770 *
SPECjbb2005 (from 4 to 8) 95385 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 20 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37975
2 75189
3 79012
4 97264 *
5 95951 *
6 95048 *
7 94170 *
8 93308 *
SPECjbb2005 (from 4 to 8) 95148 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 21 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 39358
2 75839
3 78211
4 97018 *
5 96006 *
6 94947 *
7 94043 *
8 93117 *
SPECjbb2005 (from 4 to 8) 95026 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 22 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 36946
2 75451
3 78556
4 97651 *
5 96328 *
6 95189 *
7 94311 *
8 93611 *
SPECjbb2005 (from 4 to 8) 95418 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 23 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38691
2 74705
3 79525
4 97756 *
5 96473 *
6 95414 *
7 94597 *
8 93769 *
SPECjbb2005 (from 4 to 8) 95602 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 24 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37815
2 77025
3 79091
4 96717 *
5 95219 *
6 94366 *
7 93618 *
8 92869 *
SPECjbb2005 (from 4 to 8) 94558 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 25 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37944
2 75143
3 75815
4 95483 *
5 93934 *
6 92833 *
7 91948 *
8 91309 *
SPECjbb2005 (from 4 to 8) 93101 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 26 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 40399
2 76417
3 75861
4 97194 *
5 95832 *
6 95059 *
7 94033 *
8 93121 *
SPECjbb2005 (from 4 to 8) 95048 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 27 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37928
2 76745
3 79086
4 95847 *
5 95910 *
6 95021 *
7 93838 *
8 93200 *
SPECjbb2005 (from 4 to 8) 94763 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 28 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37416
2 79401
3 78610
4 97133 *
5 96444 *
6 95331 *
7 94382 *
8 93614 *
SPECjbb2005 (from 4 to 8) 95381 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 29 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37687
2 78657
3 78606
4 96299 *
5 95369 *
6 94296 *
7 93503 *
8 92600 *
SPECjbb2005 (from 4 to 8) 94413 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 30 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37929
2 77185
3 78158
4 96589 *
5 95436 *
6 94560 *
7 93600 *
8 92670 *
SPECjbb2005 (from 4 to 8) 94571 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 31 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 38437
2 74992
3 78265
4 96778 *
5 95676 *
6 94640 *
7 93813 *
8 92729 *
SPECjbb2005 (from 4 to 8) 94727 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010

JVM 32 Scores:
Warehouses SPECjbb2005 bops Incl. in metric
1 37372
2 76439
3 77296
4 96094 *
5 95262 *
6 94413 *
7 93414 *
8 92573 *
SPECjbb2005 (from 4 to 8) 94351 SPECjbb2005 bops
SPEC license # 11 Tested by: IBM Corporation Test date: Apr 2, 2010
SPECjbb2005 Version: [SPECjbb2005 1.07, March 15, 2006]
Reporting page, Copyright © 2005-2007 SPEC. All rights reserved

First published at SPEC.org on 07-May-2010
