| Name | H3C UniServer R6700 G3 |
| Vendor | New H3C Technologies Co., Ltd. |
| Vendor URL | http://www.h3c.com |
| Available | Dec-2018 |
| Model | H3C UniServer R6700 G3 |
| Form Factor | 2U |
| CPU Name | Intel Xeon Platinum 8280 |
| CPU Characteristics | 28 core, 2.70GHz, 38.5MB L3 Cache (Turbo Boost Technology up to 4.00 GHz) |
| Number of Systems | 1 |
| Nodes Per System | 1 |
| Chips Per System | 4 |
| Cores Per System | 112 |
| Cores Per Chip | 28 |
| Threads Per System | 224 |
| Threads Per Core | 2 |
| Version | 2.00.27 V100R001B02D027 |
| CPU Frequency (MHz) | 2700 |
| Primary Cache | 32 KB I + 32 KB D on chip per core |
| Secondary Cache | 1 MB I+D on chip per core |
| Tertiary Cache | 38.5MB I+D on chip per chip |
| Other Cache | None |
| Disk | 1x 960GB SATA SSD |
| File System | xfs |
| Memory Amount (GB) | 3072 |
| # and size of DIMM(s) | 48 x 64GB |
| Memory Details | 64GB 4DRx4 PC4-2666V-LE2-11 |
| # and type of Network Interface Cards (NICs) | 1x 1 Gbit NIC |
| Power Supply Quantity and Rating (W) | 2 x 1200 |
| Other Hardware | None |
| Cabinet/Housing/Enclosure | None |
| Shared Description | None |
| Shared Comment | None |
| Notes | - Yes: The test sponsor attests, as of date of publication, that CVE-2017-5754 (Meltdown) is mitigated in the system as tested and documented.
- Yes: The test sponsor attests, as of date of publication, that CVE-2017-5753 (Spectre variant 1) is mitigated in the system as tested and documented.
- Yes: The test sponsor attests, as of date of publication, that CVE-2017-5715 (Spectre variant 2) is mitigated in the system as tested and documented.
- Supported by New H3C Technologies Co., Ltd.
|
|
| Name | None |
| Vendor | None |
| Vendor URL | None |
| Version | None |
| Available | None |
| Bitness | None |
| Notes | None |
|
|
